Parts for Whirlpool BEA30AZAIM0: 01 - Color Variation Parts

This gearcase housing is the molded outer case that supports and protects the washer transmission/gearcase assembly, keeping internal gears aligned for reliable spin and agitation performance. What it does

• Replaces a cracked, broken or warped gearcase outer housing that can cause gearbox misalignment
• Restores correct mounting and support for the transmission and related internal gears
• Helps stop wobbling, grinding noises or agitation/spin issues caused by a damaged housing
• Preserves seals and internal components by providing correct enclosure and alignment

• Inspect surrounding seals, fasteners and the gearcase for wear while replacing the housing
• Disconnect power and water supply before beginning work; drain tub and follow manufacturer safety procedures
• Use correct fasteners and torque per OEM specifications to avoid leaks or misalignment

This planetary gear assembly drives the washer's agitator/spin mechanism to transfer motor motion into drum movement, restoring smooth agitation and spin action. Designed to fit as the washer's internal gearing component for reliable operation. What it does:

• Converts motor rotation into the agitator/drum motion for effective washing and spinning
• Replaces worn or damaged gears that can cause noisy operation or grinding sounds
• Helps correct slow, intermittent, or no-agitation and no-spin symptoms when gearbox failure is present
• Works as the internal gearset that mates with the transmission/agitator components

• One planetary gear assembly

• Disconnect power and water before beginning any repair
• Requires partial disassembly of the washer cabinet and access to the transmission/agitator area
• Inspect related parts (agitator, drive coupling, transmission) for wear and replace as needed

This planetary gear assembly transfers motor motion to the appliance's drive mechanism, restoring smooth rotation and normal operation. It replaces a worn or damaged planetary component to reduce noise and restore consistent drive performance. What it does:

• Transfers motor torque through the gear train to the driven component for proper operation
• Replaces worn or damaged gears that can cause grinding, clunking, or loss of drive
• Helps stop intermittent or failed agitation/spin caused by stripped or broken gear teeth
• Restores correct gear engagement to reduce excessive noise during operation

• One planetary gear assembly

• Disconnect power and water before starting any repair
• Some disassembly of the gearcase or transmission may be required; follow the OEM service manual
• Inspect surrounding seals, bearings, and fasteners; replace any damaged components
• Use proper tools and torque values

Color: Onyx black

This cover is a replacement access panel that protects internal components and restores the appliance's exterior appearance. It keeps wiring and controls shielded while maintaining a clean, finished look. What it does:

• Shields control components and wiring from dust, spills, and accidental contact
• Restores damaged or missing exterior panels for a finished appearance
• Helps maintain proper airflow and component clearance by covering openings
• Can reduce rattles or vibration by replacing a loose or broken panel

• One replacement cover

• Disconnect power (and gas or water if applicable) before starting any repair
• Basic hand tools are typically required; follow the appliance's service manual for specific steps
• Handle edges carefully; align tabs/fasteners before securing to avoid damage
• Replace worn fasteners or clips to ensure a secure fit

This cobalt blue replacement cover restores the appliance's exterior look and protects internal components from dirt and wear. It fits where the original colored trim or panel cover has become cracked, faded, or missing. What it does:

• Replaces a damaged or worn cobalt blue cover to renew appearance and finish
• Shields underlying components from dust and debris
• Helps prevent small items from entering openings behind the cover
• Commonly used when the original cover is cracked, chipped, faded, or broken

• Disconnect power to the appliance before beginning any work to avoid shock or injury.
• Installation typically requires only basic hand tools; follow the appliance's service instructions.
• Handle edges carefully — clips or tabs can be sharp or brittle on older parts.
• Only install a part that matches the appliance's original location and attachment points; do not force or modify the part.

This grille control surface assembly provides the finished front trim for the appliance control area and restores a clean, secure fit and appearance. It replaces a cracked, damaged or loose control-area grille to improve panel alignment and aesthetics. What it does

• Covers and protects the appliance control area while providing the finished exterior appearance
• Restores proper fit and alignment when the original grille is cracked, bent, or broken
• Helps keep moisture and debris away from underlying controls and wiring
• Matches Onyx black finish for a consistent look with the rest of the appliance

• Disconnect power to the appliance before beginning any repair
• Basic hand tools (screwdriver, possibly trim tool) are typically required for removal and reattachment
• Align tabs and screw holes carefully to avoid cracking the trim during installation
• Replace damaged internal fasteners or mounting clips to ensure a secure fit
