Parts for Amana ACM1120AB: 03 - Interior Controls Parts

This baseless light bulb restores the washer drum light so you can clearly see inside during loading and unloading. Replace a failed lamp to regain visibility and help prevent small items from being missed. What it does:

• Illuminates the washer drum when the light feature is activated
• Replaces a burned-out or damaged baseless lamp in the drum light assembly
• Common symptoms: light won't turn on, flickers intermittently, or the bulb appears darkened/broken
• Helps you check for remaining items after a cycle

• Includes 1 baseless light bulb

• Disconnect power to the appliance before servicing
• Allow the old bulb to cool completely before handling
• Access the drum light housing; pull the old bulb's leads straight out and insert the new bulb's leads fully into the socket
• Avoid touching the glass; handle the new bulb with clean gloves or tissue, then restore power and test

This electrical safety fuse opens the circuit when a short or overcurrent occurs. Replacing a blown fuse can help restore power after the root cause is corrected, protecting controls and wiring from further damage.

• Protects the appliance by interrupting power during overcurrent or short-circuit events
• When open/blown, the appliance may be completely unresponsive
• Helps prevent damage to control boards and wiring during faults
• Often fails after a component shorts or a power surge occurs

• Disconnect power to the appliance before servicing
• Use a multimeter to test the fuse for continuity; replace only if open
• Install a fuse with the exact same rating and form factor as the original
• If the new fuse blows again, stop and diagnose the underlying fault; consider service for high-voltage systems

This propeller is the small impeller that mounts to the dishwasher circulation pump to move wash water through the spray arms for effective cleaning. Replacing a worn or damaged propeller restores proper water flow and wash performance. What it does:

• Spins on the pump shaft to circulate wash water through the spray arms
• Restores normal water flow when a cracked or stripped propeller reduces circulation
• Helps resolve symptoms such as poor cleaning, weak spray, or inconsistent water movement
• Works with the pump motor; does not include the motor or pump housing

• Disconnect power and water supply before beginning any repair
• Access the pump assembly from the dishwasher base or cabinet front per your model service instructions
• Inspect the pump shaft and seal for wear; replace damaged components to prevent repeat failure
• Reassemble carefully and test operation

This is a Whirlpool microwave magnetron. The microwave magnetron is one of the main components that control the heating function in the appliance. If a microwave has suddenly stopped heating but is still turning on normally, the problem could be the magnetron. Use a voltage tester to confirm whether this part is causing the problem. This component is made for installation in a microwave and oven combo where the microwave doubles as a vent hood. To replace this part, begin by unplugging the appliance and removing it from above the oven. Two people will be needed for this repair. This part requires exposure to highly sensitive electrical parts that could cause severe injury.This is a genuine OEM replacement part sourced directly from the manufacturer. This part is compatible with Whirlpool, Magic Chef, Amana, and Maytag appliances.

This replacement capacitor restores stable electrical timing and motor/run performance in compatible Whirlpool appliances. It helps the appliance start and run smoothly when the original capacitor has failed or weakened. What it does:

• Provides the stored charge needed for motor start/run circuits and control timing.
• Helps prevent motor hum, slow starts, or failure to start when the capacitor is failing.
• Reduces erratic cycling or intermittent operation caused by a weak capacitor.
• Supports reliable operation of blower, fan or small motor circuits that rely on a dedicated capacitor.

• Disconnect power to the appliance at the source before accessing electrical components.
• Capacitors can hold charge—discharge safely before touching terminals.
• Use insulated tools and avoid shorting terminals; verify correct fit and secure connections.

15 Amp, 125/250 Volt. Package of 2. Switches have 3/16 inch terminals.

The Screw is an OEM part for Whirlpool microwaves. It is responsible for securing various parts of the microwave together. This screw ensures a tight and secure fit for parts and helps maintain the structural integrity of the microwave, preventing any loose or rattling parts.

A bad microwave screw can occur due to wear and tear, accidental damage, or misplacement during maintenance or repairs. If you notice symptoms such as loose or wobbly components, difficulty in opening or closing the microwave door, or abnormal noises while the microwave is in use, it may be time to replace this part.

Symptoms of a bad microwave screw include:

• Loose or wobbly components
• Difficulty in opening or closing the microwave door
• Abnormal noises during operation

Restore your Whirlpool microwave by replacing the faulty or missing microwave screw with this genuine OEM part.

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.
