Nichola S Escondido , CA May 13, 2019 Appliance: KitchenAid Electric Cooktop KECC566RBL01 One of my Kitchenaid cooktop burners stopped working, part of the two burner bridge combo Ordered a new combo unit consisting of two round burners plus the bridge section, and received it in two days - earlier than expected! Ten screws attaching the cooktop to the burner enclosure were removed to reveal the burner element. I could see the burnt out area of the bad burner. I marked each wire according to the terminal (1a, 1b, 2a, 2b) on both of the round burners and then removed the bad burner. Then simply re-attached the wires to the corresponding terminals on the new burners, using the enclosed extension wires where necessary (the new unit had terminals arranged differently than the original). The entire repair took about thirty minutes. Turned the electricity back on and - presto - it's all working perfectly again. Read More... Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Screwdrivers
Michael A Cleburne , TX August 10, 2025 The element failed The replacement element included extensions to make the wires long enough. Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
Johnny B Sylvan Springs , AL January 30, 2022 Surface element. After waiting 3 months for a local repair center to keep telling me parts were on order, I decided to order the part myself. I found AppliancePartsPros online and ordered it. I received it in 4 days but it was damaged. I called APP and they shipped me a replacement overnight. Had a little trouble since the wiring was a little different from the original. Talked with Mary B at APP, very courteous. We got it working. Very Satisified. Johnny B. Read More... Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Screwdrivers
