Parts for Frigidaire FED300DSA: 03 - Backguard Parts

This interior refrigerator light assembly provides replacement illumination for the fresh food compartment, restoring visibility when the door opens. Designed to match the original fit and function for a direct swap. What it does:

• Replaces a burned-out, dim, or flickering interior light to restore proper compartment lighting
• Houses the bulb and lens to direct light into the refrigerator cavity
• Ensures the door switch/lighting circuit can illuminate the compartment when closed/opened
• Helps you see food clearly and check contents without guessing

• Disconnect power or unplug the appliance before service to avoid shock
• Use a non-abrasive cloth to clean surrounding area; avoid touching bulb with bare hands if replacing bulb
• Remove the old assembly by releasing the lens/fasteners and disconnecting the wiring harness; reverse steps to install
• If light still does not work after installation, check the door switch and bulb and power to the unit

Restore reliable timekeeping and timed-cycle control with this Clock/Timer Kit. It replaces a failed clock/timer so you can set the time, run countdowns, and receive alerts as designed by the manufacturer. What it does

• Displays and keeps the appliance's current time
• Controls kitchen timer/countdown functions and audible alerts
• Interfaces with the appliance to manage timed cycles (start/stop)
• Helps resolve issues like blank or dim display, timer not advancing, drifting time, or unresponsive keys/knob

• 1 clock/timer kit assembly

• Disconnect power at the breaker before servicing; verify no voltage is present
• Access the control area; note screw locations and panel orientation
• Label or photograph wire locations; transfer connections one at a time to the new unit
• Mount securely, reassemble, restore power, and set the clock before testing timer functions

The Switch Rocker is an OEM part for Frigidaire ranges. This switch is used to control various functions of the range, such as turning on heating elements or activating specific cooking modes. It provides a reliable and straightforward interface for managing the range's features.

You should replace the range switch rocker if it becomes faulty. Causes of a bad switch rocker can include wear and tear from frequent use, exposure to high temperatures, electrical malfunctions, or physical damage from impacts or mishandling. A defective switch rocker can result in unresponsive controls, making it challenging to operate the range effectively.

Symptoms of a bad Range Switch Rocker include:

• The switch not responding when pressed
• Inconsistent or flickering performance of the heating elements
• Physical damage or looseness in the switch
• Intermittent operation or complete failure to activate the desired function

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

This control knob replaces a worn, cracked, or missing range/oven control knob to restore safe, precise selection of heat and function settings. It gives a secure grip and a clear tactile stop for common range controls. What it does:

• Fits onto the range/oven control shaft to select temperature or function settings
• Provides a positive grip and stop so settings stay where you set them
• Replaces broken, stripped, cracked, or missing knobs that won't turn or won't stay set
• Helps restore proper user control for burner or oven functions

• Always disconnect power (unplug or shut off breaker) and shut off gas supply before servicing
• Pull the old knob straight off the control shaft; align and push the replacement knob onto the shaft until fully seated
• Don't force the knob; if it won't seat, inspect the control shaft and the knob opening for debris or damage

This truss-head machine screw secures a switch to its mounting bracket or panel. Replacing a worn or missing screw restores a solid, aligned switch fit for reliable operation.

• Fastens the switch body to a bracket or chassis panel
• Helps keep the switch aligned for consistent actuation
• Replaces stripped, corroded, or missing mounting hardware
• Common symptoms: loose or wobbly switch, misalignment, rattling or vibration around the switch area

• Disconnect power to the appliance before servicing
• Start threads by hand to avoid cross-threading; tighten snugly without overtightening
• Verify thread size and length match the original hardware
• If multiple screws secure the switch, replace them in a consistent pattern to maintain alignment

This is a replacement refrigerator door gasket that restores the seal around the door to help maintain proper temperature and efficiency. It's a direct-fit sealing strip designed to replace a worn, torn, or deformed door seal. What it does:

• Seals the gap between the door and cabinet to help keep cold air in and warm air out
• Helps reduce frost buildup and prevents moisture and leaks around the door
• Restores consistent internal temperature for better food preservation
• Reduces compressor run time caused by an improper door seal

• One refrigerator door gasket

• Recommended: replace gasket on a clean, dry door surface; remove old gasket and adhesive residue before installing
• Use the manufacturer's recommended attachment method (snap-in or adhesive) for your model
• Inspect hinge alignment and door fit before finalizing gasket installation to ensure an even seal
• For safety, unplug the appliance or disconnect power before beginning repairs

This is a #8 screw, 0.500 inch long, used to secure panels and components in appliances. It provides a correct-fit fastener for repairs where the original #8 x 1/2" screw was required, restoring proper assembly and stability. What it does:

• Fastens trim, panels, brackets and small components where a #8 x 1/2" screw is specified
• Holds parts securely to prevent rattling, gaps or loose panels
• Replaces worn, stripped or missing screws to restore proper fit
• Appropriate for common interior and exterior appliance mounting points

• Use the correct screwdriver (typically Phillips) and avoid over-tightening to prevent strip or damage
• Disconnect power and follow appliance manufacturer safety instructions when accessing internal parts

The Overlay is an OEM part for Frigidaire ranges. This component is the interface layer that sits over the control panel, providing labels and markings for the various buttons and controls. It ensures that users can easily identify and operate the range settings.

You should replace the overlay if it becomes damaged or worn out. Causes of a bad overlay can include exposure to high temperatures, frequent cleaning, or general wear and tear, which can cause the labels to fade or peel off.

Symptoms of a bad overlay include:

• Fading or illegible labels
• Peeling or bubbling of the overlay surface
• Difficulty in reading and using the controls accurately
• Physical damage such as cracks or tears

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.
