Parts for Kenmore 911.4308090 (9114308090, 911 4308090): Cooktop Parts

This is the official user manual that explains how to operate and care for your appliance, helping you use controls correctly and follow safety guidance. Keeps key operating, maintenance, and troubleshooting info at hand. What it does:

• Describes control panel functions, settings, and normal operation
• Lists routine care and cleaning steps to protect performance
• Provides safety warnings and recommended handling procedures
• Offers basic troubleshooting guidance for common symptoms
• Helps owners reference operating information during maintenance

• Read the manual fully before operating the appliance
• Keep the manual for future reference, model-specific information, and service
• Follow all safety warnings and disconnect power before servicing

This electronic control regulates oven functions and user commands, restoring reliable cycle selection, timing and temperature control when the original control fails. Designed as a direct-replacement control assembly for affected 2400-series ranges. What it does:

• Manages oven cooking cycles, timers and user interface inputs so settings run as selected
• Sends and receives signals to heating circuits and sensors to control temperature and run cycles
• Helps stop symptoms like a blank or flashing display, unresponsive buttons, or an oven that won't start or won't stop heating
• Restores normal electronic control behavior when the original board is damaged or fails

• Disconnect power (unplug or shut off breaker) before accessing the control — risk of electric shock
• Label or photograph wiring before disconnecting to ensure proper reconnection; handle the board by its edges to avoid damage
• Test functions after reconnecting power

The Infinite Switch is an OEM part for Whirlpool cooktops and ranges, designed to control the temperature of the burners. This critical component allows for the precise adjustment of heat levels, providing the flexibility needed for various cooking tasks, from simmering sauces to boiling water.

Causes of these symptoms can vary from electrical issues within the switch, such as faulty contacts or internal components, to physical damage from wear and tear or overheating. It's essential to address these issues promptly to maintain the safety and functionality of your cooktop or range.

Symptoms of a bad Infinite Switch include:

• Burners not heating to the set temperature
• Inability to adjust the heat level of the burner, resulting in it being stuck on high, low, or off
• The burner not turning on at all

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

This is a round infinite control knob that replaces a worn, cracked, or missing stove surface control knob to restore user control and a finished appearance. It provides a simple push-on replacement for the stove's infinite switch shaft. What it does:

• Attaches to an infinite (surface element) control shaft to allow variable heat settings
• Lets you smoothly adjust burner power levels instead of using a broken or missing control
• Commonly replaced when the knob is cracked, stripped, loose, or will not stay on the shaft
• Fits standard D-shaped or splined infinite switch shafts (verify shaft type before ordering)

• One (1) infinite control knob

• Turn all power to the appliance off before servicing controls
• Pull the old knob straight off the control shaft; align and push the replacement onto the shaft until fully seated
• If the knob will not seat, verify shaft shape and orientation; do not force or hammer into place
• If the control shaft or switch is damaged, replace the switch assembly rather than forcing a knob

A replacement red indicator lens that restores the panel light's appearance and visibility so you can see when the control or heating element is active. Exact-fit lens designed to mount over the indicator lamp and provide the correct red signal. What it does

• Covers and protects the indicator bulb from dirt, grease, and mechanical damage.
• Provides the red color filter so the indicator clearly shows element or function status.
• Helps restore a faded, cracked, missing or discolored indicator on the control panel.
• Works with the existing indicator lamp and housing to return panel visibility.

• Disconnect power to the appliance before starting any work.
• Typically snaps into the indicator housing; use gentle pressure to avoid cracking.
• Inspect the lamp/housing for damage and replace the bulb if the indicator still does not illuminate.

Restore reliable heat on your range's small burner with this 6-inch surface coil element. Replacing a worn or burned-out coil brings back consistent temperature response and dependable everyday cooking performance.

• Supplies direct electric heat to a 6-inch cooktop burner
• Replaces a coil that is warped, cracked, or has an open/burned-out section
• Common symptoms include: burner won't heat, heats unevenly, or works intermittently
• Visible damage, hot spots, or arcing at the terminals can indicate failure

• Disconnect power by unplugging the range or switching off the circuit breaker
• Lift the old coil and pull straight out from the receptacle to remove
• Inspect the element receptacle/terminal block for discoloration or pitting; replace if damaged
• Align terminals and support, insert fully, and ensure the element sits level in the drip bowl

The 8" Surface Element is an OEM part for GE ranges. It is an 8-inch heating element that fits into the cooktop to provide heat for cooking.

Causes of a bad surface unit include wear and tear from regular use, damage due to heavy cookware, or electrical issues that prevent the element from heating correctly.

Symptoms of a bad surface unit include:

• The burner not heating up
• Uneven heating or hotspots
• Visible damage or burn marks on the element

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

Electric range 6 inch surface unit drip bowl. Color: Chrome. It measures about 8 inches in diameter at its widest point at the top. For an 8 inch large drip pan order WB32X106

The 8-Inch Large Drip Pan is an OEM part for GE ranges and cooktops. This drip pan is designed to sit beneath the heating element, catching any spills, drips, or overflow that occurs during cooking. It helps to protect the range from food debris and liquids, making cleaning easier and preventing damage to the stove's surface.

Symptoms of a failing Drip Pan include:

• Visible wear, rust, or corrosion on the pan
• Difficulty in fitting the pan securely beneath the heating element
• Accumulation of burnt food or discoloration that cannot be cleaned
• The pan becoming warped or damaged from high heat exposure

Causes of a bad drip pan can include regular wear and tear from frequent use, exposure to high temperatures, and spills from cooking. Over time, these factors can lead to rust, corrosion, and other forms of damage that necessitate replacement.

This OEM GE part is also compatible with some models from Hotpoint, RCA, and Kenmore.

This terminal block provides a secure, heat-resistant junction for appliance wiring, ensuring stable power to the connected component. Replacing a damaged or charred block restores safe operation and helps prevent arcing, intermittent power, or failure.

• Creates a solid connection point between appliance wiring and the attached component
• Insulates and separates conductors to reduce shorts and arcing
• Helps deliver consistent power for reliable performance
• Replace if the block is cracked, burned, melted, or if terminals are loose
• Common symptoms include intermittent operation, no heat/run condition, visible scorching, or a burning odor

• Disconnect power at the breaker/fuse and verify no voltage is present before servicing
• Photograph or label wires; move one lead at a time to the matching terminals
• Tighten terminal screws/fasteners securely to ensure firm, low-resistance connections
• Inspect wire ends for heat damage and replace any compromised connectors with high-temperature, manufacturer-approved fittings

This mounting bracket secures the surface element terminal block to the cooktop. Replacing a bent or missing bracket helps keep the coil element connection aligned and stable so the burner plugs in firmly during use.

• Provides a fixed mount for the surface element receptacle beneath the burner opening
• Helps prevent the terminal block from shifting, sagging, or rotating when inserting/removing the element
• Common symptoms include a loose or wobbly receptacle, element not seating fully, or visible bracket damage/missing bracket
• Replace if the bracket is bent, broken, or cannot hold the receptacle in position

• Disconnect power at the breaker and allow the cooktop to cool completely
• Remove the surface element and lift/open the cooktop to access the terminal block area
• Transfer the receptacle/terminal block onto the new bracket and secure with existing hardware, ensuring correct alignment
• The element prongs insert smoothly before restoring power

Package of 12

The Igniter Mounting Screw is an OEM replacement part for GE ovens and ranges. This screw secures the igniter to the burner assembly, ensuring it remains firmly in place for consistent and reliable ignition. Its precise fit and durable design help maintain the stability and functionality of the igniter.

Over time, mounting screws can become corroded, stripped, or lost during repairs or maintenance. A missing or damaged screw may result in a loose igniter, affecting the appliance's ability to ignite properly.

Symptoms of a bad or missing igniter mounting screw include:

• The igniter becoming loose or misaligned

• Difficulty securing the igniter during installation or repair
• The burner fails to ignite reliably or consistently
• Increased noise or movement of the igniter during operation

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.
