Parts for Thermador SGCS304RB: 02 - Maintop Component Parts

The Grate Foot Kit is an OEM part for Bosch ranges. This kit includes the small rubber feet that attach to the bottom of the range grates, providing stability and preventing the grates from scratching the range surface.

Over time, the grate feet can wear out or become damaged due to exposure to high temperatures, regular cleaning, or accidental impact. Missing or worn-out feet can cause the grates to sit unevenly or scratch the range surface.

Symptoms of a bad grate foot kit include:

• The range grates sitting unevenly or wobbling
• Scratches or damage on the range surface
• Grates sliding or shifting during cooking
• Missing or visibly worn-out rubber feet

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

The Burner Cap is an OEM part for Bosch gas cooktops. This small black burner cap safely contains the flame underneath to concentrate heat efficiently for precise cooktop control. Reliable burner caps are crucial for safety, performance, and aesthetics.

Causes of a bad burner cap can include warping or cracking from continuous exposure to high heat over the long run, as well as surface scratching or punctures.

Symptoms of a faulty cap include:

• Flames escaping beyond cap and licking up sides of cookware
• Visible damage or deterioration on cap surfaces
• Inability to adjust flame height as intended
• Burners no longer heating or shutting off properly

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

The Burner Cap Assembly "C" Matte Blk is an OEM part for Bosch gas cooktops. As the rounded covering fitted over individual burners, it safely contains flames underneath cookware. Maintaining proper cap placement is vital for heating performance and safety compliance standards.

Causes of a bad burner cap assembly can include cracks or punctures from sustained high temperature cycling that compromise its insulating barrier. Over time, surface imperfections like scratches also diminish durability against consistent heat exposure.

Symptoms of faulty caps are:

• Flames improperly escaping from under pan edges
• Visible damage present on cap surfaces
• Inconsistent flame height adjustment or shut-off
• Excessive heat concentration in burnered area

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

This Venturi is an OEM part for Bosch Ranges. It plays a role in supplying air to the burner for proper combustion. Continuous exposure to heat and debris can cause this part to degrade or malfunction.

What Causes a Bad Venturi:
Exposure to heat and debris from cooking can cause the venturi to deteriorate over time. Blockages or clogs in the venturi can also affect its functionality.

Symptoms of a Bad Venturi:

• Uneven flame or inconsistent burner operation
• Reduced gas flow to the burner
• Burner flame discoloration

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

This burner base supports the cooktop's burner cap and directs flame for even heating. It replaces a damaged or warped base to restore stable burner alignment and consistent flame pattern. What it does:

• Holds the burner cap in place and centers the gas flame
• Channels gas flow for proper burner operation
• Helps prevent wobbling or uneven heating from a warped base
• Commonly replaced when the base is cracked, corroded, or bent

• One burner base (B)

• Turn off gas supply and power to the appliance before servicing
• Remove surrounding burner components and reassemble in reverse order
• Inspect nearby seals and burner ports for damage; replace if necessary

The Burner Gasket is an OEM part for Bosch cooktops and ranges. It provides a seal between the burner and the cooktop surface, preventing gas leaks and ensuring efficient operation.

Causes of a bad burner gasket can include wear and tear from frequent use, exposure to high temperatures, or damage from cleaning activities. Over time, the gasket may become brittle or develop cracks, compromising its sealing ability.

Symptoms of a bad burner gasket include:

• Gas odors near the cooktop
• The burner not igniting properly
• Visible cracks or deterioration in the gasket
• The burner not sitting securely in place

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

This burner base supports the cooktop burner assembly and helps position the burner cap for a consistent flame. Replace a damaged or warped base to restore proper burner alignment and reliable ignition. What it does

• Holds the burner head and cap in the correct position for even flame distribution.
• Stabilizes the burner assembly so the ignition electrode can spark reliably.
• Helps prevent burner cap wobble or misalignment that causes uneven heating.
• Can resolve symptoms like burners that light intermittently or produce an irregular flame pattern.

• One burner base.

• Disconnect power and shut off the gas supply before beginning service.
• Remove burner grates and caps; replace base using basic hand tools—do not force parts.
• Inspect surrounding gaskets and the ignition electrode for damage; clean any debris before reassembly.

The Gas Burner Seal is an OEM part for Bosch cooktops and ranges. This component sits between the burner and the cooktop surface, providing a seal that prevents gas leaks and ensures efficient burner operation. The seal helps maintain proper gas flow and supports the stability of the burner during cooking.

You should replace the gas burner seal if it becomes damaged or deteriorates. Over time, exposure to high temperatures, food spills, and regular cleaning can cause the seal to wear out or crack, leading to potential gas leaks and reduced burner efficiency.

Symptoms of a bad gas burner seal include:

• Visible cracks or damage to the seal
• Gas smell near the burner area
• Inefficient or uneven burner flames

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

This is a cooktop burner igniter OEM replacement part for Bosch cooktops and ranges and is sold as an individual part. This part creates a spark that ignites the burner within your cooktop or stovetop and is made of a combination of metal and ceramic.

Causes of a bad ignition plug can include issues with the electronic module, worn electrodes that no longer spark reliably, or damaged wiring.

Symptoms of a bad ignition plug include:

• Gas burners that will not light or remain lit
• Delayed ignition of one or more burners
• Intermittent or no sparking from the ignition plug

This OEM Bosch part is also compatible with Thermador, Gaggenau and some Kenmore models.

Position: Rear, for front order 00414781.

The Lens Red Pilot Long is an OEM part for Bosch gas ranges. It serves as the indicator within individual burner controls, signaling at a glance whether a burner is active. Reliable performance is important for user awareness and safety.

Causes can be prolonged bulb operation wear, shocks or impact stress, or thermal cycling taking its toll over years of use.

Symptoms of a faulty lens include:

• Lens lamp failing to illuminate when burner engaged
• Flickering or intermittent glow rather than steady light
• Visible cracks or damage compromising lens integrity

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

The Igniter Mounting Clip is an OEM part for Bosch ranges. It secures the igniter to the range top, ensuring it is properly aligned and stable for optimal ignition performance. The surface igniter is crucial for the ignition of gas burners, facilitating an immediate and safe flame to cook with.

Over time, the Igniter Mounting Clip can succumb to various forms of wear and tear, including corrosion from exposure to moisture, degradation from frequent heating cycles, or physical damage during cleaning or maintenance activities.

Symptoms of a compromised Igniter Mounting Clip include:

• The surface igniter becoming loose or dislodged
• Difficulty in igniting the burner or uneven flames
• Noisy or irregular ignition sounds
• Visible signs of damage or corrosion on the clip

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

Color: Black
