Whirlpool WPW10346525 Overfill Control Float (Dishwasher) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Dishwasher Valve.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10346525 replaces AP6020008, W10346525, 4445387, PS11753319.

Description

This overfill control float sits in the dishwasher tub and rises with the water level to signal the float switch to stop filling. Replacing a cracked or sticking float helps prevent leaks and recurring fill issues. What it does:

• Rises with the water level to actuate the float switch and stop the inlet valve
• Helps prevent overfilling and water leaking from the door
• A float stuck in the UP position can cause no fill or short fill
• A float stuck DOWN or damaged can allow overfilling

What's included:

• 1 overfill control float

Install notes:

• Disconnect power and turn off water before servicing
• Remove the lower rack; lift out the old float from its guide and clear any debris in the well
• Insert the new float, ensuring it moves freely and reliably actuates the switch when raised
