Parts for Ge ZIF360NPBLH: Cabinet (1) Parts

This halogen light bulb restores interior lighting so you can clearly see inside your appliance while cooking and cleaning. It replaces a burned-out or dim halogen lamp to improve visibility and safe operation. What it does:

• Provides bright, focused light for appliance interiors so you can check food and settings.
• Replaces a burned-out or flickering halogen lamp that leaves the oven or cooktop dimly lit.
• Matches the OEM part style for direct replacement when this part number is specified.
• Helps restore normal lighting without modifying the fixture or wiring.

• One halogen light bulb.

• Allow the appliance to cool and disconnect power before replacing the bulb.
• Handle the bulb by the base or wear clean gloves; oils from skin can shorten halogen bulb life.
• Test the light after installation and dispose of the old bulb properly.

The Temperature Sensor is an OEM replacement part for GE refrigerators, designed to accurately monitor and relay the temperature inside the refrigerator and freezer compartments to the electronic control board. By detecting the slightest changes in internal temperature, the sensor allows the control board to make real-time adjustments to the cooling system, activating the compressor and fans as needed to maintain optimal conditions for food preservation.

Over time, the temperature sensor can fail due to electrical issues, exposure to moisture, or general wear and tear. A malfunctioning sensor can lead to improper temperature regulation, affecting the efficiency of the refrigerator and the freshness of stored food.

Symptoms of a bad Temperature Sensor include:

• The refrigerator or freezer not maintaining the set temperature
• The appliance running continuously or more frequently than normal
• Inaccurate temperature readings displayed

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

This evaporator fan bracket secures the evaporator fan assembly behind the rear panel. A rigid, correct-fit mount preserves blade clearance and airflow across the evaporator coils for steady temperatures while minimizing vibration and noise.

• Holds the evaporator fan assembly firmly in position
• Maintains alignment and clearance to prevent fan rubbing and excess noise
• Supports proper airflow through the evaporator compartment for consistent cooling
• Replace if the bracket is cracked, warped, or loose; symptoms may include rattling, scraping sounds, or the fan contacting the shroud

• Disconnect power before servicing and use cut-resistant gloves
• Remove shelves/drawers and the rear evaporator cover to access the fan assembly
• Transfer the fan motor and existing hardware to the new bracket; ensure the blade spins freely without contact
• Avoid damaging the evaporator coils; reassemble panels and restore power to test

Keep the refrigerator's rear fan assembly secure and airflow on track with this fan orifice bracket. It supports the fan shroud/orifice so the motor and blade stay aligned, helping maintain proper cooling and reduce vibration.

• Secures the fan orifice/shroud to the machine-compartment frame
• Maintains correct fan motor and blade positioning for smooth operation
• Helps direct airflow through the condenser area for effective heat removal
• Typical symptoms of a failed bracket include rattling/buzzing from the back, a loose or wobbling fan assembly, reduced airflow, or warm temperatures

• Disconnect power and move the refrigerator to access the rear machine compartment
• Remove the rear access cover; support the fan motor/blade before loosening fasteners
• Transfer any reusable mounting hardware to the new bracket; align the orifice/shroud properly
• Ensure the fan spins freely and the assembly is secure before reinstalling the rear cover and restoring power

The Evaporator Fan Blade is an OEM part for GE refrigerators. This fan blade is crucial for circulating air over the evaporator coils, which helps to maintain an even temperature throughout the refrigerator and ensures efficient cooling.

Common causes of a bad fan blade include regular wear and tear, damage from ice buildup or debris, and mechanical issues that cause the blade to crack or warp. A compromised fan blade can lead to poor air circulation, resulting in uneven cooling and potential frost buildup.

Symptoms of a bad evaporator fan blade include:

• Unusual noises coming from the freezer compartment
• Inconsistent temperatures within the refrigerator or freezer
• Frost buildup on the evaporator coils
• Reduced cooling efficiency

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Lid Bumper is an OEM part for GE refrigerators. It is designed to provide cushioning and protection for the refrigerator lid, preventing damage and ensuring smooth, quiet closing.

Causes of a bad Lid Bumper can include deterioration over time due to frequent use, exposure to temperature variations, or damage from accidental impacts. A worn or damaged bumper may no longer provide adequate cushioning, leading to potential damage to the lid or the refrigerator itself.

Symptoms of a bad Lid Bumper include:

• The refrigerator lid closing too hard
• Unusual noises when closing the lid
• Visible wear or cracks on the bumper

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Fan Motor Grommet is an OEM replacement part for GE refrigerators. It is a small but essential component that helps to seal and insulate the area around the fan motor, preventing air leaks and maintaining optimal cooling efficiency.

Causes of a damaged or worn-out fan motor grommet can include prolonged use, exposure to extreme temperatures, or physical damage from improper handling or installation.

Symptoms of a bad fan motor grommet include:

• Reduced cooling performance
• Increased energy consumption
• Frost buildup in the freezer compartment
• Unusual noises coming from the fan area

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Fan Motor Grommet is an OEM replacement part for GE refrigerators. This small but essential component serves as a seal and insulator around the area where the fan motor shaft protrudes from the appliance body.

Causes of needing to replace the fan motor grommet can include normal wear and tear over time, exposure to extreme temperatures or moisture, or physical damage due to impact or improper installation.

Symptoms of a faulty or missing grommet include:

• Air leaks or drafts around the fan motor area
• Condensation buildup or frost formation near the motor shaft
• Increased noise or vibration from the fan motor assembly
• Reduced cooling efficiency due to air leakage

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore refrigerator models.

This evaporator fan motor dust cap is an authentic OEM replacement part found on refrigerator and freezer fan motors. This dust cap prevents the fan motor bearing and housing from being damaged by dirt and debris. If the dust cap is cracked or broken, the fan may make loud squealing noises. If the dust cap is not removed and replaced, the fan could stop working and ultimately cause the refrigerator's temperature to be affected. To start, disconnect the power and water to the refrigerator. Remove food from the freezer so that the back panel of the freezer can be accessed to reach the fan. Remove the ice maker and set it outside the freezer. Disconnect the fan and take it out of the freezer to expose the fan's shaft and the dust cover. Pry the dust cover off and install the new one. Replace the fan and cover. Reconnect the wires and reinstall the icemaker. Put the food back in the freezer. Reconnect the power and water.The evaporator fan motor dust cap is a white plastic part that is sold individually. This dust cover is made for use in refrigerators manufactured by General Electric, Hotpoint, and Kenmore.

The Temperature Sensor Grille is an OEM part for GE refrigerators. This grille covers and protects the temperature sensor, ensuring it accurately measures the internal temperature of the refrigerator.

Causes of a bad grille can include physical damage from impacts, regular wear and tear, or the buildup of dust and debris that can obstruct airflow.

Symptoms of a bad temperature sensor grille include:

• Inaccurate temperature readings
• The refrigerator running continuously or not cooling properly
• Visible damage or obstruction on the grille
• The sensor becoming loose or dislodged

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This top fan bracket secures the refrigerator's top/condenser fan assembly to the cabinet, helping keep the fan aligned for proper airflow and quiet operation. Replaces a worn or broken mounting bracket to restore stable fan mounting. What it does:

• Provides a secure mounting point for the top/condenser fan assembly
• Keeps the fan aligned to prevent rubbing, vibration, and noise
• Helps maintain proper airflow for consistent cooling performance
• Commonly replaced when bracket is cracked, bent, or broken

• Disconnect power to the appliance before beginning work
• Typical installation requires removing the top access cover and fan housing; keep track of all fasteners
• Handle sheet metal edges carefully and wear gloves to avoid cuts
• Reuse original screws if not supplied; verify fan alignment and clearance after installation

A 2 amp replacement fuse that protects low-current appliance circuits by opening when an overcurrent occurs. Install this direct-replacement fuse to restore power to control circuits and stop damage from a blown fuse. What it does:

• Interrupts current in control or low-voltage circuits when the fuse rating is exceeded
• Prevents electrical damage by opening the circuit on overloads
• Common symptoms of a blown fuse: appliance won't power on, controls are unresponsive, or intermittent operation
• Use as a like-for-like replacement matched to the original 2 amp rating

• Disconnect power to the appliance before inspecting or replacing the fuse
• Replace only when the appliance is cool and dry; avoid touching conductive ends

This DC evaporator fan motor assembly circulates cold air across the evaporator coil to maintain proper refrigerator/freezer temperatures and efficient cooling. Replaces a failed or noisy evaporator fan to restore normal airflow. What it does:

• Spins the evaporator fan blade to move cold air through the evaporator and into the cabinet.
• Helps prevent frost buildup by maintaining airflow across the coil.
• Common symptoms of failure: loud or grinding noise, fan not running, uneven cooling, or warm compartments.
• Works as the airflow drive behind frost buildup and temperature fluctuation issues when the compressor and thermostat are otherwise functioning.

• One evaporator fan motor assembly (DC) as shown.

• Disconnect power at the breaker or unplug the appliance before starting any repairs.
• Access typically requires removing interior panels/evaporator cover and handling evaporator components carefully to avoid coil damage.
• Confirm connector orientation and secure mounting; test operation before reassembling panels.
• If you find ice on the evaporator, fully defrost the compartment and verify no air leaks or drainage issues remain.

This evaporator coil assembly circulates refrigerant and absorbs heat inside the freezer section to enable efficient cooling and proper temperature control. Replacing a worn or damaged coil restores normal refrigeration performance. What it does:

• Circulates refrigerant through the freezer evaporator to remove heat from the air
• Helps maintain cold temperatures and proper defrost cycling when functioning correctly
• Commonly linked to symptoms such as reduced cooling, excessive frost or ice buildup, or long run times
• Works with the freezer compartment's fan and defrost system to keep airflow and temperature stable

• Disconnect power before beginning any service to avoid electrical shock
• Refrigerant system work (evacuating or recharging) must be performed by a certified HVAC/refrigeration technician per local regulations
• Handle the coil carefully to avoid bending fins or damaging the tubing and connections
• Confirm fit and necessary mounting hardware or gaskets before installation; additional components may be required

This is a replacement edge trim piece that restores a clean, finished edge and helps protect cabinet or door surfaces from chips and wear. It improves the appearance and prevents edges from catching on seals or gaskets. What it does:

• Covers and protects exposed metal or plastic edges on appliance doors or panels
• Replaces cracked, split, or missing trim that can catch on clothing or seals
• Helps maintain a smooth sealing surface to reduce gaps or snags
• Restores finished appearance after damage or wear

• One edge trim piece as shown

• Remove any old adhesive or debris before installing for a secure fit
• Trim to length if required and press firmly into place; some installations use adhesive or snaps
• Wear gloves to avoid sharp edges during removal and installation

This Evaporator trough (catch) collects defrost water from the evaporator and channels it to the refrigerator drain pan, helping prevent water buildup and freezing around the evaporator assembly. What it does:

• Catches melt water produced during automatic defrost cycles and directs it to the drain path
• Helps prevent water pooling or ice buildup inside the freezer/evaporator area
• Supports proper drainage to the condenser/drip pan to avoid leaks under the appliance
• Fits behind the evaporator cover to maintain correct water flow and containment

• One evaporator trough (catch) as shown

• Disconnect power to the appliance before starting any repair
• Remove evaporator cover/panels carefully to access the trough; avoid bending evaporator fins
• Verify correct orientation and secure with existing screws/clips; ensure drain outlet aligns with the drain tube

This left-hand link actuator moves a device linkage to restore proper mechanical motion in the appliance. Replacing a worn or broken actuator helps stop erratic movement and restores reliable operation at the affected linkage. What it does:

• Converts motor or lever movement into motion at the left-hand linkage
• Replaces a cracked, stuck or broken actuator that prevents proper linkage movement
• Can stop clicking, grinding or failed movement caused by a damaged link actuator
• Works where a left-side linkage needs an exact-fit actuator to restore function

• Disconnect power to the appliance before starting work
• Remove only the panels and fasteners necessary to access the actuator; label connectors if needed
• Handle plastic tabs and mounting points carefully to avoid breakage during removal and installation
• Reconnect wiring and test the mechanism through a full cycle before reassembling all panels

Spring should have GOLD color.

This fresh food compartment fan circulates cool air inside the refrigerator section to help maintain even temperatures and reduce hotspots. Replacing a worn fan can restore airflow and improve overall cooling consistency. What it does:

• Moves air through the fresh food compartment to help distribute cold air evenly
• Helps prevent warm spots and reduces temperature fluctuations in the refrigerator section
• Common symptom of failure: reduced airflow or unusual noise coming from the fresh food area

• One fresh food compartment fan

• Disconnect power to the appliance before attempting any repairs
• Access often requires removing interior panels or shelves; keep track of fasteners and trim
• Inspect wiring and connectors for damage before installing the new fan
