Parts for Ge GFE24JGKBFBB: Dispenser Door Parts

The water filter is an OEM part for GE refrigerators. This filter removes or reduces various contaminants.

Features and Benefits:

• Easy DIY replacement, typically mounted inside the refrigerator at the back of the compartment.
• Removes or reduces various contaminants in your water and ice, including lead, cysts, asbestos, atrazine, , taste and odor, chlorine, sediment, turbidity, and more
• NSF/ANSI 42 and 53 standards
• 6 Month lifespan filter
• Carbon Block media
• Micron rating: 0.5-1 micron (Class I)

When to replace your filter:

• Bad taste or odor in water and ice
• Cloudy or discolored ice
• Reduced water flow or pressure
• Refrigerator replace filter indicator light is on

Note: If replacing the Culligan metal canister design filter for the first time, a special adapter, part number AP2615702 is needed, which is not included with this part. The compatible bypass cap is part number AP6891551.

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.


This refrigerator door gasket replaces a worn or damaged door seal to restore a tight closure. A proper seal helps keep cold air in, reduce moisture and frost, and maintain consistent temperatures for better food preservation.

• Forms an airtight seal between the door and cabinet to contain cold air
• Helps maintain stable internal temperatures and efficiency
• Can reduce condensation or frost around the door opening
• Helps with symptoms like a door not sealing, gaps, or warm spots inside

• Unplug the refrigerator before servicing; wear cut-resistant gloves
• Remove the old gasket and clean the door channel and mating surfaces
• Warm the new gasket in hot water to relax bends; press fully into the door channel starting at the corners
• After installation, ensure even contact all around; use low, controlled heat only if needed to smooth waves, and avoid overheating plastics

The Fastener Handle Assembly is an OEM part for GE refrigerators, specifically designed to securely attach the refrigerator or freezer handle to the door. This assembly includes the necessary components, such as screws or bolts, brackets, and possibly end caps, depending on the design, to ensure a sturdy and durable connection between the handle and the door.

Causes for a Fastener Handle Assembly to fail include normal wear and tear from repeated use, excessive force applied to the handle, or corrosion of metal parts due to moisture and refrigeration environment.

Symptoms of a bad Fastener Handle Assembly include:

• A loose handle that moves or wobbles when touched or used.
• Difficulty in opening the refrigerator or freezer door due to a compromised handle attachment.
• Visible damage or wear to the components of the fastener assembly

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

This stop door closes the refrigerator dispenser opening to help keep cold air in and protect the dispenser area from debris. Replacing a damaged stop door restores proper sealing and smooth dispenser operation. What it does:

• Seals the dispenser opening when not in use to reduce cold-air loss
• Helps prevent debris and pests from entering the dispenser chute
• Works with the dispenser actuator/lever to open and close the door during dispensing
• A worn or broken stop door can cause visible gaps, drafts, or debris falling into the dispenser

• Disconnect power to the appliance before starting any work
• Access may require removing the dispenser bezel or inner liner panels
• Handle the door carefully to avoid scratching or breaking the mounting tabs
• Verify proper alignment and actuator engagement before reassembling

The Hinge Bushing is an OEM part for GE refrigerators designed to fit within the hinge assembly of your refrigerator, providing support and smooth movement for the door.

A bad hinge bushing can be caused by regular wear and tear over time or damage due to mishandling or impact. If you notice that your refrigerator door is not opening or closing smoothly, or if it feels loose or wobbly, it may indicate a problem with the hinge bushing.

Symptoms of a bad hinge bushing include:

• Difficulty in opening or closing the refrigerator door
• Door not staying securely closed
• Door sagging or misaligning with the refrigerator frame

Replace your faulty hinge bushing with this genuine OEM part to restore your refrigerator door. This GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.


The Articulating Mullion Assembly is an OEM part for GE refrigerators. This mullion assembly is the vertical divider located between the French doors of the refrigerator. It helps to seal the gap between the doors when they are closed, improving energy efficiency by preventing cold air from escaping and warm air from entering.

Causes of a bad mullion assembly can include wear and tear, physical damage, or hinge misalignment. If you notice any issues with your refrigerator doors not sealing properly, it may be time to replace the mullion assembly.

Symptoms of a bad articulating mullion assembly include:

•  The doors not sealing properly
• Visible gaps between the refrigerator doors
• Increased condensation or frost inside the refrigerator
• Higher energy bills due to inefficient sealing

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This spring water conduit is a protective coil that fits over a refrigerator water supply tube to prevent kinking and abrasion, helping maintain steady water flow to the dispenser/ice maker. It's a simple replacement that restores proper routing and protection for the water line. What it does:

• Protects the water supply tube from sharp bends, kinks, and wear
• Helps keep the water line routed correctly behind the appliance
• Reduces the chance of flow restrictions caused by pinched tubing
• Can prevent rubbing damage where the line contacts cabinet edges

• One spring water conduit

• Disconnect power and shut off the water supply before starting work
• Remove access panels as needed to reach the water line; slide the conduit over the tubing to cover the exposed run
• Ensure the tubing is free of sharp bends and that the conduit seats where needed; restore panels and water/power, then check for leaks

Size: 10-32 GXTT FLP.595 S

This hinge bushing is a small replacement sleeve that helps the refrigerator/freezer door pivot smoothly and maintain proper alignment. Replacing a worn bushing restores quieter operation and reduces door binding or uneven closing. What it does:

• Provides a low-friction surface for the door hinge pin to rotate against
• Helps keep the door aligned and prevents sagging or uneven gaps
• Reduces squeaks, sticking, or rough movement at the hinge
• Works at the hinge location where the bushing sleeve fits over the pin

• Unplug the appliance or disconnect power before starting work
• Support the door when removing hinge fasteners to prevent sudden movement or injury
• Basic hand tools are typically all that's needed; follow OEM instructions for your model

This duct door assembly replaces the vent door that covers the dryer exhaust opening, helping direct airflow and keeping the vent closed when the dryer is off. Restores proper vent sealing and prevents drafts or pests. What it does:

• Replaces a broken, bent or stuck vent door that won't open or close smoothly
• Helps ensure exhaust air exits the dryer housing instead of leaking into the cabinet
• Reduces drafts and keeps out dust or small pests when the dryer is idle
• Stops rattling caused by a loose or damaged duct door

• Disconnect power (and gas supply if applicable) before servicing the appliance.
• Access may require removing the dryer's rear or top panel—keep track of fasteners.
• Handle trim and door edges carefully to avoid bending; align hinges before tightening.

The Motor Duct Door is an OEM part for GE refrigerators. It is the cover that houses the evaporator fan motor and ductwork in the refrigerator. The motor and ductwork circulate cold air throughout the unit to maintain even temperatures for food storage.

Causes of a bad motor duct door can include failed seals that compromise cooling performance or damage to the door and hinges that prevent proper opening and closing.

Symptoms of a bad motor duct door include:

• Warm or lukewarm air inside the refrigerator sections
• Improper airflow causes warmer or colder spots
• Difficulty opening or closing the duct door

Replacing with this genuine GE OEM part allows for optimal air circulation throughout the refrigerator. This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This spring duct door is a replacement spring that helps the duct/vent door open and close properly, restoring correct airflow control and reducing unwanted drafts. What it does:

• Provides tension to the vent/duct door so it opens and closes reliably
• Helps prevent the door from sticking open or closed, improving airflow performance
• Restores proper damper action that keeps unwanted drafts and moisture out when the appliance is idle
• Supports normal operation of the vent/duct assembly without modifying other components

• Designed to install in the duct/vent door assembly; follow the appliance service manual for access steps
• Disconnect power (and gas if applicable) and ensure the appliance is cool before servicing
• Use proper tools and retain all fasteners; verify correct spring orientation before reassembly

The Water Valve is an OEM component for GE side-by-side refrigerators. Located internally within the water dispenser assembly, this valve controls water flow to the ice maker and dispenser.

Causes of a faulty water valve can include mineral buildup restricting flow over time, gasket wear from constant opening/closing, and electrical faults impacting the valve's solenoid.

Symptoms requiring replacement are:

• Slow or inconsistent water flow from the dispenser
• The ice maker fails to fill or produces irregular cubes
• Water leaking into areas it should not reach

This OEM GE part fits additional appliances under the same household brand family such as Hotpoint, RCA, and comparable Kenmore models.

The Switch Paddle Assembly is an OEM component specifically designed for GE side-by-side refrigerators. This assembly consists of the control switch and controls access for various refrigerator features and functions.

Causes of a bad switch paddle assembly can include repeated use over time, unintended impacts, liquid spills inside the fridge, or damage to internal wiring/electronics.

Symptoms of a bad switch paddle assembly include:

• Faulty or unresponsive control switches
• Lights or compartments not functioning properly
• The control panel displaying error codes
• Internal refrigerator components running unexpectedly

Replace this assembly to restore full functionality to your refrigerator’s control center. This genuine GE OEM part ensures dependable access to cooling, dispensing, and other common settings. It is compatible with Hotpoint, RCA, and some Kenmore models as well.

A replacement collar gasket — a small rubber sealing ring that restores a secure, watertight seal at the collar connection. Replaces worn or damaged gaskets to help stop leaks and restore normal sealing performance. What it does:

• Seals the collar connection to prevent water leaks and pooling.
• Helps stop moisture intrusion that can cause corrosion or staining around the connection.
• Restores proper sealing when the original gasket is cracked, flattened, or missing.
• Supports a snug fit between mating parts to reduce drip or seepage at the joint.

• Turn off power to the appliance and shut off the water supply before beginning any repair.
• Remove the old gasket and clean the mating surfaces of any debris or residue before installing the new gasket.
• Press the new gasket fully into the collar groove until it seats evenly; there are no twists or gaps.
• After reinstalling components, restore power and water, then check carefully for leaks.

This port gasket seals the port opening to prevent air and moisture exchange and help maintain proper refrigerator/freezer temperatures. Durable material provides a tight seal to support efficient cooling and help reduce frost buildup. What it does

• Forms a protective seal around the port to reduce air leaks and moisture intrusion
• Helps maintain consistent internal temperatures and can reduce frost accumulation near the port
• Minimizes energy loss caused by gaps or worn seals
• Supports proper operation of components behind the port by keeping the area sealed

• Disconnect power to the appliance before inspecting or replacing the gasket
• Remove the old gasket carefully to avoid damaging surrounding trim or components
• Align the replacement gasket and press into place; ensure a continuous, even seal

The Handle is an OEM part for GE refrigerators. It allows for easy opening and closing of the door. This handle is designed to provide a sturdy grip, making it convenient to access your food items.

A bad handle can be caused by wear and tear over time, excessive force applied to the handle, or damage due to accidental impact or mishandling.

Symptoms of a bad drawer handle include:

• Difficulty in opening or closing the door.
• Loose or wobbly handle.
• Cracks or breaks in the handle.

Replace your worn-out or damaged handle with this OEM part and restore your refrigerator. This GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.


This cold water tank is the refrigerated reservoir that stores and supplies chilled water to the dispenser/ice system, restoring normal cold-water delivery and helping maintain consistent dispenser performance. What it does:

• Holds chilled water delivered from the refrigerator's cooling system for the dispenser/ice system
• Re-establishes chilled water availability when a cracked or damaged tank causes loss of cold-water supply
• Can stop leaks or pooling caused by a failing or cracked reservoir
• Helps resolve weak or no cold-water dispense when the tank is the damaged component

• One cold water tank

• Turn off power to the appliance and shut off the water supply before starting
• Drain remaining water from the system to avoid spills when removing the old tank
• Handle the tank carefully to avoid damage to fittings and mounting tabs
• Follow the refrigerator's service manual for disassembly/reassembly and routing of inlet/outlet fittings

The Dispenser Door Bin is an OEM part for GE refrigerators. It is designed to hold and organize items within the refrigerator door, providing additional storage space and easy access to frequently used items.

Common causes of a bad door bin include regular wear and tear from repeated use, accidental impacts that cause cracks or breakage, and exposure to heavy loads that can stress the plastic material.

Symptoms of a bad door bin include:

• Cracks or breakage in the bin
•  The bin not sitting securely in the door
• Difficulty in opening or closing the refrigerator door due to the bin's instability

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

Replace a cracked or missing middle bin on the dispenser-side refrigerator door. This bin restores secure, organized storage for bottles and condiments so items stay accessible and the door can close properly.

• Mounts on the dispenser-side fresh food door in the middle position
• Holds bottles, jars, and small containers to maximize door storage
• Helps keep items stable when opening and closing the door
• Common replacement signs: cracked/chipped bin, won't stay seated on door tabs, or missing

• Remove contents; lift the old bin up and off the door tabs, then align and snap the new bin into place
• Bins are position-specific; use this part only for the middle spot on the dispenser-side door
• Do not force the bin; ensure both tabs are fully engaged before loading items

This ice box door assembly restores a damaged or worn freezer/ice compartment door so the compartment seals and cools correctly. It replaces the entire ice box door to help stop cold-air loss and protect stored frozen items. What it does:

• Replaces a cracked, dented or broken ice box/freezer door
• Restores a proper seal to reduce frost buildup and temperature fluctuations
• Helps stop cold air from escaping, improving cooling performance
• Prevents food from being exposed to warm air and moisture

• Disconnect power to the appliance before starting any repair.
• Remove all contents from the compartment and support the door during removal and installation.
• Installation requires basic hand tools; handle glass or painted surfaces carefully to avoid damage.
• If seals or mounting hardware are worn, inspect and replace separately for best performance.

This HMI Main Board is the user-interface control board that operates the appliance's display, touchpad/buttons, and dispenser/selector functions. Replaces a failing interface to restore responsive controls and visible status indicators. What it does

• Receives input from the touchpad/buttons and runs the display and status lights
• Sends commands to the appliance control system for dispenser, temperature display, and user selections
• Commonly used when the display is blank, buttons or touchpad don't respond, or front-panel indicators act erratically
• Works as the interface between the user and the main control circuitry

• One HMI main board (control/display assembly)

• Disconnect power to the appliance before beginning any repair to avoid shock or damage
• Handle board by the edges and avoid touching components; use ESD protection if available
• Note wire and connector locations before removal; reinstall connectors fully and secure mounting hardware

Specs: 8-18 AB IHW 5/8 S

This is a replacement spring paddle that helps operate the dispenser actuator, restoring reliable dispense control and a responsive paddle feel. Replaces worn or broken paddles so the dispenser starts and stops correctly. What it does

• Provides the return force and contact surface for the dispenser actuator
• Helps the dispenser arm snap back after use to prevent continuous dispensing
• Restores normal user feel when pressing the dispenser paddle
• Commonly replaced when the paddle is loose, cracked, or fails to return

• One spring paddle

• High-level, vehicle-agnostic replacement — often accessed from the dispenser assembly inside the refrigerator door
• Remove power to the appliance before servicing to avoid electrical hazards
• Handle small plastic parts carefully to avoid breaking tabs; check surrounding components for wear
