Jackie S Springfield , IL July 01, 2016 Appliance: Model KITCHENAID KGRS505XWH04 3 burner knobs would not turn frozen Ordered correct replacement parts (your online form helped to identify correct valves 2 had black dot on inside stem for back small burner 1 had red dot for larger front burner). locked stove, turned off gas, unplugged cord. removed knobs, 5 screws and front plate also removed L shaped plate below knobs for better access to comp. fittings. pulled off ignitior controls loosened compression fittings (hard to get wrench on nut but doable), removed screw holding valve to manifold. reversed order for new valves. Lit burners and sprayed soap solution on all joints to check for leaks. All good. Read More... 38 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Screwdrivers, Wrench Set
Peter R East Greenwich , RI December 18, 2015 Appliance: KitchenAid Gas Range KGRS505XSS02 Left front burner valve stuck (could not turn knob) Ordered replacement valve which was delivered quickly without expedited shipping. Make sure you order correct valve. There are three different valves with different BTU ratings which look identical and are interchangeable. Replacement valve is easy to install. Read More... 19 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
Sandie B Cornville , AZ May 24, 2015 Burner valve locked could nit turn burner on Removed front facing, turned off gas and power. Removed old valve and replaced with new top burner valve. Read More... 11 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Screwdrivers, Wrench Set
Dan N Eagle , IL December 02, 2014 Appliance: Model KITCHEN AID Burner was stuck in the "on " position thanksgiving meal prep and production became stressful when it was discovered that the shaft of the left front burner was stripped and would not turn Turned off gas to the stove before I learned about holding the start button for 5 seconds. This still did not kill AC power to the knob lock out switches. Yikes. Screw driver and a half inch wrench 15 minutes. I put silicone at live wire touchable spot. Easy Read More... 3 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers, Wrench Set
Ron R Bakersfield , CA March 29, 2019 2 of the burner gas valve stems were bent, one wouldn’t turn on the gas and the other one wouldn’t turn off the gas I replaced the two bad valves with new ones. Pay close attention to the color code on the old valve stems ( blue or black dots for the smaller burners and orange dots on the larger burners, different btu values & different part numbers) I unplugged the stove and turned off the gas then I removed the 6 screws holding on the panel covering the gas valves. Next I removed the electrical harness for the 2 bad valves by lifting up the plastic clasps and gently pulling it off both valves . Next I used a longer 1/2” open ended wrench to loosen the nuts holding the gas line to each bad valve and removed the lines. Next I removed the screw that held the valve to the manifold and removed the bad valves. Installed new valves in the reverse order, before putting the panel back on plug in the stove and turn on the gas & check gas connections on valves for leaks. Install the panel. Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers, Wrench Set
