Parts for Bosch HEI7152U/01: Door Parts

This genuine replacement part is a hob top, which is the cooktop of a stove. The hob top is the main top piece of the stove where the burners are located. Replacing a hob top is a relatively simple process.First, make sure to unplug the range. Have a screwdriver readily available. To replace the cooktop, locate the screws found underneath the range. Unthread the screws, and put them off to the side. Then push up on the cooktop to loosen it from the range. Lift it off the stove and set it aside. Install the new hob top on top of the stove and fasten the screws underneath to resecure the new cooktop.This OEM hob top is sold individually and is compatible with Bosch, Gaggenau, and Thermador stoves.

Oven not heating or baking unevenly? This range heating element restores consistent cooking temperature. Straightforward repair for most DIYers.

Oven not heating or baking unevenly? This range heating element restores proper temperature. Common DIY repair that takes 30-45 minutes with basic tools.

This replacement heating element warms the air inside an electric dryer so clothes dry efficiently. Use it to restore normal heating when the dryer runs but does not produce sufficient heat. What it does:

• Heats incoming air that circulates through the dryer drum to evaporate moisture
• Commonly used when the dryer runs but produces little or no heat
• Works with the dryer's internal blower and venting to maintain normal drying cycles
• Should be checked alongside thermal fuses and thermostats when diagnosing heating problems

• One heating element assembly

• Disconnect power at the circuit breaker before accessing the heater assembly; this part can be connected to high voltage
• Replacement typically requires access to the dryer's rear or lower front panel and basic hand tools
• Avoid touching element terminals or sharp sheet-metal edges; follow OEM instructions for secure electrical and mounting connections
• If the dryer still doesn't heat after installation, test or replace related components (thermal fuse, high-limit thermostat, wiring) as needed

This is a replacement oven control board manufactured by Bosch. The oven control board is the oven's brain and handles all the functions. It also includes the display and provides users with the ability to control functionality, like bake and broil, setting timers, and more. While the oven control board does not include moving parts, heat and moisture can damage soldered components and lead to failure. Signs that the control board may need to be replaced include lack of information on the display, inability to control specific functions, or complete lack of operability. Note that this part is often misdiagnosed, so make sure to check the old board's operability with a multimeter before replacing it. To replace the oven control board, first remove the exterior cowling. Locate the wiring harness and disconnect it before removing the mounting screws. Install the replacement part following these steps in reverse.This genuine OEM part is sold individually. It only fits Bosch Thermador ovens.

This pushbutton switch controls power to the appliance circuit. When pressed, it opens or closes the electrical path to turn the function on or off, restoring reliable button response and consistent operation.

• Controls on/off power for the selected function
• Worn or stuck switch can cause no response when pressing the button
• Intermittent, delayed, or stuck-on operation may indicate switch failure
• Physical damage or heat discoloration on terminals are common failure signs

• Disconnect power before service to avoid electrical shock
• Note wire positions or photograph connections before removal
• Transfer wires firmly to the new switch; ensure terminals are fully seated
• Test function before reassembling panels

If your range controls aren't responding or the heating element won't turn on, this push-button switch restores reliable front-panel operation.

Replacement glass panel for range oven doors. Installs on the inner or outer door assembly. Order when your original glass is cracked, shattered, or broken.

This sealing ring creates a watertight seal in the dishwasher pump/motor area to help prevent leaks and protect the motor assembly. It's a small but essential replacement for worn or damaged seals. What it does:

• Seals pump housing joints to stop water leaks beneath the dishwasher
• Helps maintain proper water pressure and circulation for cleaning performance
• Prevents water from reaching the motor and electronics, reducing risk of damage
• Replaces brittle, cracked, or flattened seals that commonly cause under-unit leaks

• One sealing ring

• Turn off power and water to the appliance before starting any repair
• Inspect mating surfaces and clean away debris or buildup before installing the new ring
• Lubricate the seal lightly with OEM-recommended lubricant or a thin film of water if needed to ease installation
• If multiple seals or gaskets show wear, replace them together to ensure a complete seal.

Replace your worn, cracked, or missing range oven control knob. Restores smooth temperature selection and cooking function control with a precise fit.

Fix range control issues or power problems with this cable harness. Common fix for unresponsive controls or electrical faults. Moderate DIY repair.

This cable harness routes power and signals between electrical components to restore reliable connections and proper operation. It replaces a damaged or worn wiring assembly so your appliance can receive power and communicate between modules. What it does:

• Carries power and control signals between components
• Restores intermittent or lost electrical connections caused by frayed or broken wires
• Helps eliminate symptoms like no power to a module, intermittent operation, or failed cycles
• Maintains proper routing and strain relief to prevent shorts or connector damage

• Always disconnect the appliance from power before beginning any service
• Note connector locations and wire routing before removal; take photos if needed
• Reconnect all terminals firmly and secure the harness with any factory clips or fasteners

Oven door sealing strip creates airtight seal for efficient heating. Replace if worn, cracked, or oven struggles to maintain temperature. Verify fit.

Decorative trim plate for ranges. Installs around controls or edges to cover gaps and provide a finished look. Replace if cracked, chipped, or missing.

Fix an oven door stuck closed after a cleaning cycle or error code 41. This door latch assembly restores normal lock/unlock operation on gas ranges.

The Convection Fan Motor is an OEM component specifically designed for Bosch combination and convection steam oven ranges. Located within the oven cavity, it powers the convection fan and circulation of hot air.

Symptoms of a bad convection motor include:

• Failure to achieve even heat distribution within the oven
• Loud grinding noises or vibrations from the fan
• Inability to select convection cooking modes
• Burning smells indicating possible overheating

Causes of failure may involve normal wear over extended use. Blocked ventilation from food debris could overload the motor. Accidental liquid spillage presents corrosion risks.

Replacing with this genuine Bosch motor restores essential airflow. Compatible with 500 series models, it features a permanently lubricated design for durable performance. Backed by Bosch quality, this convection replacement ensures reliable cooking for years to come. It is also compatible with Thermador and Gaggenau ranges.


Catalyzer component for electric ovens and ranges. Installs inside the oven cavity. Order a replacement if your catalyzer is cracked, damaged, or missing.

Fix intermittent power or component failure with this range socket electrical connector. Restores secure wiring connections in electric and gas ranges.

The Oven Light Switch is an OEM part for Bosch ranges. It engages convenient interior illumination through a single motion, allowing monitoring of baked goods without compromising temps.

Causes of a bad oven light switch can include failures from the natural stresses of constant clicking associated with opening and closing the oven door.

Symptoms of a bad oven light switch include:

• Dim or unresponsive lights even when the door is opened properly
• Inability to turn lights off, leaving them burning needlessly
• Stuck in either the on or off position without toggle functionality
• Potentially hazardous exposed live terminals under switch housings

This OEM Bosch part can also be used on Thermador and Gaggenau appliances.

This dishwasher water sensor monitors wash-water conditions so the control can adjust cycle time, rinses, and heating for consistent performance. Replace a failed sensor to restore reliable cleaning results and proper automatic cycle adjustments. What it does

• Detects water conditions during the wash cycle and reports to the control
• Helps the dishwasher optimize cycle length, rinses, and energy use
• Common symptoms: unusually long or short cycles, inconsistent cleaning, or sensor-related error messages
• Trigger erratic cycle behavior when the sensor is faulty or contaminated

• One sensor assembly

• Disconnect power and turn off water before servicing
• Access is typically from the underside; place a towel or pan to catch residual water
• Transfer/seat the seal properly if present; fully engage the locking tabs and reconnect the harness
• After installation, run a quick cycle and check for leaks and proper operation

The Sensor is an OEM part for Bosch ovens and ranges. It detects and monitors the actual interior temperature to maintain precise baking and roasting conditions.

Causes of a bad temperature sensor can include wear from prolonged heat exposure within the oven cavity. Physical damage, moisture intrusion or circuitry malfunctions may also lead to sensor failure over time.

Symptoms of a bad oven temperature sensor include:

• Inability to accurately read or achieve set target temperatures
• Fluctuations in readings displayed
• Cooking modes like bake and broil functioning abnormally

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

This heating element is the direct-replacement heater assembly that provides the heat source for compatible appliances, restoring proper heating so cycles reach the temperatures needed for effective drying or cleaning. What it does:

• Generates heat for the appliance's thermal system (air or water heating depending on model).
• Replaces a failed or damaged heater element to restore normal temperature rise.
• Common symptoms it may fix: no heat, weak/no drying or cleaning performance, or unusually long cycles.
• Works as part of the appliance's safety and temperature-control circuit (thermostats or sensors may also be involved).

• Always disconnect power (and water, if applicable) before replacing the element.
• Allow the appliance to cool fully and wear protective gloves; heating elements can have sharp edges.
• After installation, restore power and run a short test cycle to check for any error codes.

Restore even baking when your oven heats unevenly. This convection fan blade circulates hot air for consistent cooking. Moderate DIY install.

Restore oven visibility with this complete light assembly. Replace when bulb won't light, lens is cracked, or socket is damaged. Verify fit with your model.

This grille for pan is a replacement trim piece that restores proper airflow and appearance around the appliance pan. It helps keep the pan area protected and looking finished after repair. What it does:

• Covers and ventilates the pan opening to help direct airflow and prevent debris entry
• Replaces a cracked, warped, or missing grille to restore fit and finish
• Helps eliminate rattling or rubbing caused by a damaged trim piece
• Matches OEM fit so it installs cleanly with the original mounting points

• Install requires removal of the surrounding trim or access panel; follow your appliance manual
• Handle carefully to avoid scratching the finish; use non-marring tools as needed
• Disconnect power to the appliance before working in the service area
• Replace damaged clips or screws with OEM fasteners for secure fit

This wire shelf provides a stable, ventilated storage surface inside the refrigerator to organize food and improve airflow for even cooling. It replaces a damaged, bent or missing shelf to restore usable interior storage space. What it does:

• Replaces a bent, rusted or broken refrigerator wire shelf that no longer supports items safely
• Restores flat, secure storage for food containers, bottles and produce
• Helps maintain proper air circulation in the compartment for more consistent cooling
• Fits into existing shelf tracks or supports designed for factory wire shelves

• One replacement wire shelf

• Slide shelf into existing tracks/supports; no tools typically required for drop-in style shelves
• Handle carefully to avoid sharp wire ends; wear gloves if needed
• Only replace with the correct part number for secure fit and safe operation

Range overheating or shutting down unexpectedly? This cooling fan circulates air to maintain stable temperatures and protect internal components.

This Terminal Box is an OEM part for Bosch Built-In Ovens. Integral to the oven's electrical system, this component serves as a secure connection point for various electrical wires within the appliance.

A common issue with a malfunctioning Terminal Box is loose connections or damage to the terminal block due to heat exposure or aging.

Symptoms of a defective Terminal Box may include:

• Inconsistent power supply to the oven
• Non-functional heating elements
• Sparks or electrical arcing within the terminal box area

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

The range door hinge plate is the metal bracket that anchors your oven door to the range frame and controls how the door opens and closes. It supports the full weight of the door and keeps it properly aligned. Replace this part if your oven door sags, won't stay open at a set angle, closes unevenly, or feels loose on one side.

Leveling foot for electric and gas ranges. Adjustable metal foot installs at base corner. Replace if cracked, broken, or missing to level your range.

Secures internal components and panels to restore proper alignment in your range. Replace when bracket is broken, cracked, or missing to fix loose parts.

Secures your range door and allows smooth pivoting for proper alignment and seal. Replace if your door won't close fully, sags, or doesn't seat correctly.

Restores smooth rack gliding in your oven. Replace when racks stick, scrape, or don't extend fully. Confirm fit with your model number before ordering.

Replacement storage drawer for gas ranges. Restores under-appliance space and smooth sliding. Replaces cracked, broken, or worn drawers.

This inner door is the dishwasher's inner panel that supports the door assembly and helps contain water and steam during cycles, restoring a secure, finished door surface. It replaces damaged or corroded inner door panels to improve sealing and appearance. What it does:

• Serves as the interior face of the dishwasher door and provides structural support for inner components
• Helps maintain a watertight seal and prevents leaks from the door area
• Replaces dented, cracked, or corroded inner panels that can trap moisture or cause cosmetic damage
• Restores proper alignment so the door closes and latches correctly

• 1 inner door panel

• Disconnect power and water supply before starting any repair
• Handle panel edges carefully; use gloves to avoid cuts and protect finish
• Installation typically requires removing the outer door panel and disconnecting inner fasteners—keep hardware organized for reassembly

This part is a replacement fixing kit and is a genuine OEM part manufactured by Bosch. This part has been sourced directly from the manufacturer and is intended to repair a broken or faulty door in a variety of different oven models. This fixing kit includes both of the door hinges that are necessary for repairing the oven door. These hinges are necessary for the user to control the opening rate of the door, as well as allow the door to remain ajar at an angle. When undergoing any repair work, make sure to always disconnect the power and gas supplies from the oven. It is highly recommended that work gloves are worn to for proper protection.This is an authentic replacement part and thus is suitable for use on several different models of ovens that have been manufactured by Bosch, Thermador, Gaggenau, and some other brands.

This part is a replacement fixing kit and is a genuine OEM part manufactured by Bosch. This part has been sourced directly from the manufacturer and is intended to repair a broken or faulty door in a variety of different oven models. This fixing kit includes both of the door hinges that are necessary for repairing the oven door. These hinges are necessary for the user to control the opening rate of the door, as well as allow the door to remain ajar at an angle. When undergoing any repair work, make sure to always disconnect the power and gas supplies from the oven. It is highly recommended that work gloves are worn to for proper protection.This is an authentic replacement part and thus is suitable for use on several different models of ovens that have been manufactured by Bosch, Thermador, Gaggenau, and some other brands.

This glass front panel is the exterior replacement glass that restores the appliance's finished look and protects the underlying door and control area from scratches and wear. It fits into the door assembly to provide a clean, glossy surface. What it does:

• Replaces cracked, chipped, or heavily scratched front/door glass to restore appearance
• Protects internal components and trim from direct contact and debris
• Helps keep the door surface smooth and easy to clean
• Restores a secure fit when broken or loose glass affects the door finish

• One glass front panel

• Disconnect power to the appliance before starting any repair
• Handle glass with gloves and protective eyewear to avoid cuts
• Installation typically requires removing the door trim or bezel—follow the OEM service instructions for your model

This insulating part provides electrical and thermal isolation for internal appliance components, helping prevent shorting and reducing heat transfer where wiring or terminals meet sensitive parts. Use it to restore safe operation after damage or wear. What it does:

• Provides electrical insulation for terminals, connectors, or wiring to prevent shorts and arcing
• Reduces heat transfer between hot components and nearby wiring or plastic parts
• Helps maintain safe clearances and protects against chafing or contact-related failures
• Commonly replaced when cracked, melted, burned, or otherwise compromised

• One insulating part

• Always disconnect power (unplug appliance or switch off breaker) before servicing
• Verify correct orientation and seating; do not force the part into place
• Inspect surrounding wiring and terminals; replace any damaged connectors or wires

Replace a damaged heat shield causing nearby components to overheat or melt. This protective panel restores the heat barrier on your gas range.

Decorative strip for your range door or drawer handle. Replace if the original is cracked, discolored, or missing to restore your appliance's appearance.
