Parts for Frigidaire FCS367CHBD: 04 - Body Parts

This replacement drawer body restores a smooth-sliding storage bin in your appliance. Integrated rollers let the drawer glide on its tracks, keeping items organized and easy to access when the original is cracked, warped, or difficult to open.

• Forms the storage bin and supports items within the compartment
• Built-in rollers enable smooth travel along the drawer rails/tracks
• Helps resolve sticking, popping off track, rough movement, or broken tabs
• Restores proper fit and slide action for everyday use

• Empty and remove the damaged drawer; transfer any reusable front trim or inserts from the old drawer if needed
• Clean and inspect the rails/tracks; align the rollers with the track openings and slide in level until fully seated
• Do not force the drawer—re-align if resistance is felt to avoid damaging tabs or rails
• Avoid lubricants; wipe tracks and rollers with mild soap and water only

This replacement drawer liner restores a clean, smooth surface inside the refrigerator drawer to protect stored items and make cleaning easier. It's a direct-fit internal liner used where a damaged or stained liner needs replacing. What it does

• Provides a smooth, protective surface for a refrigerator drawer to contain spills and prevent direct contact with the drawer bottom
• Helps drawers slide and seat correctly when the original liner is warped, cracked, or missing
• Makes routine cleaning easier—wipes clean with mild soap and water
• Restores interior appearance when the factory liner is stained or damaged

• One drawer liner

• Remove the drawer from the cabinet per the owner's manual before replacing the liner
• Typically drops or snaps into the drawer cavity; no special tools required for most installs
• Clean both liner and drawer opening with mild detergent and dry before installation

This is a medium burner pan that is used with ranges and stoves. The burner pan is located under the heating unit to catch any drips and spills. This prevents the drips from reaching the internal components of the stove where they could cause additional damage. Over time, the burner pan can be overly soiled and damaged and may need to be replaced. The process of replacing the medium burner pan takes only a few minutes. The first step is to unplug the stove or range. Next, the elements on the cooktop need to be lifted to access the parts underneath. The burner pan will be found in one of the cavities under the burners. These can be removed by hand and set aside. When replacing the burner pan, make sure the hole on the side is oriented to fit the terminals. Plug the elements back in and plug in the stove.The medium burner pan is made for use with ovens, ranges, and stoves manufactured by Kenmore and Frigidaire. It is sold as an individual product. This is an authentic OEM replacement part that is sourced directly from the manufacturer.

Color: Black.

The Cap-Burner is an OEM replacement part for Frigidaire cooktops and ranges. It is a crucial component that covers and protects the gas burner assembly, while also distributing the flame evenly for optimal cooking performance.

Symptoms of a bad Cap-Burner:

• Uneven or irregular flame patterns
• Difficulty in igniting or maintaining a steady flame
• Discoloration or warping of the cap due to excessive heat exposure
• Clogged or obstructed gas flow, leading to poor burner performance

Causes of a defective Cap-Burner can include prolonged exposure to high temperatures, impact damage, or general wear and tear over time.

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore cooktops and ranges.

This door gasket seals the refrigerator door to help keep cold air in and warm, humid air out—reducing frost build-up and helping the appliance run more efficiently. Fits where a full perimeter door seal is required. What it does:

• Creates an airtight seal around the refrigerator door to maintain consistent internal temperatures.
• Helps prevent warm air infiltration, moisture, and frost accumulation inside the compartment.
• Reduces energy waste caused by a failing or damaged door seal.
• Common symptoms of a bad seal: condensation at the door, frost on shelves, fluctuating temperatures, or higher energy use.

• Disconnect power to the appliance before attempting any service.
• Remove the old gasket carefully; replacement typically seats into the door channel around the full perimeter.
• Inspect and, if needed, adjust door alignment and hinge condition to ensure a proper seal.

This is a 10-24 x 1/2 inch machine screw used to secure temperature probes, thermistor brackets, shields and drawer/box components. It provides a simple, reliable fastener for small appliance assemblies. What it does:

• Secures probe or thermistor brackets to the appliance chassis or housing
• Holds shielding or small drawer/box parts in place to prevent movement or rattling
• Helps maintain correct sensor positioning so temperature readings stay stable
• Common replacement when a stripped, corroded, or missing screw causes loose parts or vibration

• One 10-24 x 1/2 in. screw

• Use the matching 10-24 threaded hole; avoid over-tightening to prevent stripping or cracking nearby plastic
• If replacing a corroded screw, inspect mating threads and components for damage before reuse
• Turn off and unplug the appliance or disconnect power before accessing internal components

This replacement 10-24 x 3/8 machine screw secures panels, brackets, and small components in compatible Frigidaire appliances. It restores proper fastening where a missing or damaged screw allows parts to shift or rattle. What it does:

• Fastens metal or plastic appliance parts such as trim, brackets, or small assemblies
• Helps eliminate movement, rattling, or loose connections caused by missing or stripped screws
• Restores safe, secure mounting for controls and hardware
• Matches OEM size for proper fit in designated threaded holes

• Disconnect power to the appliance before servicing to avoid shock or injury
• Use the correct screwdriver or nut driver to avoid stripping the head
• Start threads by hand to ensure alignment; tighten until snug — do not over-tighten
• Replace any stripped mating hardware or use correct thread engagement for secure fit

This is a #8 screw, 0.500 inch long, used to secure panels and components in appliances. It provides a correct-fit fastener for repairs where the original #8 x 1/2" screw was required, restoring proper assembly and stability. What it does:

• Fastens trim, panels, brackets and small components where a #8 x 1/2" screw is specified
• Holds parts securely to prevent rattling, gaps or loose panels
• Replaces worn, stripped or missing screws to restore proper fit
• Appropriate for common interior and exterior appliance mounting points

• Use the correct screwdriver (typically Phillips) and avoid over-tightening to prevent strip or damage
• Disconnect power and follow appliance manufacturer safety instructions when accessing internal parts

Specs: 8 - 18 x 0.500

This is a replacement screw used to secure appliance panels and components. It restores proper fastening so panels, trim, or assemblies stay tight and reduce vibration or rattling. What it does

• Fastens panels, brackets, or trim to the appliance chassis
• Helps stop loose or vibrating panels and trim pieces
• Restores proper alignment where a missing or stripped screw causes gaps or movement
• Use when the original screw is missing, damaged, or corroded

• One replacement screw as shown

• Disconnect power to the appliance before starting any repair
• Use the correct screwdriver or bit to avoid stripping the screw head
• Tighten until snug; avoid over-torquing which can strip threads or crack plastic
• Keep removed screws in a safe place; this screw matches the original before installation
