Parts for Maytag JED8430BDF18: 03 - Burner Box Assembly Parts

The fan control switch is the panel-mounted switch that sends power to the appliance's fan motor. Replacing a worn switch restores reliable on/off control and proper airflow so the fan starts and stops when it should.

• Provides user-operated on/off power to the fan/blower motor
• Helps regulate airflow for cooling, venting, or convection depending on model
• Typical symptoms: fan won't run, runs continuously, intermittent operation, or a loose/broken switch shaft
• Mounts behind the control panel and is actuated by the exterior knob/lever

• Disconnect power at the breaker before servicing
• Remove the control knob/actuator and panel trim to access the switch
• Note wire positions or take a photo; transfer wires one at a time to the new switch
• Secure with the original hardware, restore power, and test operation

This dual infinite switch controls power to a dual-size surface element on your range or cooktop, restoring smooth, accurate heat adjustment. Replace a failed switch to regain proper temperature control and dual-ring operation.

• Regulates cycling power to the inner and outer circuits of a dual surface element
• Provides variable heat levels from low to high
• Common symptoms of a failed switch: element won't heat, only heats on high, can't adjust temperature, element won't shut off, inner or outer ring won't activate
• Restores reliable response when selecting single-ring or dual-ring settings

• Disconnect power at the breaker before servicing
• Remove the control/console panel to access the switch
• Photograph/label wiring and transfer leads one at a time to matching terminal markings on the new switch
• Reassemble, reinstall the knob, and test both single-ring and dual-ring operations

This infinite switch controls the power level to an electric surface element, letting you adjust burner heat smoothly from low to high for consistent cooking performance.

• Regulates power cycling to the surface element to maintain set heat
• Replaces a failed control that leaves a burner stuck on high or won't heat
• Helps resolve issues like no heat, uneven or erratic heating, or a burner that won't shut off
• Restores precise temperature control to the affected cooktop burner

• Disconnect power to the range before servicing
• Note wire locations or take a photo before removing the old switch
• Transfer knob and mounting hardware from the original if required
• After installation, restore power and test burner operation through the full heat range

This knob sleeve secures a control knob to the control shaft, restoring proper knob alignment and smooth operation so settings stay where you set them. What it does:

• Centers and stabilizes the control knob on the shaft
• Prevents knob wobble, slipping, or uneven rotation
• Helps maintain reliable control selection for temperature/settings
• Common symptom: loose, tilted, or spinning knob

• Disconnect power to the appliance before servicing for safety
• Remove the control knob to access the sleeve; installation typically slides into place on the control shaft
• Reinstall the knob and test function before restoring normal use

A 6" replacement surface heating element for electric ranges and cooktops that restores heat to a single burner. Use this element to replace a damaged or non-heating coil and get your cooktop back to proper cooking performance. What it does:

• Heats cookware when the burner control is turned on; functions as the cooktop's primary heat source for one 6" burner.
• Replaces elements that are broken, visibly damaged, not heating, or heating unevenly.
• Re-establishes proper electrical contact at the burner connection when the element is correctly seated.
• Works with manual and infinite-switch style burner controls.

• One (1) 6" surface heating element.

• Disconnect power to the range at the circuit breaker before beginning any work.
• Allow the cooktop and element to cool completely; remove the old element by lifting and unplugging from the terminal block or unsnapping from the receptacle.
• Inspect the element receptacle/terminal for damage and replace the receptacle if loose or corroded.
• Seat the new element fully in the receptacle and test operation with power restored; do not operate without cookware or with damaged wiring.

This dual-ring surface heating element replaces a faulty top burner to restore flexible cooking power and even heat across the cooking zone. It fits compatible Whirlpool-range cooktops and provides inner and outer heating rings for varied pan sizes. What it does:

• Replaces a damaged or non-heating top burner element so the cooktop can heat again.
• Restores both inner and outer heating zones when one or both rings have failed.
• Helps resolve symptoms such as no heat from the burner, weak heating, or uneven cooking.
• Matches the OEM element design for direct-fit replacement on supported ranges.

• One dual-ring surface heating element (single assembly)

• Disconnect power to the appliance before attempting any service to avoid electrical shock.
• Allow the cooktop to cool completely before touching the element.
• Basic removal typically involves lifting the cooktop or opening the cooktop rim.
