Parts for Ge PGB910SEM3SS: 02 - Control Panel & Cooktop Parts

This right-side end support secures and centers the appliance's rotating assembly so the motor and blower run smoothly. It restores proper alignment and reduces rubbing or wobble that can cause noise or airflow issues. What it does:

• Holds the motor shaft or fan spindle in place to maintain correct rotation alignment
• Keeps the blower/fan wheel properly seated to prevent contact with housing
• Helps reduce vibration and audible noise from a loose or worn support
• Supports reliable airflow by preserving correct component spacing

• One right-side end support

• Disconnect power before starting any repair
• Access may require removing panels or components; keep fasteners organized
• Inspect mating surfaces and brush away debris before installing to ensure a secure fit

This end support is a small mounting bracket that secures the freezer/refrigerator end panel and helps keep the cabinet aligned for smooth door operation and proper seal. It replaces a worn or broken support to restore stability and reduce rattling. What it does:

• Supports and anchors the end panel at the left-front corner of the cabinet
• Maintains correct panel alignment to help doors and seals close properly
• Reduces vibration, shifting, or rattling caused by a damaged or missing support
• Fits into mating slots/tabs on the cabinet frame as the OEM bracket does

• One end support (left-front)

• Basic hand tools required; remove power to appliance before service
• Handle parts carefully to avoid scratching painted surfaces
• Inspect adjacent clips, screws and panels and replace any damaged fasteners

This electronic oven control board (ERC) governs the clock, display, keypad inputs, and bake/broil relays. Replacing a failed control restores accurate temperature regulation, responsive controls, and normal display/timer operation.

• Controls bake and broil relays to heat the oven to the set temperature
• Manages the digital clock, timer, and display
• Interprets keypad inputs to start/stop cooking functions
• Common symptoms: oven won't heat or won't start, temperature drifts, blank or unresponsive display, recurring error codes/beeping

• Disconnect power at the circuit breaker before servicing
• Access the control behind the control panel; note screw locations and panel orientation
• Photograph wiring and move connectors to the new board one at a time to prevent miswiring
• Handle by the edges to avoid static damage; transfer any mounting hardware or overlay from the original board

This mounting screw secures appliance components to the chassis for a tight, rattle-free fit. Replacing a missing, stripped, or corroded fastener helps keep panels, brackets, or burner assemblies properly aligned and secure.

• Fastens designated parts to the appliance frame or mounting points
• Helps maintain proper alignment of panels, trim, brackets, or burner assemblies
• Restores hold when the original screw is worn, rusted, or lost
• Symptoms include loose or wobbly components, rattling/vibration, or visible gaps

• Disconnect power; allow all surfaces to cool. For gas units, also shut off the gas supply.
• Use the correct driver/bit; avoid cross-threading.
• If mating threads or clip/nut are damaged, repair or replace them before installing.
• Tighten until secure; do not overtighten to prevent stripping.

The GE spark module kit is an OEM replacement part for GE stoves and ranges. It generates the spark needed to ignite the gas burners. The kit includes the spark module and associated wiring harness. When the burner control knob is turned to the "ignite" position, the spark module receives a signal and activates. It then produces an electrical spark that ignites the gas as it flows from the burner orifice, allowing the burner to light.

Over time, spark modules can fail due to electrical issues, wear and tear from frequent use, or exposure to moisture. A malfunctioning spark module can disrupt the ignition process, making it difficult to light the burners.

Symptoms of a bad spark module include:

• Burners not igniting
• No clicking sound when turning the burner knob
• Intermittent sparking
• Only some burners igniting

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

Replace worn or damaged stovetop grates with this cast surface burner grate kit. It restores a level, stable cooking surface on your gas range or cooktop so pots and pans sit securely and heat evenly over the burners.

• Supports cookware at the correct height above the burners
• Provides an even, stable surface for moving pots and pans
• Common fix for cracked, warped, or broken grates
• Helps reduce rocking or instability from worn grates

What's included: One surface burner grate kit (cast), as supplied by the manufacturer. Installation notes:

• Allow the cooktop to cool completely before handling grates.
• Lift off old grates; position the new grates so they align properly and sit fully on the cooktop.
• Handle carefully—cast parts can chip or scratch surfaces if dropped.
• Verify each grate sits flat and stable before use.

Replace worn or damaged stovetop grates with this cast surface burner grate kit. It restores a level, stable cooking surface on your gas range or cooktop so pots and pans sit securely and heat evenly over the burners.

• Supports cookware at the correct height above the burners
• Provides an even, stable surface for moving pots and pans
• Common fix for cracked, warped, or broken grates
• Helps reduce rocking or instability from worn grates

What's included: One surface burner grate kit (cast), as supplied by the manufacturer. Installation notes:

• Allow the cooktop to cool completely before handling grates.
• Lift off old grates; position the new grates so they align properly and sit fully on the cooktop.
• Handle carefully—cast parts can chip or scratch surfaces if dropped.
• Verify each grate sits flat and stable before use.

Replace worn or damaged stovetop grates with this cast surface burner grate kit. It restores a level, stable cooking surface on your gas range or cooktop so pots and pans sit securely and heat evenly over the burners.

• Supports cookware at the correct height above the burners
• Provides an even, stable surface for moving pots and pans
• Common fix for cracked, warped, or broken grates
• Helps reduce rocking or instability from worn grates

What's included: One surface burner grate kit (cast), as supplied by the manufacturer. Installation notes:

• Allow the cooktop to cool completely before handling grates.
• Lift off old grates; position the new grates so they align properly and sit fully on the cooktop.
• Handle carefully—cast parts can chip or scratch surfaces if dropped.
• Verify each grate sits flat and stable before use.

This factory screw secures components on GE cooking appliances. Replacing a lost or stripped fastener helps keep parts tight and aligned for safer, rattle-free operation.

• Fastens brackets, panels, trim, or burner components on a range, cooktop, or wall oven
• Replaces missing, corroded, or stripped hardware
• Helps reduce looseness, vibration, or rattling noises
• Restores proper alignment after service or cleaning

• Disconnect power and shut off gas supply. Allow the appliance to cool completely.
• Match this screw to the original and install in the same location.
• Use the correct driver; hand-tighten and avoid overtightening to prevent stripped threads or cracked parts.
• If mating threads are damaged, repair or replace the affected component before reassembly.

This cooktop mounting screw secures the cooktop to its frame or mounting brackets, keeping the surface stable and properly aligned. Replace stripped, missing, or rusty hardware to eliminate wobble, rattling, or lifted corners.

• Secures the cooktop to the chassis or brackets to prevent movement during use
• Helps maintain a flush, stable installation and proper alignment
• Replacing damaged or missing screws can reduce vibration, rattling, and gaps
• Supports safe, consistent operation of the cooking surface

• Disconnect power at the breaker; for gas models, also shut off the gas supply
• Support the cooktop while loosening/tightening hardware to avoid stressing the top
• Start all screws before tightening; do not overtighten

This control panel overlay (T011) is the adhesive graphic label for the appliance's electronic control. It refreshes worn or unreadable button markings so settings are easy to identify and the console looks clean again. What it does:

• Provides the printed icons and text for the control keys and display; contains no electronics
• Restores legibility when the original overlay is faded, peeling, cracked, or damaged
• Clearly labels functions to help you select the correct settings
• Commonly used when replacing the electronic control board or refurbishing the console

• One T011 control panel overlay

• Disconnect power at the breaker before servicing
• Access the existing overlay by removing the control panel or electronic control per your model's service information
• Carefully peel off the old overlay, clean any adhesive residue, align, and apply the new overlay to a clean, dry surface
• Reassemble the panel and restore power

• Overlays are layout- and finish-specific; match the T011 layout and graphics to your original before installing

The Burner Cap Assembly is an OEM part for GE gas ranges and cooktops. It sits atop the gas burner to help distribute the flame evenly for better cooking performance. This cap is crucial for achieving precise temperature control and consistent heating, ensuring that food cooks evenly across the cookware.

Symptoms of a bad Burner Cap Assembly include:

• Uneven flame distribution, leading to uneven cooking or heating.
• Difficulty igniting the burner, or the flame going out unexpectedly.
• Visible signs of wear, such as warping, discoloration, or chipping of the burner cap.

Causes of a bad burner cap can include accumulation of food particles or cleaning products that clog the ports, physical damage from impact or dropping, or general deterioration from regular exposure to high temperatures.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Burner Cap Assembly is an OEM part for GE gas ranges and cooktops. It is designed to sit atop the burner base, helping to distribute the flame evenly across the cooking surface. The cap also serves to protect the burner head from spills and debris, which can clog the gas outlets.

Symptoms of a bad Burner Cap Assembly include:

• Uneven flame distribution, which can cause uneven cooking or take longer to heat food.
• Difficulty lighting the burner, or the flame going out unexpectedly.
• Visible signs of wear like chipping, warping, or discoloration.

Causes of a bad burner cap can include accumulation of spilled foods or cleaning chemicals, which might block the gas flow, and normal wear and tear from high-temperature exposure that can alter the shape or integrity of the cap.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Burner Cap Assembly is an OEM part for GE gas ranges and cooktops. It sits atop the burner head and serves to distribute the flame evenly across the surface, enhancing cooking efficiency and consistency.

Symptoms of a faulty burner cap assembly include:

• Uneven flame distribution or a yellow or orange flame.
• Difficulty igniting the burner.
• Excessive soot or unburned gas smell, indicating incomplete combustion.

The common causes of issues with the burner cap assembly include misalignment, food spillage clogging the ports, or wear and tear from regular use. These can affect the flow of gas and air, leading to inefficient combustion and poor cooking performance.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Burner Cap Assembly is an OEM part for GE cooktops and ranges. It is designed to cover the burner head, ensuring even flame distribution for efficient and effective cooking. The cap also protects the burner head from spills and debris, which can interfere with burner performance and cause clogs.

You should replace the burner cap assembly if it becomes damaged or worn out. Causes of a bad burner cap assembly can include regular exposure to high heat, food residue buildup, or accidental impacts that cause cracks or warping. A compromised burner cap can lead to uneven flames and inefficient cooking.

Symptoms of a bad burner cap assembly include:

• Uneven or yellow flames
• Difficulty igniting the burner
• Visible cracks, chips, or warping in the burner cap
• Poor cooking performance with hotspots on cookware

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Top Burner Spark Electrode is an OEM replacement part for GE brand appliances. Compatible with select GE gas ranges, this spark electrode ensures a reliable ignition for your burners. It features a white ceramic base and a metal electrode tip.

Symptoms of a bad igniter:

• Burners not lighting
• Igniter sparking erratically

The causes of a bad part can include physical damage or wear and tear over time.

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

The Small Surface Burner is an OEM part for GE ranges and cooktops. It provides a consistent heat source for cooking, designed for use with smaller cookware, making it ideal for simmering and precise heating tasks.

You should replace the small surface burner if it becomes damaged or worn out. Causes of a bad surface burner can include regular wear and tear, spills, and exposure to high temperatures. A defective burner can lead to uneven heating or failure to ignite properly.

Symptoms of a bad Small Surface Burner include:

• The burner not igniting or taking a long time to ignite
• Uneven flame distribution
• The burner not producing heat at the expected levels

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Burner Base is an OEM part for GE ranges and cooktops, designed to securely hold the burner and distribute gas evenly for cooking. This part serves as the foundation for the gas burner, ensuring a stable and consistent flame that can be adjusted for precise cooking temperatures.

Causes of a bad Burner Base can include corrosion, clogging from spilled foods or liquids, and general wear and tear over time. A damaged or deteriorated burner base can affect the flame's quality, leading to uneven cooking or, in some cases, posing a safety hazard.

Symptoms of a bad Burner Base include:

• Uneven flame or poor heat distribution
• Difficulty igniting the burner
• A yellow or orange flame instead of blue
• Gas leakage smell when the burner is on

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Vision Burner XL is an OEM part for GE ranges. It is a large burner designed to provide high heat output for tasks that require intense cooking temperatures, such as boiling large pots of water or rapid heating. This burner ensures efficient and powerful cooking performance.

Causes of a bad Vision Burner XL can include wear and tear from frequent use, exposure to high temperatures, or damage due to impact or spills. Electrical issues can also lead to malfunctioning.

Symptoms of a bad Vision Burner XL include:

• The burner not igniting
• Uneven flame or weak flame
• The burner not maintaining a steady flame
• Visible damage or corrosion on the burner

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Medium Surface Burner is an OEM part for GE ranges and cooktops. This burner is essential for a wide range of cooking tasks, from simmering sauces to sautéing vegetables. The medium surface burner ensures even heat distribution and efficient fuel consumption, contributing to the overall cooking performance of your appliance.

Causes of a bad Medium Surface Burner can range from clogged burner ports, which impede gas flow and affect flame consistency, to wear and tear on the igniter or the burner assembly that prevents proper operation.

Symptoms of a malfunctioning Medium Surface Burner include:

• Inconsistent flame size or failure to ignite
• Uneven heating or hot spots on the cookware
• Visible damage or corrosion on the burner itself

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Electrode Clip is an OEM part for GE gas ranges. This part secures the electrode, which provides the ignition spark that lights the burners.

Causes of a bad Electrode Clip can include corrosion, physical damage from impact or mishandling, or loosening over time due to heat exposure and repeated use.

Symptoms of a bad Electrode Clip include:

• Failure of the burners or oven to ignite
• Intermittent or inconsistent ignition
• Visible damage or deterioration of the clip itself

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

Package of 12

This replacement screw fastens appliance components to restore secure fit and reduce vibration or panel movement. Simple, direct replacement for a missing or stripped fastener to help maintain proper assembly and operation. What it does:

• Secures panels, brackets or trim to keep parts aligned and prevent rattling
• Restores mounting where a lost or damaged screw causes loose or sagging components
• Helps maintain electrical and mechanical connections by keeping parts properly seated
• Small hardware solution for cosmetic and functional stability

• Use the correct sized screwdriver or driver bit to avoid stripping the head
• Inspect mating threads and replace if damaged; do not force a stripped screw
• Tighten until snug — avoid over-tightening which can crack plastic or strip threads
• If accessing areas near power or controls, disconnect appliance power first and follow all safety precautions

This replacement screw secures appliance components so panels, brackets, and trim stay tight and aligned. Use it to replace a missing, stripped, or rusted fastener and restore a solid, rattle-free fit in the affected assembly.

• Fastens parts to the chassis/frame or mounting brackets
• Replaces lost, damaged, or corroded hardware
• Can help address loose or vibrating panels and minor misalignment
• Maintains a secure attachment during normal operation

• Disconnect power before servicing; for gas appliances, also shut off the gas supply
• Match the screw to the original location and reuse any clips or washers if present
• Start threading by hand to avoid cross-threading; tighten snugly without overtightening
• Repair/replace damaged receiving threads or clip for proper hold

The Griddle Assembly is an OEM part for GE ranges. This griddle is designed to fit over the burners, providing a flat and even cooking surface ideal for preparing foods like pancakes, eggs, and grilled sandwiches.

Causes of a bad griddle can include regular wear and tear, warping from high heat exposure, or physical damage from dropping or mishandling. A compromised griddle can lead to uneven cooking and potential safety hazards.

Symptoms of a bad griddle assembly include:

• Warping or bending of the griddle surface
• Uneven heating or hot spots during cooking
• Cracks or chips on the griddle
• Food sticking excessively despite proper maintenance

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

Size: 8 - 18 ab hxw 5/8 s
