Parts for Gaggenau EB378-610: 03 - Door Parts

This inner door frame is the replacement structural frame that supports the dishwasher's inner door panel and secures internal door components for proper fit and operation. It restores correct door assembly where the inner frame is cracked, bent, or missing. What it does:

• Provides structural support for the inner door panel and mounting points for controls and hardware
• Keeps the inner door aligned so the latch and hinges engage reliably
• Helps prevent panel vibration and rattling during operation
• Addresses symptoms such as a loose or warped inner door panel, visible frame damage, or door alignment issues

• Disconnect power to the appliance at the breaker before starting work.
• Turn off the water supply and open the door fully; support the door while removing panels to avoid injury.
• Replacement typically requires removing the outer/inner door panels and transferring hardware; keep fasteners organized.
• Follow model-specific disassembly instructions or refer to a service manual.

This door hinge provides the pivot point that lets the appliance door open smoothly and close flush. Replacing a worn or bent hinge restores proper alignment and sealing for safe, reliable door operation.

• Provides the pivot point that guides door opening and closing
• Helps keep the door square to the cabinet for a consistent seal
• Wear or damage can cause sagging, binding, gaps, or a door that won't close flush
• Restores smooth movement and proper door alignment

• Disconnect power before servicing; also shut off gas or water
• Support the door during removal to prevent damage or injury
• Transfer any mounting screws/brackets from the old hinge to the new one
• After installation, verify door alignment and gasket contact; adjust as needed

This top door insulation piece cushions and thermally insulates the upper section of the appliance door to help maintain internal temperature and reduce noise. It's a simple replacement to restore proper door fit and performance. What it does:

• Replaces worn or damaged top door insulation to improve sealing and thermal retention
• Helps reduce vibration noise from the door assembly
• Restores correct door spacing to prevent rubbing or misalignment
• Supports overall efficiency by helping the door maintain its intended temperature barrier

• One top door insulation piece

• Disconnect power and remove water supply before starting
• Follow OEM disassembly steps for door panels to avoid bending or damaging trim and fasteners
• Inspect surrounding foam, clips, and gasket condition; replace any damaged hardware for a secure fit
• Reassemble carefully and test door operation before returning appliance to service
