Parts for Kitchenaid KRFC400ESS01: 09 - Dispenser Front Parts

A replacement chute extension yoke that guides laundry into the appliance's drum and helps maintain proper material flow. Restores alignment for consistent loading and prevents fabric jams caused by a misaligned chute. What it does:

• Re-establishes the chute path so items feed smoothly into the drum or tub
• Helps prevent clothes from catching or bunching at the entry point
• Maintains correct alignment between the cabinet opening and internal chute
• Reduces noise and wear caused by a loose or damaged chute connection

• One chute extension yoke

• Intended for direct replacement; compare part visually before installing
• Turn off and unplug the appliance before beginning any service
• Minor disassembly of the cabinet or top may be required—use basic hand tools

This chute extension yoke is a molded replacement part that secures and guides the chute opening, restoring proper alignment and part fit so items move smoothly through the appliance. It replaces a damaged, cracked, or broken yoke to reduce snagging and rattling. What it does:

• Secures the chute assembly and maintains correct chute alignment
• Guides garments and items into the cabinet opening without catching
• Prevents loose or vibrating chute pieces that can cause noise
• Restores structural support where the original yoke is cracked or worn

• One chute extension yoke assembly

• Disconnect power (and water if applicable) before beginning any repair
• Basic hand tools are typically required; refer to your service manual for disassembly steps
• Inspect surrounding chute and seals and replace any damaged hardware for best fit

This chute extension yoke supports and pivots the refrigerator dispenser's chute extension so ice is directed cleanly into your glass. Replace a cracked or worn yoke to restore smooth extension action and consistent dispensing. What it does:

• Supports and pivots the dispenser's chute extension/funnel
• Keeps the chute aligned to guide ice into the container
• Helps the extension deploy and retract smoothly when dispensing
• Failure signs: loose or broken chute extension, misdirected ice, sticking or uneven movement, visible damage to the yoke

• One chute extension yoke

• Disconnect power to the refrigerator before servicing
• Remove the dispenser trim/front panel to access the chute extension
• Note spring and hardware orientation; transfer any reusable parts to the new yoke
• Reassemble carefully and test the dispenser for smooth operation

This replacement screw secures specified refrigerator components—such as covers, brackets, and internal panels—so they stay properly mounted. Replace a missing, stripped, or corroded fastener to restore a tight, rattle-free fit and reliable operation.

• Provides the correct fastener for locations identified in your model's parts diagram
• Helps prevent looseness, vibration, and rattling of panels or brackets
• Replace if the head is stripped, threads are worn, or the screw is missing
• Symptoms can include loose parts, gaps, or noises from movement

• Unplug the refrigerator and shut off water if working near the ice maker or dispenser
• Match length and type to the original; follow your model's parts diagram for placement
• Start threads by hand to avoid cross-threading; tighten snugly without over-torquing, especially into plastic
• Keep track of screw positions; do not mix different screw lengths or styles

This target ring is a small trim piece that restores the original fit and appearance around a control button or panel opening. Replacing a damaged ring helps ensure clean button engagement and a finished look. What it does:

• Serves as the trim/target around a control button or panel opening
• Keeps the button aligned for consistent engagement and operation
• Restores finished appearance when the original ring is cracked, warped, or missing
• Prevents debris from collecting around the control area

• One replacement target ring

• Disconnect the appliance from power before attempting replacement
• Usually installs by snapping into place or securing with retained fasteners — handle gently to avoid breaking tabs
• Confirm proper button movement and secure fit before returning appliance to service

This yoke and pad assembly connects the dispenser auger motor to the ice bucket auger. Replacing a stripped yoke or worn pad restores torque transfer for smooth, reliable ice dispensing with reduced slipping and noise.

• Connects the auger motor shaft to the ice bucket auger
• Transfers drive torque through a cushioned pad to move ice out of the bin
• Helps reduce shock and slippage in the dispenser drive
• Common symptoms: ice won't dispense, auger doesn't turn, clicking/grinding during dispense

• Disconnect power and remove the ice bin to access the dispenser drive
• Support the auger motor to protect wiring; remove the retaining fastener and the old yoke/pad
• Install the new assembly on the motor shaft; align fully and tighten in the same orientation as the original
• Reassemble components, restore power, and test ice dispensing

The Ice Chute Door Spring is an OEM part for Whirlpool refrigerators. This part returns the ice chute door to its closed position after ice has been dispensed, ensuring the door remains sealed to maintain proper temperature and efficiency.

Causes of a bad ice chute door spring can include wear and tear over time, corrosion from exposure to moisture, or damage due to repeated use or mishandling.

Symptoms of a bad ice chute door spring include:

• The ice chute door not closing properly
• Ice or frost buildup around the ice chute
• Warm air entering the freezer compartment
• Difficulty in dispensing ice

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.
