Parts for Kitchenaid KDTM504EPA2: Control Panel And Latch Parts

The Affresh Dishwasher Cleaner is an OEM accessory designed specifically for Whirlpool brand dishwashers. This citrus-scented tablet removes residue, odor-causing soils, and food particles from the dishwasher tub and gasket area during the cleaning cycle. Symptoms of a buildup include unwanted odors emanating from the dishwasher, especially after opening the door. Over time, residue and grime accumulate in hard-to-reach areas and provide an environment for mold and mildew growth.

Regular cleaning helps prevent this by removing leftover soils before they harden or encourage bacterial activity. The Affresh tablet utilizes a unique blend of cleaning ingredients that target soils and biofilms through a combination of powerful scrubbing action and natural cleaning enzymes.

As the #1 recommended dishwasher cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and select Kenmore dishwashers for consistent cleanliness and freshness. The package includes six tablets 4.2 ounces

This console is the replacement control panel housing that holds and protects the dryer's user controls and display, restoring a secure, finished front for normal operation and appearance. What it does

• Provides the mounting surface and housing for control knobs, buttons, and the display.
• Protects internal control components and wiring from debris and damage.
• Restores proper alignment and fit of user controls and display lenses.
• Helps eliminate issues like loose or misaligned controls, exposed wiring, or cosmetic damage.

• Disconnect power (unplug or switch off breaker) before starting any work.
• Remove console trim and retain all mounting screws for reinstallation.
• Handle with care to avoid damaging attached switches, display, or wiring harnesses.

This small retaining clip secures trim and appliance components to keep panels and assemblies in place, helping prevent rattling and loose parts during use. It's a simple replacement that restores proper fit and alignment. What it does:

• Holds panels, trim, or small assemblies in place to maintain a secure fit
• Prevents rattling, vibration noise, and movement of loose parts
• Replaces broken, bent, or missing clips that allow gaps or misalignment
• Works where a small fastener is needed to secure plastic or metal components

• Disconnect power or unplug the appliance before servicing to avoid shock or injury
• Inspect the mounting area for damage; replace any broken mating tabs or screws for a secure fit
• Installation typically requires basic hand tools such as pliers or a screwdriver; apply steady pressure to snap clip into place

This is an electrical wire-harness connector used to join wiring in the appliance. It restores a secure electrical connection so controls and components receive proper power and signaling. What it does:

• Provides a secure mating point between wiring harnesses or between a harness and a component
• Maintains proper electrical contact to prevent intermittent power or signal loss
• Commonly used where a detachable electrical connection is needed for service or assembly
• Can help address symptoms like intermittent operation, components not powering on, or visible damaged/loose plug ends

• Disconnect power to the appliance before inspecting or replacing any electrical connector
• Verify connector orientation and full engagement; bent terminals may need replacement
• Compare the replacement to the original to ensure terminal count, shape and locking feature match
• If wiring insulation or terminals are damaged, replace the harness

This factory screw secures appliance components. It restores a tight, reliable hold when the original hardware is stripped, missing, or corroded—helping prevent vibration and keeping panels and brackets properly aligned.

• Provides threaded fastening for panels, brackets, covers, or internal components
• Replaces worn, rusted, stripped, or missing hardware
• Helps reduce vibration and rattling from loose parts
• Restores proper alignment and a secure fit of attached parts

• Disconnect power; turn off water supply before service
• Note original screw location and retain any spacers or clips for reassembly
• Start threads by hand to avoid cross-threading
• Tighten snugly; do not overtighten to prevent stripping

The Door Latch is an OEM replacement part for Whirlpool dishwashers. It is a crucial component that ensures the dishwasher door remains securely closed during wash cycles, preventing water leaks and maintaining the proper pressure and temperature within the tub.

Symptoms of a bad dishwasher door latch include:

• The door not closing properly or securely
• Water leaking from the dishwasher during cycles
• Error codes or fault indicators related to the door latch mechanism
• Difficulty opening the door after a cycle has completed

Causes of a bad door latch can range from physical damage or obstruction preventing proper closure to wear and tear on the latch components over time.

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Affresh Dishwasher Cleaner is an OEM accessory designed specifically for Whirlpool brand dishwashers. This citrus-scented tablet removes residue, odor-causing soils, and food particles from the dishwasher tub and gasket area during the cleaning cycle. Symptoms of a buildup include unwanted odors emanating from the dishwasher, especially after opening the door. Over time, residue and grime accumulate in hard-to-reach areas and provide an environment for mold and mildew growth.

Regular cleaning helps prevent this by removing leftover soils before they harden or encourage bacterial activity. The Affresh tablet utilizes a unique blend of cleaning ingredients that target soils and biofilms through a combination of powerful scrubbing action and natural cleaning enzymes.

As the #1 recommended dishwasher cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and select Kenmore dishwashers for consistent cleanliness and freshness. The package includes six tablets 4.2 ounces

This electronic control board replaces the appliance's main control module to restore responsive controls and proper cycle operation. It provides the logic and timing functions the appliance uses to run selected settings. What it does:

• Receives input from push-buttons or touch controls and sends commands to motors, heaters, valves or lights
• Controls cycle timing, start/stop and user-selected options
• Can resolve symptoms such as unresponsive or intermittent controls, blank or flickering display, or incorrect cycle behavior
• Works as the central electronic regulator for the appliance's functions and safety interlocks

• Disconnect power before replacing this part to avoid electrical shock.
• Handle the board by its edges and avoid touching components or contacts to prevent ESD damage.
• Verify harness connectors and mounting locations match before finalizing installation.

This replacement brace is a structural support bracket that helps stabilize and secure appliance components for reliable operation. Installing the correct brace restores alignment and reduces movement that can cause noise or wear. What it does

• Provides structural support to internal or external assemblies to keep parts properly aligned
• Helps reduce vibration and rattling caused by loose or damaged supports
• Prevents excess movement that can lead to premature wear of adjacent components
• Commonly replaced when the original bracket is bent, cracked, or missing

• One replacement brace/support bracket

• Use appropriate tools and fasteners for your model; retain any original screws if reusable
• Disconnect power (and water if applicable) before beginning any repair for safety
• Inspect surrounding components and mounting points; replace damaged hardware as needed
