Parts for Ge JKD3000DN4WW: Flat Badge Asm Parts

Decorative badge assembly that mounts on the front of your range. Displays brand and model information. Replace if cracked, peeling, or missing.

This oven door liner is the inner metal panel that forms the inside surface of the oven door, restoring structural support and the finished interior appearance. Replaces a damaged or warped liner to help the door seal and support the inner glass. What it does:

• Provides the interior surface and structural backing for the oven door and inner glass
• Restores proper alignment and support when liner is dented, cracked, or bent
• Helps maintain the door's sealing surface to reduce heat loss and maintain cooking performance
• Prevents contact between the inner glass and insulation or components

• Disconnect power to the appliance before starting and allow all surfaces to cool completely
• Handle glass and metal edges with care; wear gloves and eye protection
• Installation typically requires removing the oven door and inner glass; follow the oven manufacturer's instructions

Secures cabinet liner and interior trim panels in wall ovens. Replace if cracked or loose to restore proper alignment and prevent gaps. Confirm fit with your model.

Covers fastener holes in your oven's inner door liner for a clean finish. Replace when missing, loose, or damaged to keep grease out. Confirm fit with your model.

Right-hand door hinge for electric wall ovens. Mounts to the oven cavity and door frame to support smooth opening and closing. Replace if cracked or worn.

Replace a broken or worn left door hinge on your wall oven. Installs on the left side of the oven door frame to support proper door alignment.

Oven door window pack assembly includes glass pane and frame for viewing food while cooking. Replace if cracked, shattered, or broken from heat damage.

ST10-16 X 7/16"

Black. 8-18 AB HXW 3/8

Hex head machine screw with 10-32 thread, 1-3/4 inches long. Secures brackets, panels, and internal oven components. Replace missing or stripped screws.

10-32 machine screw secures panels, brackets, door hinges, and handles in ovens and ranges. Replace missing, stripped, or broken screws for tight fit.
