This part is discontinued by the manufacturer and is no longer available for purchase.
Fix burners that won't spark or click constantly. This igniter switch wiring harness restores reliable lighting on gas ranges. DIY-friendly repair.
Gas burners won't ignite? A faulty spark module may be the issue. This part sends electrical current to igniters. DIY-friendly, takes minutes.
This burner head is used on gas ranges to provide the cooking heat. The burner head is attached to the burner tube assembly that supplies the gas. When the burner is ignited, the holes in the burner head produce the flame that is used for cooking. Over time, food spills and normal corrosion may cause the holes in the burner head to become clogged or damaged. If this occurs, food will not cook evenly, or the burner may not ignite. The burner head should be removed and replaced. Turn the gas and power off to the stove. Remove the burner grate and burner cap and set them aside. Lift the burner head off the stove and dispose of it. Place the new burner head over the burner base and make sure the pin goes inside it. Seat the burner head level over the hole and make sure it is level. Place the burner cap and grate back on the stove. Reconnect the gas and power.This burner head is an authentic OEM replacement part sourced directly from the manufacturer for use on gas ranges by Kenmore, Frigidaire, Crosley, and Electrolux. It is a silver metal part that is sold individually.
Replace worn, clogged, or damaged gas burner heads on your cooktop. Restores proper gas flow and flame distribution when old burners are dirty or corroded.
Igniter and orifice assembly includes igniter, orifice, and gas tube. Replace if cracked, corroded, or broken. Installs under range top at burner base.
Replaces the burner igniter electrode and orifice holder assembly on gas range cooktops. Needed when the original is cracked, corroded, or broken.
Igniter and orifice assembly for gas range burners. Mounts under the cooktop to spark and control gas flow. Replace if cracked, corroded, or damaged.
Regulates gas pressure from your home's supply line to the range burners. Replace if cracked, leaking gas, causing whining noises, or damaged threads.
Mounting bracket that secures the gas pressure regulator to your range frame. Replace if bent, broken, or missing to properly support the regulator assembly.
Usually ships within 4 - 14 days
Carries fuel between the pressure regulator and gas control valve on your gas range. Replace if the tube is kinked, damaged, leaking, or missing.
If your oven won't ignite but the igniter glows red-hot, a faulty safety valve may be blocking gas flow. This valve regulates gas to restore ignition.
Replace a cracked, clogged, or damaged surface burner head on your gas range or cooktop. Restores proper gas distribution and flame pattern.
Fix an oven that won't heat or takes too long to preheat. This igniter glows but may be too weak to open the gas valve. DIY repair in under an hour.
Replace your gas range oven baffle if cracked, damaged, or missing. Directs heat circulation inside the oven cavity for even cooking performance.
This dual gas valve includes the tube running from this valve to the gas supply tube elbow above.
Angled elbow connector that routes gas tubing in tight spaces. Replace if cracked, leaking, or broken during LP conversion to restore secure connections.
Oven won't light or ignites with a loud pop? A faulty igniter is usually the cause. Simple DIY fix—disconnect two screws and wire nuts to replace.
Secures the ignitor assembly to your gas cooktop burner base. Replace if screw head is stripped, threads damaged, or screw is missing after disassembly.
Meters gas flow to your range's top burner for proper flame size and heat output. Replace if worn, incorrect size, or during fuel type conversion.
Burner orifice installs in the gas valve to control fuel flow to the cooktop burner. Replace if cracked, clogged, or when converting between LP and natural gas.
Convert your gas range from natural gas to liquid propane with this LP conversion kit. Includes all necessary orifices for burners when switching fuel types.
Protective wire shield for gas range safety valve. Replaces cracked, damaged, or missing guards. Installs over valve wiring for safety and protection.
Replace your gas range's burner control knob housing cover if cracked, broken, or missing. Installs on the control panel to protect internal components.
8-18 x 0.5 inch mounting screw for electric and gas ranges. Replaces lost, stripped, or corroded screws used to secure components and panels.
Hex head screw secures regulator brackets and components in ranges and ovens. Replace if missing, stripped, or damaged to restore proper fastening.
Secures gas valve assemblies and mounting brackets to your range. Replace if screw is stripped, missing, or corroded to keep valve hardware stable.
Replacement mounting screw for ovens and ranges. Secures panels, brackets, trim, and internal components. Replace missing or stripped screws to restore fit.
Instruction manual and care guide for LP conversion kit installation on gas ranges. Includes step-by-step guidance for converting natural gas to propane.
