Parts for Electrolux EW36IC60LS2: Control Panel Parts

This ignition generator and wiring harness assembly routes power and provides the spark/ignition signal needed for gas appliance burners to light. It replaces a worn or damaged ignition assembly to restore reliable lighting. What it does:

• Sends ignition voltage to the burner igniters and electrodes so burners light reliably
• Routes and secures wiring between the control module and ignition components
• Common failure symptoms: burners won't light, continuous clicking, or intermittent ignition
• Works as the electrical interface between the control and the igniters for safe startup

• One generator and wiring harness assembly

• Disconnect electrical power and turn off the gas supply before starting work
• Follow the appliance OEM diagram for correct routing and connector locations
• Inspect connectors and electrodes for damage and replace if corroded or worn

This small plastic clip secures the dishwasher drain hose to the pump assembly or discharge fitting, keeping the hose in place and helping prevent leaks or disconnection during operation. What it does:

• Holds the drain hose firmly to the pump or outlet fitting to maintain a watertight connection
• Prevents the hose from slipping free during drain cycles
• Helps stop water leaks and washing chamber flooding caused by a loose hose
• Useful when replacing a cracked or broken retaining clip

• One drain hose retaining clip

• Disconnect power and water supply before accessing the dishwasher lower access area
• Remove the access panel or kickplate to reach the drain hose and pump connection
• Use pliers or a flat tool to remove the old clip and snap the new clip over the hose/fitting until fully seated
• After installation, run a short drain cycle and inspect for leaks; re-secure if necessary

The Terminal Block Kit is an OEM part for Frigidaire appliances, typically used for connecting house power to various electrical appliances like ranges and dryers. This kit includes includes screws, nuts, and a unique terminal block. It plays a critical role in the power supply system by providing a reliable connection point for the appliance's main power cord, preventing loose connections and potential electrical hazards.

Symptoms of a bad Terminal Block Kit include:

• Signs of burning or melting at the connection points,
• Flickering power or intermittent operation of the appliance,
• A burning smell from the appliance area.

Causes of terminal block failure often involve loose connections that can lead to arcing and overheating, improper installation, or general wear and tear that degrades the integrity of the electrical contacts.

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

This main electronic control board manages the appliance's functions and user interface, restoring normal cycle selection and timed operations when the original board fails. Replaces a failed control to return reliable electronic control of the unit. What it does:

• Receives user commands and runs the appliance's operating cycles
• Controls timers, relays and display indicators for proper operation
• Common symptom: appliance won't start or respond to controls
• Common symptom: no or erratic display, or cycles stop unexpectedly
• Helps resolve issues caused by burned or shorted control circuitry

• Disconnect power before attempting any service to avoid shock or damage
• Handle the board by its edges and avoid static discharge; use anti-static precautions
• Verify the appliance model and part number before ordering and swapping parts
