Parts for Ge ZDP304LP7SS: Door Parts

This small set screw secures components inside your refrigerator. Replacing a missing or stripped set screw restores a tight, reliable hold so attached parts stay aligned and are less likely to loosen or rattle during use.

• Fastens an attached part to its mounting point to prevent movement or slipping
• Helps maintain proper alignment of handles, brackets, or trim pieces
• Reduces wobble, vibration, and rattling noises caused by loose hardware
• Replaces missing, stripped, or corroded set screws

• Unplug the refrigerator and shut off water if working near door/dispenser areas
• Support the part being secured; start the screw by hand to avoid cross-threading
• Tighten with the correct driver for your model; do not overtighten to prevent stripping
• The component is secure and aligned before restoring power

This small end cap fits the end of an extension piece to act as a stop and finish. It restores a secure, finished edge so the sliding component or trim stays aligned and doesn't over-travel during use.

• Caps the end of an extension rail or trim to prevent over-travel and pullout
• Keeps the assembly aligned to reduce wobble
• Replaces cracked, missing, or worn caps
• Helps eliminate rattling and exposed edges

• Disconnect power and allow all hot surfaces to cool before servicing
• Access the end of the extension/rail; release any locking tab and remove the old cap
• Align and snap or press the new cap into place
• Verify smooth travel and a secure stop after installation

This top door insulation is the molded thermal insert that fits behind the door liner to help the appliance maintain proper temperatures and reduce cold-air loss. It replaces damaged or compressed insulation for better performance. What it does:

• Restores the insulated cavity behind the top door liner to help retain cold air
• Helps reduce unnecessary compressor cycling caused by heat gain
• Can limit moisture buildup that leads to frost or icing near the door
• Maintains a proper seal and fit when the door liner is reinstalled

• One top door insulation piece

• Disconnect power to the appliance before starting any repair
• Remove the door liner/trim and any retained clips or adhesive to access the insulation
• Handle the insulation carefully—avoid tearing the foam or vapor barrier
• Reinstall the liner and hardware securely; verify door closes and seals properly

This bottom door insulation panel helps keep cold air inside the freezer door cavity to maintain temperature and improve efficiency. It replaces torn, compressed, or missing insulation to reduce frost build-up and uneven cooling. What it does

• Fills the bottom section of the freezer door cavity to help retain cold air and stabilize internal temperature.
• Restores the factory insulation barrier that prevents warm air intrusion and reduces frost accumulation.
• Helps improve overall cooling performance when damaged or missing insulation causes temperature or frost issues.
• Works with the door liner and gasket to maintain a proper sealed environment.

• One bottom door insulation panel

• Disconnect power and empty food from the door/freezer section before starting.
• Remove the door or inner liner per your model's service instructions to access the insulation pocket.
• Handle carefully to avoid tearing the insulation; secure with the original clips/fasteners or new hardware if required.

The Door Hinge (Right) is an OEM part for GE gas ranges. It acts as the pivot point allowing the right side of the range door to smoothly and securely open and close.

Causes include normal wear and tear from repeated use, accidental impacts deforming the hinge, or deterioration of spring components.

Symptoms of a bad right door hinge include:

• Resistance felt only when opening/closing the right side of the door
• Noise, rubbing or squeaking coming from the right hinge area
• Visual bending or damage evident on the hinge itself
• Improper alignment of just the right side causing sealing issues

This OEM replacement is compatible with Hotpoint, RCA, and select Kenmore gas range models.

The Door Hinge (Left) is an OEM part for GE gas ranges. This hinge is responsible for securely and smoothly mounting the oven door to allow easy access to the cooking cavity.

Causes of a bad hinge include normal wear and tear from years of opening and closing the heavy oven door. The repeated motion can cause hinge mechanisms to loosen, fail to properly support the door weight, or become misaligned over time.

Symptoms of a bad hinge (left) include:

• The oven door sagging or unable to stay open on its own
• Difficulty smoothly opening and closing the door
• Noisy or gritty motion from the hinge when in use
• Improper alignment that impacts sealing of the door

This genuine GE replacement hinge is compatible with some Hotpoint and RCA models as well.

This replacement screw secures appliance components so panels, brackets, and trim stay tight and aligned. Use it to replace a missing, stripped, or rusted fastener and restore a solid, rattle-free fit in the affected assembly.

• Fastens parts to the chassis/frame or mounting brackets
• Replaces lost, damaged, or corroded hardware
• Can help address loose or vibrating panels and minor misalignment
• Maintains a secure attachment during normal operation

• Disconnect power before servicing; for gas appliances, also shut off the gas supply
• Match the screw to the original location and reuse any clips or washers if present
• Start threading by hand to avoid cross-threading; tighten snugly without overtightening
• Repair/replace damaged receiving threads or clip for proper hold

This door gasket is the replacement sealing strip that fits around an oven door to help keep heat and moisture inside for more even cooking and energy efficiency. It restores the oven's seal and reduces heat loss during use. What it does:

• Seals the gap between the oven door and cabinet to help maintain cooking temperature
• Helps reduce heat and moisture escaping into the kitchen
• Can improve bake/roast performance when a worn gasket allows leaks
• Common symptom: visible gaps, torn/compressed rubber, or oven failing to hold temperature

• One door gasket

• High-level replacement: remove oven door or access clips/retainer, pull out old gasket, and press new gasket into the retainer channel
• Use gloves to protect your hands; allow the oven to cool completely before starting
• Check gasket orientation and that it seats evenly around the full perimeter for a proper seal
