Parts for Ge ZSC2200NWW01: 02 - Controller Parts

This electronic control board assembly manages washer cycles and user commands so the machine runs the selected wash programs and responds to button/knob inputs. It restores control functions when the original board is faulty. What it does:

• Receives input from the console and sends signals to the motor, valves, and timers to run selected wash cycles
• Controls water fill, agitation/spin timing, and drain sequence based on selected program
• Replaces a failed or intermittently responding control board that causes no power, unresponsive controls, or erratic cycle behavior
• Helps resolve symptoms like no start, no cycle advancement, or random stops that trace to the main electronics

• One electronic control board assembly

• Disconnect power before attempting replacement to avoid shock or damage
• Handle the board by its edges; avoid touching components or connector pins to prevent static damage
• Verify connectors and harness routing match before securing the assembly

Display holder bracket for built-in and over-the-range microwaves. Secures the control panel display assembly. Replace if cracked, broken, or missing.

Indicator light for built-in microwaves. Installs on control panel to show active settings. Replace if cracked, burned out, or missing.

This LED board powers and/or controls interior lighting so the appliance interior is illuminated for easier visibility. Replaces a failed or dim LED module to restore consistent, energy-efficient light in the compartment. What it does:

• Provides LED illumination for the appliance interior or compartment.
• Supplies light when the door is opened or when the interior lighting circuit is activated.
• Commonly replaced when lights are dim, flicker, intermittently work, or do not light at all.
• Works with the original mounting and wiring harness to integrate with factory controls.

• Disconnect power to the appliance before servicing to avoid shock.
• Handle the board by its edges and avoid touching LEDs or circuitry.
• Verify proper alignment and secure mounting; reconnect any plugs fully.

Selector knob or dial stopped working? This encoder board translates rotary control input into signals. Moderate DIY repair requires control panel removal.

Fixes microwave that won't heat or has a dark display. This power transformer converts incoming voltage to power the magnetron and control board.

Microwave not working or no power? The relay board controls power distribution to the magnetron and fan. Requires control panel removal to install.

This relay board controls and distributes power to key components, restoring proper operation when the original board fails. It helps resolve power-routing issues that cause intermittent or non-responsive cooking functions.

• Switches high-voltage loads on/off under control of the main electronics
• Can cause no heat, dead display with power present, or intermittent operation when failing
• May produce clicking without function or blown fuse symptoms if shorted
• Restores consistent power delivery to heaters, fans, or transformers as designed

What's included: 1 relay board assembly Install notes:

• Disconnect power before service; high-voltage components may be present
• Handle the board by edges; avoid touching soldered components
• Photograph wiring and transfer connectors one at a time to matching terminals
• Secure board and verify proper routing before restoring power and testing

A replacement board supporter that secures the appliance control board to the cabinet, helping keep the board stable and positioned away from wiring and chassis. Restores proper mounting to reduce vibration and movement of the control board. What it does:

• Holds and supports the control/PC board to prevent excessive movement or rattling
• Keeps the board spaced from the chassis and wiring to reduce risk of shorting or contact
• Helps maintain stable electrical connections for reliable control operation
• Reduces noise caused by a loose or vibrating control board
• Can prevent further wear on board mounting points and connectors

• Disconnect power to the appliance before beginning any service.
• Handle the control board by its edges and avoid touching components; use ESD precautions if available.
• Remove nearby panels or components as needed for access; retain all fasteners for reassembly.
• If mounting points or fasteners are damaged, inspect nearby parts and replace as required.
