Parts for Thermador PRG366US: 22 - Bottom Frame Parts

This orifice is the small, calibrated gas jet used in the oven burner to control natural gas flow for proper combustion and consistent heat. It replaces a worn or clogged orifice to help restore reliable oven ignition and baking performance. What it does:

• Directs and meters natural gas to the oven burner for correct flame size and stability
• Helps resolve symptoms like weak or uneven burners, weak ignition, or yellow/sooting flames when caused by a restricted orifice
• Used on the oven top/burner assembly where a #38 sized jet is specified
• Fits into the burner orifice holder and works with the existing regulator and valve

• Install only after shutting off the gas supply and following all safety procedures; check for leaks with a soapy water solution or approved leak detector
• Use correct tools and avoid damaging the orifice tip; thread carefully to prevent cross-threading
• Do not modify the orifice; replace with the exact specified size to maintain safe operation

The Oven Burner Igniter is an OEM part for Bosch ranges. This part ignites the gas burner to provide the necessary heat for cooking. The igniter works by heating up and creating a spark that ignites the gas, ensuring efficient and reliable operation of the oven.

Causes of a bad igniter can include regular wear and tear, damage from repeated heating cycles, or issues with the electrical connections.

Symptoms of a bad igniter include:

• The oven not heating up
• Difficulty igniting the burner
• The burner not staying lit
• Unusual clicking or sparking noises during ignition

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

Support, hinge counter restores proper hinge support and door balance for a worn or damaged hinge assembly. This replacement helps the appliance door open and close smoothly and stay aligned for reliable everyday use. What it does:

• Provides structural support to the door hinge and helps counterbalance the door
• Stabilizes hinge movement to reduce sagging, binding, or uneven closing
• Helps the door latch and seal correctly by keeping the hinge alignment consistent
• Use when you notice door droop, difficulty latching, or irregular door motion

• Installation may require partial disassembly of the door or hinge assembly—refer to the OEM instructions for your model
• Disconnect power and turn off water supply before beginning any repair
• Inspect surrounding hinge components and fasteners; replace any damaged parts and test door operation after installation

This metal angle flue guard protects and covers the flue opening on compatible gas ranges, helping direct exhaust and keeping nearby components shielded from heat. It restores the range's original flue trim and helps maintain safe operation. What it does:

• Replaces a bent, cracked or missing flue guard that no longer shields the flue opening
• Directs heat and combustion byproducts away from surrounding panels and components
• Helps reduce hot spots and contact with wiring or insulation near the flue area
• Restores proper fit and appearance of the cooktop/flue assembly

• One angle flue guard

• Turn off and disconnect power and gas supply before starting any repair
• Remove cooktop or access panels as required to reach the flue; retain original fasteners unless new ones are supplied
• Handle edges carefully; metal trim may be sharp

This glow igniter heats electrically to light the appliance's gas burner. A weak or failed igniter can stop ignition or cause very long preheat times; replacing it restores reliable burner lighting and proper heating performance.

• Heats to a bright glow to ignite the gas burner
• Common fix for oven not heating or burner not lighting
• Often resolves long preheat times or intermittent ignition
• If the igniter doesn't glow—or glows but no flame appears—it may be weak or failed

• Disconnect power and shut off gas before servicing; allow the unit to cool completely
• Handle the ceramic element carefully; avoid touching the igniter surface and do not flex, drop, or strike it
• Transfer any reusable mounting hardware and wiring/connectors from the old part as needed
• Verify secure connections and proper positioning near the burner before restoring power and gas
