Carla P Keller , TX March 14, 2015 I broke the oven door glass after running the cleaning cycle and wiping it with a damp cloth Ordered the replacement glass through AppliancePartsPros.com and it arrived the next day. Wow! There are three pieces of glass (four if you include the front glass panel on the oven door when it is closed) layered inside and in looking at the diagram I ordered #7 and #24 replacement parts. I figured while I was in there the oven glass looked stained and maybe I would want new glass. With that said when the glass arrived and my husband and I got the oven door off and apart, we realized I actually needed part #3. #7 and #24 were the two pieces of glass that are in the middle of the door. They were both discolored so I was glad that I had both pieces to replace. I then contacted AppliancePartsPros.com and spoke with a very friendly, helpful woman who did confirm that the broken piece needing to be replaced was #3. We got it ordered and it arrived three days later - it was late Friday night and so the weekend got in the way. My husband and I just took it apart again and put in the last new piece. While I had it apart the first time I had thoroughly cleaned every square inch of the door so when it went back together it looked brand new! So after debating with myself to take apart and clean the lower oven also, I decided to do it. The second one went much faster as we were now quite familiar with how to dis / reassemble. Cleaned all the glass pieces and door and the area you can not get to with the door attached - both the door and the unit. Put it all back together and now they both look new. Amazing! All in all the cost of the three pieces of glass for the top oven was around $150. Customer service was top notch and also the accompanying video on how to take the oven door off the unit and disassemble was incredibly helpful!. The video was a different model than ours, but it is the same principle and it worked beautifully. Thank you so much! Read More... 28 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Screwdrivers
Edward B Chatsworth , CA June 12, 2014 Appliance: KitchenAid 30" Built-In Electric Oven Self Clean Thermal Convection KEBC107KSS03 Cracked oven door glass The Kitchenaid wall oven hot side glass cracked when water spilled on it. Ordered replacement glass which arrived very quickly and was expertly packaged. There are two, no, three important lessons that were learned. a. There are up to four layers of glass in an oven door. The inner glass facing the hot oven is labeled "inner", and the two nested glass panes in the interior of the door are also labeled "inner". Be sure to order the correct inner glass b. the "how to" movie shows how to unlatch a modern Kitchenaid door from the oven. It was incorrect for my oven. For my oven it required lodging small screwdriver bits into the open mechanisms. Then by closing the oven door the door latches could unhook from the wall unit. c. the "how to" movie for replacing the glass was not correct for my door. I basically had to unscrew and disassemble the whole door and all four panes to get to the cracked glass. Take measures to photograph disassembly to help with re-assembly. Also mark or photograph screw types. There are at least two different types and it is not intuitive where they should return. d. Lastly... When you clamp the inner glass panes back into place, apply sufficient screw torque to the clamping frame, else once door goes into place, the inner inner glass will slide down. The final repair looks awesome. The glass is clean and of top notch quality. Read More... 120 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Screwdrivers
Martha L Seneca , SC February 07, 2015 I broke the inner door glass of my oven door when i cleaned it I watched a YouTube video prepared by someone at Appliance Parts Pro. Then I did a live chat to get the part ordered. It came 4 days later and that night my husband and I fixed it. Awesome! Thanks Appliance Parts Pros! Read More... 13 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Screwdrivers
Joel K Cumming , GA March 23, 2014 The glass on my oven door had a crack I ordered the glass from you and it was delivered earlier than I expected. It was packed perfectly with easy directions and it took me under an hour to complete the job. Read More... 6 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Screwdrivers
Dennis S Jeffersonton , VA December 06, 2018 Appliance: Whirlpool Wall Oven RBD306PDQ12 I broke the innermost glass (piece facing oven) I broke the innermost glass (piece facing oven). This occurred after cleaning all 3 of the glass panels inside the door. I apparently got the fiberglass insulation wet, but not evenly wet. After reassembly, I ran the cleaning cycle and that is when it broke. So, I ordered a new replacement glass and new fiberglass insulation. Problem gone. Thanks Read More... 3 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
