Whirlpool WP3976575 Dryer Timer (60 Hz) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WP3976575 replaces AP6009024, 3976575, 3406014, 548374, PS11742166.

Description

This 60 Hz mechanical timer controls and advances the dryer's cycles. Replacing a worn timer restores accurate cycle timing so the dryer starts, runs, and shuts off when it should. What it does:

• Sequences power to motor, heat, and other circuits through the cycle using internal cams/contacts
• Advances the cycle at proper intervals for timed and automatic settings
• Helps address symptoms like a cycle that won't start, won't advance, or won't shut off
• Can correct intermittent operation, stalling mid-cycle, or erratic timing

What's included:

• 1 timer assembly

Install notes:

• Disconnect power; shut off gas supply on gas models before servicing
• Access the timer in the control console; remove the rear panel or console screws as required
• Photograph/label wiring and transfer wires one at a time to matching terminals on the new timer
• Mount the timer, transfer the original knob/dial if applicable, reassemble, and test cycle advance
