Parts for Thermador REF30: 04 - Sequence Manifold Assembly Parts

Used to hold down the jet holder assembly.

This tubing assembly routes water inside the appliance to maintain proper flow and sealing where factory tubing is required. It replaces damaged or leaking tubing to restore normal water routing and prevent leaks. What it does:

• Replaces worn, cracked, or pinched tubing that can cause leaks or reduced water flow
• Restores proper internal water routing to dispensers/valves or drain lines
• Helps stop visible water on the floor or pooling near appliance bases
• Maintains secure connections where the original tubing was installed

• Turn off power to the appliance and shut off the water supply before servicing
• Inspect connection fittings and clamps; replace any damaged clips or seals
• Avoid sharp bends or kinks when routing the tubing; secure with existing brackets

This tubing assembly routes water inside the refrigerator to the dispenser/ice system, restoring a sealed water path and reliable flow. Use it to replace cracked, kinked, or leaking tubing for better water delivery. What it does:

• Carries water from the inlet to the dispenser/ice components to enable ice and water dispensing
• Stops leaks and seepage caused by cracked or damaged tubing
• Restores proper water routing when bends or kinks restrict flow

• Tubing assembly

• Turn off the refrigerator and shut off the water supply before starting work
• Drain any remaining water from lines and have a towel/container ready for spills
• Inspect connections and use new fittings or seals if the old ones are damaged

The Gas Valve Cooktop is an OEM part for Bosch cooktops. This valve is responsible for controlling the flow of gas to the burners on the cooktop. It opens and closes to allow gas to pass through when a burner is turned on and stops the flow of gas when the burner is turned off.

Causes of a bad gas valve can include wear and tear over time, issues with the valve mechanism such as stuck or blocked components, or damage from exposure to moisture or impact.

Symptoms of a bad gas valve include:

• Burners not lighting or sparking repeatedly without igniting
• Uneven or unpredictable burner flame heights
• Burners not getting hot enough for cooking
• Burners that cannot be turned on or off
• Gas leaks around the valve area

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore cooktop models.


This gas burner jet holder assembly routes fuel through the orifice to the burner and secures the connection. The red 11,000 BTU version is designated for the right-front or left-rear burner, helping restore proper flame and heat output.

• Positions the jet and routes gas from the manifold to the burner for the specified heat output
• 11,000 BTU, red-coded variant designated for RF/LR burner location
• Provides a stable, serviceable connection between tubing and burner base for a consistent flame
• Symptoms include weak or irregular flame, failure to ignite, or incorrect flame size at the RF/LR burner

• Shut off gas supply and power; allow the appliance to cool before servicing
• Remove grates, burner caps/heads, and any panels needed to access the holder
• Support gas tubing and use two wrenches on fittings to avoid twisting or damage during removal/installation
• After installation, check all joints with an approved leak-detecting solution and verify flame quality

The Jet Holder with Nut is an OEM part for Bosch ranges and cooktops. It holds precisely machined jets that control gas flow from each burner valve.

Causes may be wear and deterioration from prolonged heating exposure. Physical impacts or damage accumulation over time could also compromise the jet holder.

Symptoms of a bad jet holder can include:

• Inability to adjust or maintain proper flame stability and heat output
• Irregular or uneven flame patterns between surface burners
• Potential gas leaks observed at jet connections

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

This is a redesigned kit. It is strongly recommended to have a certified Thermador technician install this kit as some modifications may be necessary.

The Spark Switch is an OEM part for Bosch ranges. This part ignites the burners by sending a signal to the spark module, which then produces the spark needed to ignite the gas.

Causes of a bad spark switch can include wear and tear from regular use, damage from spills or cleaning agents, or electrical issues.

Symptoms of a bad spark switch include:

• Burners not igniting
  Continuous clicking even after the knob is turned off
  No spark when attempting to ignite the burner
  The cooktop not producing a flame

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.
