Parts for Thermador REF30: 18 - Rdds30v, Red30v Snorkel Assy Parts

Plastic endcap for range snorkel assembly. Installs on the top left side. Replace if cracked, broken, or missing to complete the snorkel appearance.

Black plastic endcap that covers the right side of the range snorkel vent. Replace if your original endcap is cracked, broken, or missing.

Black snorkel trim piece for range top. Replaces damaged, cracked, or missing decorative trim. Restores clean finished appearance to cooktop edge.

The knob bezel is the decorative trim ring that surrounds control knobs on the cooktop surface. Replace if the bezel is cracked, discolored, or missing, which can allow spills to enter the control mechanism underneath.

The Vent Control Button is an OEM component specifically designed for select Bosch downdraft ventilation ranges. Pressable from the countertop, its reliable switch operates the vent position. Precise guidance aligns ductwork airflows.

Symptoms of a faulty control button may include intermittent or unresponsive vent movement. Over-activation degrades contacts requiring change.

Causes of a bad button relate to typical contact wear reducing conductivity. Splashes introduce moisture necessitating replacement over time.

Causes of a bad vent control button involve:

• Vents remaining stuck open exposing grease-laden air
• Closed vents trapping cooking emissions near surfaces
• Failure to change vent direction as needed

This OEM Bosch part is also compatible with some Thermador, Dacor, and Viking downdraft ventilation ranges. Replace to maintain convenient vent management directing smoke and odors safely outdoors.


The Vent Switch is an OEM replacement part for Bosch range hoods. It is an electronic control device located inside the range hood that regulates the internal vent and fan functions.

Causes of a faulty vent switch can include long-term use in high-heat cooking environments, damage from accidental spills or impacts, or normal component degradation over time.

Symptoms include:

• Failure of the fan or vents to engage during cooking
• Variable or inconsistent fan speeds that don't adequately vent smoke
• Electrical shorting or sparking noises from within the hood control unit

This genuine Bosch replacement part is also compatible with Thermador, Gaggenau, and some Kenmore range hood models.

Black control knob for electric ranges and cooktops. Replaces cracked, broken, or missing knobs. Installs on burner control dial stem for precise heat adjustment.

Captures grease and cooking vapors to keep air fresh and prevent buildup. Replace when clogged or discolored. Verify fit by model number and dimensions.

This is a control panel that mounts on the front of the range, providing the surface where controls and indicators are housed. It serves as both a structural and cosmetic component that protects internal wiring and electronics. Replace this panel if it is cracked, warped, damaged by heat, or if mounting points are broken.

This upper snorkel limit switch detects the snorkel assembly position and signals the dishwasher control so cycles run correctly. Replacing a faulty switch restores reliable control of the snorkel mechanism and helps prevent cycle interruptions. What it does:

• Senses the upper snorkel position and sends a signal to the appliance control
• Helps prevent overfill or incorrect snorkel operation when working properly
• Faulty switch can cause cycle interruption, failure to advance, or snorkel-related errors
• Works as the control-point for the snorkel mechanism that affects water handling

• Disconnect power to the appliance before beginning any repair
• Turn off and/or disconnect water supply if required for access
• Remove access panels or trim as needed to reach snorkel assembly; handle clips and connectors carefully
• Test electrical connections and proper operation after installation
