Parts for Ge AJCQ08ACGL1: Base Pan & Unit Parts

This discharge tube routes condensate and defrost water from the refrigerator/freezer evaporator to the drain pan, helping prevent leaks and puddling under the appliance. installs as a direct replacement for the factory tube. What it does

• Channels defrost/condensate water away from the evaporator to the drain pan.
• Helps prevent water pooling or dripping inside or beneath the cabinet.
• Can reduce ice buildup around the evaporator area when functioning properly.
• Works with refrigerator drain system components to maintain normal defrost drainage.

• Disconnect power to the appliance before beginning any work.
• Remove food and shelves as needed for safe access; support doors/panels while removing fasteners.
• Inspect and replace any clamps or grommets if damaged; ensure tube seats securely in drain fittings.
• After installation, restore power and run a short test (advance defrost or pour small amount of water into evaporator drain) to confirm proper routing and no leaks.
