Whirlpool WPW10208419 Hinge Retainer Plate (Door) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Dryer Bracket & Flange and Washer Bracket & Flange.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPW10208419 replaces AP6017116, W10208419, 1872429, PS11750411.

Description

This hinge retainer plate secures the appliance door hinge to the cabinet or door, keeping alignment and smooth operation. Replace a bent, stripped, or missing plate to stop hinge wobble and help the door close and seal properly.

• Anchors the door hinge and distributes load to prevent shifting
• Maintains proper door alignment and gap for smooth opening/closing
• Helps prevent door sagging, rubbing, or poor gasket sealing
• Typical symptoms include a loose hinge, wobbly door, or door not closing flush

What's included: 1 hinge retainer plate Install notes:

• Disconnect power and support the door before removing any hinge fasteners
• Mark hinge locations to preserve alignment during reassembly
• Install the plate in the correct orientation; transfer any spacers/shims in original order
• Tighten fasteners evenly, then verify door alignment and gasket seal
