Bosch 00705174 Pump And Motor Assembly OEM Part

Ordered replacement pump and installed it.Pump was exact replacement part.Fit & worked perfectly

Replaced the pump. Found ground wire not hooked up on dishwasher. Fixed that then replaced the pump. Little bit of work getting it out but got it done. Dishwasher runs good now.

Replaced circulation Pump & Motor Assembly and works great now.

Had to pull it out from the cabinet, flip on its side (expect water on the floor). Old part came off and new part went on easily. Pulling and reinstalling the dishwasher is harder than replacing this part. The old part did have the single use clamp mentioned in the video, but I was able to cut through it with some large wire cutters. (Not small ones - this thing is thick.) Now washing better than it was before the pump broke. For anyone who needs it: My old pump had a catastrophic failure between head and rotor shaft, nothing wrong with the motor itself - the whole plastic part just broke. Resistance across any two of the three wires into the motor was about 12-14 ohms in both the old and new pump.

Purchased & installed reed switch (water meter) & heat pump. I used the video as a reference which helped quite a bit, but it still took a while. Most importantly the parts fit, the error codes disappeared, and the dishwasher works again.
