Parts for Lg DLEX8100V: Drawer Panel And Guide Parts

This water tank assembly holds and delivers chilled water to the dispenser and ice system, restoring proper water flow and preventing dispenser dry-running. Direct-fit replacement designed to match the original reservoir's form and function. What it does

• Stores and supplies water for the refrigerator dispenser and ice-making components.
• Replaces cracked or damaged reservoirs that cause leaks or loss of water supply.
• Helps resolve intermittent or no-water dispense when the tank is compromised.
• Works with the refrigerator's fill and drain pathways to maintain correct water levels.

• One water tank assembly

• Disconnect power and shut off the water supply before servicing.
• Drain remaining water from the lines and tank to avoid spills during removal.
• Handle the tank carefully to avoid damaging fittings or mounting tabs.
• After installation, restore water and power, then check connections and test for leaks and proper dispense/ice fill.

This Drawer Panel Assembly replaces a worn, cracked, or faded front panel to restore the appliance's appearance and provide a secure drawer face. It matches factory fit and finishes for a clean, finished look on compatible units. What it does:

• Replaces the exterior front face of a drawer, restoring cosmetic appearance and protecting the drawer frame.
• Provides mounting surface and alignment for the drawer closure and trim.
• Helps stop drafts or light leaks caused by damaged or warped panels.
• Common symptom: visible cracking, chipping, discoloration, or loose/warped drawer front.

• Disconnect power to the appliance before starting work and remove stored items from the drawer.
• Basic hand tools are usually required; handle painted or plated surfaces carefully to avoid scratches.
• Follow OEM service instructions for proper alignment and fastener torque; verify clips and brackets are correctly engaged.

This dryer guide cover cap installs on the drum or guide assembly. Replace if your original cover is cracked, broken, missing, or worn from regular use.

Sound dampening insulation that reduces dryer noise and vibration. Replace if worn, torn, or missing to restore quiet operation and cushioning.

Fix a dryer that won't produce steam or has weak steam output. This steam generator assembly heats water to create steam for steam-enabled cycles.

The DC pump motor assembly powers the pump that moves water through your appliance. Replacing a worn motor helps restore proper water flow so cycles can complete and reduces issues like standing water and excessive noise.

• Drives the pump impeller to move water for draining or circulation, as designed by the appliance
• Supports proper cycle completion by clearing water from the tub or sump
• Common symptoms of a failing motor include standing water, incomplete draining/circulation, loud humming or grinding near the pump, or cycle errors
• May run intermittently, stall, or overheat as internal components wear

• Disconnect power and turn off the water supply before servicing
• Expect residual water; protect the area with towels or a shallow pan
• Note wiring connectors and hose routing; transfer any brackets, grommets, or seals from the original as needed
• Secure hose clamps and test for leaks while running a brief test cycle

The Clamp is an OEM part for LG washing machines. It is used to secure the hose connections within the washer, ensuring that water flows correctly without leaks.

Over time, the clamp can become worn or damaged due to repeated exposure to water, vibration, or general wear and tear. If the clamp fails, it can lead to water leaks or hoses becoming detached.

Symptoms of a bad clamp include:

• Water leaking from hose connections
• Hoses coming loose or detaching during operation
• Visible rust or damage on the clamp
• Poor water flow or pressure issues

This OEM LG part is also compatible with Sears/Kenmore models.
