Parts for Frigidaire CGES3045KW2: 03 - Backguard Parts

This electronic control board manages a refrigerator's main functions and restores reliable cooling, defrost cycles and user controls. It replaces a failed main controller to correct related electrical control issues. What it does:

• Regulates compressor and fan operation to maintain proper temperatures — symptoms: fridge not cooling, runs continuously, or temperatures fluctuate.
• Controls automatic defrost timing and heater operation — symptoms: excessive frost buildup or thawed/icy evaporator.
• Manages display, touchpad and dispenser signals — symptoms: unresponsive controls, blank display, or incorrect readouts.
• Coordinates inputs from sensors and relays to sequence cooling and defrost cycles — symptoms: intermittent cooling or no compressor start.

• Disconnect power to the appliance before starting any repair to avoid shock or damage.
• Boards can be static-sensitive; ground yourself and handle by edges to prevent ESD damage.
• Retain or transfer any mounting hardware, brackets, or wiring harnesses from the original board as needed.

This replacement switch restores dependable on/off control for the appliance function it serves. Replacing a worn or heat-damaged switch helps eliminate intermittent operation and ensures the selected feature powers correctly and safely. What it does:

• Opens and closes the electrical circuit to the assigned component when actuated
• Can resolve issues where a feature will not turn on or will not shut off
• Helps correct intermittent operation caused by worn or pitted contacts
• Addresses damage such as melting, arcing, discoloration, or a loose/"spongy" feel

• 1 switch

• Disconnect power at the breaker before servicing to avoid electrical shock
• Note or photograph wire positions; transfer leads one-for-one to the new switch
• Ensure terminals are fully seated; do not force or stretch connectors
• Inspect wiring for heat damage and correct loose connections before reassembly

This electrical microswitch opens or closes a circuit when its actuator is engaged, allowing the control to sense position or enable a function. Replacing a worn switch restores reliable signaling and prevents intermittent faults in select ranges and wall ovens. What it does

• Changes state (open/closed) when actuated to complete or break a circuit
• Sends feedback to the control or enables power to a related component
• Helps ensure operations start/stop only when the mechanism is in the correct position
• Failure signs can include intermittent operation, cycles that won't start or finish, or related error codes/alarms

• 1 switch

• Disconnect power at the breaker before servicing
• Note/photograph wire positions and transfer one at a time to the new switch
• Match actuator orientation to the original and secure the switch firmly
• Verify function with a multimeter (continuity changes when actuated) before reassembly and testing

The Range Switch is an OEM part for Frigidaire ranges. This switch controls the power supply to the range elements, allowing you to adjust the heat levels for cooking.

Causes of a bad Range Switch can include wear and tear from regular use, electrical issues such as short circuits or faulty wiring, or damage due to spills or overheating. These issues can result in the switch failing to regulate the power to the elements properly.

Symptoms of a bad Range Switch include:

• Inability to adjust the heat level
• The element not turning on or off
• Intermittent or inconsistent heating
• A burnt smell or visible damage on the switch

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

This replacement screw secures appliance panels, brackets, and internal components. It restores a tight, rattle-free fit and proper alignment when an original fastener is missing, stripped, or corroded.

• Fastens metal or plastic parts to the cabinet/frame
• Helps maintain alignment and reduce vibration or rattling
• Direct replacement for lost, damaged, or rusted hardware
• Keeps covers and brackets safely in place

• Disconnect power before servicing; for gas appliances, also shut off gas supply
• Match one-for-one with the original screw; verify length/type before installation
• Start threads by hand to avoid cross-threading; tighten snugly without overtightening
• Use the correct driver bit to prevent stripping the screw head
