Parts for Whirlpool WGT3300XQ1: 15 - Burner Assembly Parts

Left valve coil that powers the solenoid on a water inlet/valve assembly to control water flow. Replacing a worn or burnt coil helps restore proper valve operation so the dispenser or ice maker can fill when called. What it does:

• Energizes the left solenoid on the inlet/valve assembly to open and close the valve when the appliance requests water.
• Used when a coil is damaged, burnt, or not producing the magnetic field needed to actuate the valve.
• Common symptoms: no water to dispenser or ice maker, weak or intermittent flow, humming or buzzing from the valve, or visible burn/discoloration on the coil.
• Matches the OEM function for the left-side solenoid.

• Disconnect power and shut off the water supply before servicing the valve assembly.
• Note wiring and coil orientation before removal so the replacement installs in the same position.
• Handle the valve plunger and seating components carefully; do not contaminate valve seals or passages.
• If wiring terminals are corroded or damaged, replace connectors.

This pipe plug seals an unused or service opening in a household appliance's plumbing to stop leaks and prevent debris entry. It restores a watertight closure so the appliance can operate safely and without water loss. What it does:

• Plugs open pipe or hose fittings to prevent water leaks
• Helps maintain proper water flow by sealing unused ports
• Keeps debris and contaminants out of the plumbing system
• Can stop intermittent drips originating from service openings

• One pipe plug

• Turn off water supply and power to the appliance before starting work
• Hand-start threads to avoid cross-threading; tighten only to OEM torque or finger-tight plus a quarter-turn if unspecified
• If the original used sealant or gasket, replace with the same type per OEM instructions

This 8-18 x 5/8-inch screw secures appliance panels, brackets, and covers. Replacing a missing or stripped fastener restores a tight fit and helps prevent vibration or loosening where this exact size is specified.

• Fastens sheet-metal or plastic components where a #8-18 x 5/8 screw is called for
• Helps maintain alignment and reduce rattling or vibration
• Replaces stripped, corroded, or missing screws of the same size
• Common symptoms: loose panels, gaps/poor fit, rattling noises, or visible missing hardware

• Disconnect power and shut off gas/water (as applicable) before service
• Match thread and length to the original; replace screws one at a time to keep parts aligned
• Start threads by hand to avoid cross-threading; tighten snugly without overtightening
• If the receiving threads are damaged, additional repair (clip, insert, or new nut) may be needed

The Igniter Kit and Bracket is an OEM replacement part for Whirlpool dryers. It is a kit that includes the igniter and bracket assembly, which work together to ignite the gas or electric heating element.

Causes of a bad igniter and bracket can include failure due to prolonged or repeated use, damage from impact or mishandling, or failure of integrated electronic components.

Symptoms of a bad igniter and bracket include:

• The dryer not heating or heating intermittently
• Repeated trips of the thermal fuse
• Smell of gas indicating improper ignition
• Visible damage or cracks in the igniter or bracket

This Whirlpool replacement part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and some Kenmore models.

This replacement mounting screw secures appliance panels and small components to restore proper fit and reduce movement. It's a simple, direct part for repairing loose panels, trim, or interior assemblies. What it does:

• Fastens panels, brackets, or assemblies to prevent rattling and vibration
• Restores proper alignment for doors, control panels, or trim pieces
• Helps stop intermittent noise caused by loose hardware
• Use when original screw is missing, stripped, or corroded

• Disconnect power and unplug the appliance before beginning any repair
• Use the correct screwdriver bit and hand-tighten; avoid over-torquing which can strip threads
• Keep small parts away from children and pets; magnetic tray helps prevent loss
• If multiple screws are corroded or hardware threads are damaged, inspect mating parts and replace as needed

The Flame Sensor is an OEM replacement part for Whirlpool gas dryers. This component plays a critical safety role by monitoring the presence of the gas burner flame during the drying cycle.

Causes of needing to replace the flame sensor can include normal wear and tear over extended use, exposure to high temperatures or corrosion, or physical damage to the sensor itself.

Symptoms that may indicate a faulty flame sensor include:

• The dryer not heating or producing heat properly
• Error codes related to the gas system or ignition failure
• The dryer shutting off unexpectedly during cycles

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore gas dryer models.

This part has been discontinued and is no longer available.

This LP gas conversion label identifies that the appliance has been converted for use with liquid propane. Applying it near the gas valve/regulator clearly communicates fuel type for safe service, troubleshooting, and future installation decisions.

• Marks a converted unit as LP fuel to prevent misdiagnosis or incorrect hookups
• Provides quick visual identification for technicians and inspectors
• Replaces a missing, damaged, or illegible conversion label
• Use when a conversion has been completed and the original label is not present

• Apply only after completing the correct LP conversion procedure for your specific model
• Clean and dry the mounting surface; place the label where specified (typically near the gas valve/regulator or rating plate)
• Do not cover existing safety or rating labels; press firmly to ensure full adhesion
• Leak-check all fittings before returning the appliance to service
