Parts for Ge JGB860BEJ1TS: Gas & Burner Parts

This natural gas conversion kit lets a compatible gas range be configured to run on natural gas instead of the alternate fuel type. It provides the necessary orifice and components to match burner fuel flow for safe operation. What it does:

• Replaces orifice/assembly parts to set burner fuel flow for natural gas
• Ensures burners operate with the correct flame size and combustion for natural gas
• Used when an appliance is being converted from the alternate gas type to natural gas
• Helps resolve issues related to improper fuel type, such as weak or uneven flames

• One conversion assembly kit

• Always shut off gas supply and power before installing; follow the manufacturer's instructions
• After installation, check all fittings and connections for leaks with a gas-safe test method
• Do not attempt installation if you are unfamiliar with gas appliance servicing

This LP high-altitude conversion kit adapts select gas cooking appliances for liquid propane use at elevation. It properly meters gas flow so burners light easily and produce clean, stable flames in thin-air conditions.

• Configures the appliance for LP operation in high-altitude installations
• Calibrates fuel delivery to maintain proper flame size and combustion
• Helps address yellow/sooty flames, flame lift, or hard-to-control simmer after conversion
• Promotes reliable ignition and even heat across burners

• Conversion affects gas type and pressure; must be performed per the manufacturer's instructions and local codes
• Shut off gas and power before service; work in a well-ventilated area away from open flames or sparks
• After conversion, leak-test all connections and adjust air shutters per model guidance if applicable
• Intended for LP high-altitude applications only; use the model-specific kit specified by the manufacturer

The Range NG High Altitude Kit is an OEM part for GE gas ranges. This high-altitude conversion kit allows the range to operate properly at elevations above 2000 feet.

Causes related to needing this kit are using the range at a high elevation without proper adjustment for decreased air pressure and oxygen levels.

Symptoms of needing this high-altitude kit include:

• Unstable or inconsistent flame during operation
• Excessive cooking times
• Incomplete combustion of gas resulting in carbon monoxide issues

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This small cooktop bracket secures designated components beneath the cooktop surface, keeping them properly positioned and stable. Replace a damaged or missing bracket to restore alignment and reduce movement or rattling during use.

• Provides mounting support for specific under-top components, per model design
• Helps maintain proper alignment and stability of cooktop parts
• Replace when visibly bent, cracked, or corroded

• Disconnect power; for gas models, also shut off gas and allow the unit to cool
• Remove surface components as required (grates/caps/heads for gas; elements/panels for electric) to access under the top
• Lift or remove the cooktop as directed in your model's service information and secure the new bracket with existing hardware
• Reassemble, verify alignment, and for gas units check for leaks if any gas connections were disturbed

The Medium surface burner base is an OEM part for GE ranges. It serves as the base for the surface burners, covering and protecting the burner cavities.

Causes of a bad surface burner base include warping or deformation from high heat over time, cracks or breaks from impact damage, or corrosion from liquid spills or grease accumulation.

Symptoms of a bad surface burner base include:

• Burners no longer sitting flush or securely on the cooktop surface
• Excessive air gaps around the burners allowing gas/flames to escape
• Difficulty cleaning due to liquid leaks into the burner cavities
• Visible cracks, breaks, or deformities in the material

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This small V2 inlet jet directs water flow to the dispenser/ice-making area so the appliance fills and forms properly. It restores correct water routing for consistent filling and helps reduce weak or misshapen ice or slow dispensing. What it does:

• Channels water to the ice maker/dispenser so the correct amount reaches the fill area.
• Helps ensure uniform ice formation and consistent dispenser flow.
• Can resolve symptoms like weak/slow dispensing, underfilled ice trays, or uneven ice cubes.
• Works as the small replacement nozzle where the original inlet jet is worn or blocked.

• One small V2 inlet jet

• Disconnect power and shut off the water supply before beginning work.
• Access may require removing inner panels or the ice maker/dispenser housing; follow your model's service instructions.
• Inspect the seat and surrounding fittings for debris or damage before installing; replace other damaged components as needed.

This genuine OEM GE replacement is compatible with additional Hotpoint, RCA and Kenmore gas range models.

A replacement burner valve cover that protects and conceals the gas valve assembly on compatible ranges, helping keep valve components clear of spills and debris for more reliable burner operation. What it does:

• Covers and protects the gas valve area from food, moisture and spills.
• Helps prevent debris from interfering with valve knobs and internal valve parts.
• Can reduce intermittent ignition or burner performance issues caused by contamination.
• Restores the finished appearance around the valve for safer, cleaner operation.

• Always shut off the gas supply and unplug the appliance before servicing.
• Use basic hand tools; handle the valve area gently to avoid disturbing fittings or tubing.
• After installation, check for gas leaks with a soapy-water solution or a proper leak detector—do not use an open flame.

The Orifice Holder is an OEM part for GE gas ranges. It secures the orifice spud in place, maintaining proper alignment of gas ports to burner tubes.

The orifice holder prevents any movement or misalignment of gas passages, ensuring uninterrupted and precise fuel delivery. Correct positioning is critical for safe, efficient combustion and optimal heat levels.

Causes of a faulty holder can include wear and tear, damage from impact or heat exposure, or loose fasteners allowing misalignment over time.

Symptoms of a bad orifice holder include:

• Unstable or uneven burner flames
• Inability to adjust oven temperature as needed
• Gas leaks near burner area
• Abnormal burner combustion noises

Replacing with this genuine OEM GE part restores secure orifice placement and optimized gas flow. It is also compatible with Hotpoint, KitchenAid, and select Kenmore gas range models.


This left-front orifice holder sits beneath the surface burner on gas cooktops and ranges. It routes gas from the control valve to the burner head, supporting reliable ignition and a steady flame when the original holder is damaged or stripped.

• Directs gas from the surface valve to the left-front burner
• Positions and supports the burner head/orifice for correct alignment
• Helps maintain reliable ignition and stable flame at the LF burner
• Common symptoms of a failing holder: LF burner won't light, delayed ignition, weak or uneven flame, or visible damage/stripped threads

• Gas appliance service only—disconnect power and shut off gas supply before starting.
• Allow the unit to cool; remove grates, caps, and burner head as required by your model.
• Access the holder under the cooktop; handle gas tubing carefully and tighten fittings to manufacturer specifications.
• After reassembly, restore gas and check all joints with a non-corrosive leak-detection solution; verify proper ignition and flame.

The Orifice Holder is an OEM part for GE gas ranges. This part holds the burner orifice in place, ensuring the proper flow of gas to the burner for consistent and efficient cooking performance.

Causes of a bad orifice holder can include exposure to high heat, grease buildup, or accidental impact during cleaning or maintenance.

Symptoms of a bad orifice holder include:

• Uneven or weak burner flames
• Difficulty igniting the burner
• Gas odors around the burner area
• Visible damage or corrosion on the holder

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Oven Orifice Spud LP is an OEM part for GE gas ovens. This part controls the flow of liquid propane (LP) gas into the oven burner box. The oven orifice spud plays a role in gas combustion, adjusting flow to match the needs of a liquid propane system. It connects directly to the gas supply, so an improperly sized or damaged spud can lead to gas leaks or incomplete burning.

Causes of a bad oven orifice spud include normal wear over time from constant heating cycles, exposure to cleaning chemicals, or damage during part replacement.

Symptoms of needing a replacement include:

• Uneven or inconsistent oven heating
• Extended cooking times or inability to reach desired temperatures
• Gas smell coming from the oven area
• Visible damage or cracks on the spud itself

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This bake burner is the oven's heat source for baking cycles, replacing a worn or damaged burner to restore consistent bake performance and even cooking results. Designed to match OEM fit and function. What it does:

• Provides the main heat for the oven's bake mode so food cooks through and browns properly
• Helps maintain even temperature distribution across the oven cavity
• Common replacement for symptoms like weak or no bake heat, uneven baking, or burner that won't ignite reliably
• Works with the oven's ignition and gas supply to deliver steady flame when functioning correctly

• Turn off power and shut off the gas supply before starting any repair
• Follow OEM service instructions; verify correct burner alignment and secure mounting before restoring gas and power
• Use caution handling sharp edges and hot surfaces; allow the appliance to fully cool before servicing

The Igniter Mounting Screw is an OEM replacement part for GE ovens and ranges. This screw secures the igniter to the burner assembly, ensuring it remains firmly in place for consistent and reliable ignition. Its precise fit and durable design help maintain the stability and functionality of the igniter.

Over time, mounting screws can become corroded, stripped, or lost during repairs or maintenance. A missing or damaged screw may result in a loose igniter, affecting the appliance's ability to ignite properly.

Symptoms of a bad or missing igniter mounting screw include:

• The igniter becoming loose or misaligned

• Difficulty securing the igniter during installation or repair
• The burner fails to ignite reliably or consistently
• Increased noise or movement of the igniter during operation

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This bake burner is the oven's gas burner assembly that produces the controlled flame for baking and roasting. It restores proper oven heat so food cooks evenly and the oven reaches set temperatures. What it does:

• Provides the primary gas flame for the oven bake function
• Enables even heat distribution across the oven cavity for consistent baking
• Works with the oven burner tube and igniter to light and maintain a steady flame
• Commonly replaced when the oven won't heat, has weak flame, or bakes unevenly

• Disconnect power to the appliance and shut off the gas supply before servicing
• Inspect and replace any damaged gaskets or mounting hardware; follow OEM alignment for proper ignition
• After installation, check for proper ignition and stable flame; perform a leak test on gas fittings

This orifice spud secures and positions the gas orifice for a range or cooktop burner, helping deliver a consistent gas flow for proper ignition and flame control. It's a direct-fit replacement designed for safe, reliable burner operation. What it does:

• Holds and centers the gas orifice at the burner inlet for correct flame pattern and heat output
• Ensures a sealed connection between the burner tube and orifice to prevent leaks
• Helps restore normal ignition and steady flames when a damaged or missing spud causes weak or uneven burners
• Compatible with common range/cooktop gas burner assemblies

• One orifice spud

• Turn off gas supply and electrical power before attempting service
• Only install with the exact OEM part number; hand-start the thread, then tighten to secure—do not overtighten
• After installation, check all connections for leaks with a leak-detection solution or soapy water; never use an open flame to test
• If you smell gas, shut off supply immediately.

The Orifice Spud is an OEM part for GE ranges and cooktops. It is a small, precise component responsible for regulating the flow of gas to the burner, ensuring a controlled and efficient flame for cooking. This spud is essential for maintaining the correct gas pressure and flame size.

Over time, orifice spuds can become clogged or damaged due to residue buildup, corrosion, or improper cleaning. These issues can lead to inefficient burner performance or safety hazards.

Symptoms of a bad orifice spud include:

• Uneven or weak burner flames
• Difficulty in igniting the burner
• Yellow or flickering flames
• Gas odors near the burner area

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

LP Gas. LG .99mm

Medium LP orifice

The Surface Burner Valve is an OEM replacement part for GE gas ranges. Located beneath each burner head, this valve regulates gas flow to its associated burner for consistent temperature control.

Causes of faulty valves often relate to corrosion or debris accumulation from gas vapors over time. Physical damage from impacts or misuse could also restrict proper valve function.

Symptoms include:

•  Burners failing to ignite or heat properly
•  Inability to adjust temperatures across burner settings
•  Abnormally loud noises or small flame projects during use

This genuine GE part is compatible with Hotpoint, RCA, and select Kenmore range models as well.

The Valve and Burner Assembly is an OEM part for GE gas ranges. As the central mechanism delivering gas fuel to each burner, it works to control flames precisely while maintaining consistent heat levels.

Causes of a bad valve and burner assembly include failure of internal valves, cracks in manifolds allowing gas leaks, or blockages restricting proper fuel flow.

Symptoms of a bad valve burner include:

• Inability to ignite or extinguish burners properly
• Burners that produce unstable or excessively large/small flames
• Difficulty maintaining the desired heat setting
• Repeated sensor errors or shutdowns

This GE replacement assembly ensures your range's stove-top functions safely and dependably by accurately metering gas movement. It is also compatible with Hotpoint, RCA, and Kenmore models. Install yours today before minor issues require costly repairs.


The Valve Burner is an OEM part for GE gas ranges. It delivers gas to the cooktop through a valve system. This burner distributes gas evenly across its surface to provide consistent heating for pots and pans.

Causes can be wear over time, defects, dirt/debris buildup affecting the valve mechanism, or damage from mishandling.

Symptoms of a bad valve burner include:

• Uneven or abnormal flames when lit
• Inability to control burner flames and temperatures
• Burner making clicking/hissing noises
• No gas flow or faulty ignition

This GE replacement part is compatible with Hotpoint, RCA, and some Kenmore models.

This surface burner valve regulates gas flow to a single cooktop burner for smooth, precise flame control. Replacing a worn valve can restore reliable ignition and adjustment on the affected burner while maintaining safe operation.

• Regulates and meters gas from the manifold to one surface burner
• Works with the control knob to provide simmer-to-high flame settings
• Common failure symptoms include: burner won't ignite, weak or unstable flame, gas odor near the knob/valve area, or a knob that is hard to turn
• Labeled "270" per GE specification to match the correct valve style/position used in select models

• Disconnect power and shut off the gas supply before servicing
• Access the manifold; note the valve's position and orientation before removal
• Reassemble and check all connections for leaks using an approved leak-detection solution
• If the burner still won't light, also inspect the burner orifice, igniter, and spark system

The Safety Valve is an OEM part for GE gas ranges. It automatically shuts off the gas supply if excess pressure is detected, serving as an essential safety component.

Causes of failure could be debris lodged in the valve opening, worn sealing edges from repeated exposure to extreme temperatures, or damage from impact over time.

Symptoms of a bad safety valve are:

• Inability to ignite or light the oven burners
• Continuous gas leaks even when oven is off
• Responsiveness issues when adjusting knob valves

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore gas range models.

This 90° elbow assembly redirects airflow or fluid between two hose or duct sections, restoring proper routing and fit. It's a direct-fit replacement designed to snap or seal into existing appliance connections for reliable operation. What it does:

• Provides a secure 90° turn to route air or liquid through a hose or duct without kinking
• Restores proper ventilation or drainage where a damaged or cracked elbow causes leaks or poor flow
• Helps eliminate symptoms like reduced airflow, visible leaks, or loose hose connections
• Matches OEM form to maintain fit and alignment with adjoining components

• Verify the elbow matches the original part before installing; check orientation and connection type
• Clean mating surfaces and inspect hose/clamps for wear; replace clamps if they no longer secure
• Hand-start fasteners or clips, then tighten securely; avoid over-tightening plastic fittings
• Disconnect power and/or water and follow appliance safety instructions before working on the unit

A 90° elbow assembly that redirects a fluid or discharge line at a right angle to restore proper routing and a secure connection. Simple replacement for worn, cracked, or damaged elbow fittings. What it does

• Redirects flow between two hoses or fittings at a 90° angle to enable correct line routing
• Provides a sealed connection to help prevent leaks where a straight connection won't fit
• Restores proper flow path to eliminate kinks or pressure loss caused by a damaged elbow
• Common symptom: visible leak, moisture or pooling near the elbow fitting
• Common symptom: poor or restricted flow where the line changes direction

• One 90° elbow assembly

• Turn off power and shut off the appliance water supply before starting any repair
• Inspect mating hoses and seals; replace worn clamps or gaskets for a reliable seal
• Hand-tighten then snug fittings; avoid over-tightening plastic fittings to prevent cracking
• After installation, restore water/power and check thoroughly for leaks during a test run

The Igniter Glowbar is an OEM component specifically designed for GE gas ranges. It is responsible for heating up to generate the high temperatures required to ignite the gas burners.

Symptoms of a bad igniter glow bar include:

• Inconsistent or intermittent burner ignition
• Burners failing to light or staying lit
• Dim or weak glow when attempting to ignite burners

Causes of a bad igniter glowbar can include deterioration of heating elements after heavy use over time, cracks or damage due to mishandling or impact, or premature failure of electronic components.

This OEM GE replacement is compatible with Hotpoint, RCA, and Kenmore ranges.

The Igniter Glowbar is an OEM replacement part for GE ovens and ranges. This glowbar generates the pilot flame and ignites the main burner while cooking.

Causes of a bad glowbar can be prolonged or heavy use over time leading to degradation of the element, or damage from impact or mishandling during cleaning.

Symptoms of a bad glowbar include:

• Inability to ignite or light the oven burners
• Pilot light that repeatedly goes out
• Errors codes related to ignition issues
• Burned smell coming from the oven cavity

This GE OEM replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This L-shaped support bracket stabilizes and secures appliance panels or components, restoring proper alignment and reducing vibration. Built to match OEM fit so repair keeps the original mounting geometry. What it does:

• Provides a secure mounting point for panels, trim, or internal components
• Helps stop sagging, misalignment, or rattling caused by a broken or missing bracket
• Restores correct spacing and support for adjoining parts after a repair
• Fits where original L-style supports were used in the appliance cabinet or chassis

• High-level guide only: restore bracket to original location using existing screw holes or fasteners
• Use the same hardware or OEM replacements; tighten fasteners snugly but avoid over-torquing
• Disconnect power to the appliance before accessing internal panels or performing the repair

The Electrode and Harness Assembly is an OEM part for GE gas ranges. As a critical safety mechanism, it works to detect the presence of gas and spark the burners to life properly during each cooking cycle.

Causes of a faulty assembly can include cracks in electrode materials, failures in wiring insulation or connections, or sensor electrodes clogged with debris over time.

Symptoms include:

• Unreliable or intermittent ignition of one or more burners
• Burners that will not light at all using the Ignite function
• Repeated safety shutoffs during use
• Error codes or sensor fault messages displayed

This GE replacement assembly ensures your appliance's gas detection and ignition system operate dependably to deliver safe, reliable stove-top cooking performance. It is also compatible with Hotpoint, RCA and select Kenmore models.


The Dual Safety Valve is an OEM part for GE gas ranges. As a critical safety component, it works to automatically shut off the flow of gas in the event of a flame outage, leak, or backdraft.

Symptoms of a bad safety valve include:

• Inability to ignite or light one or more gas burners
• Gas smells detected but all control knobs are off
• Repeated unwanted shutting off of burners
• Difficulty achieving or maintaining desired heat levels

Causes can be jammed or stuck valve components due to dirt or corrosion, cracks in valve material from repeated heating cycles, or loose internal mechanisms. This OEM replacement ensures your appliance operates safely by properly regulating gas flow.

This GE part is also compatible with Hotpoint, RCA, and Kenmore gas rangers. Replace yours today to restore performance and protect your home and family from gas leaks or other hazards.


The Igniter Glowbar is an OEM part for GE gas cooktops and ranges. Located within each gas burner well, this component is responsible for reliably igniting the gas flow and lighting each burner. The glowbar contains a heating coil that glows hot enough to ignite the gas when the control knob is turned on.

Causes of a bad igniter glowbar can include deterioration of heating coils over many ignition cycles, accumulation of food or liquid debris, or physical damage.

Symptoms of a bad igniter glow bar include:

• Burners failing to light or only lighting intermittently
• Low flame heights after ignition
• Burners making clicking/popping sounds on startup

This genuine OEM GE replacement is also compatible with select Kenmore and RCA gas ranges using these GE ignition systems.

This deflector is a molded air/heat shield that directs airflow and protects internal components from heat and debris, helping the appliance maintain consistent performance and reduce localized overheating. What it does:

• Directs airflow or heat away from sensitive components to help maintain even temperatures
• Shields wiring and electronics from heat, sparks, or debris
• Helps prevent hotspots that can cause uneven cooking or appliance wear
• Commonly replaced when cracked, warped, or missing and causing poor airflow or noise

• Disconnect power to the appliance before starting any service
• Inspect mounting tabs and surrounding panels; replace any damaged fasteners
• Reinstall panels and secure fasteners to restore proper airflow and shielding

This broil shield protects the oven interior above the broiler, helping direct heat and shielding the oven cavity from intense broiling temperatures for safer, more consistent broiling results. Durable metal construction resists warping. What it does:

• Shields the oven top and components from direct broiler heat to prevent damage and discoloration
• Helps maintain more even broiling by directing heat where food is placed
• Reduces the risk of flare-ups reaching wiring or insulation behind the oven liner
• Restores proper clearance between the burner and oven liner for safe operation

• One broil shield

• Disconnect power (and gas, if applicable) and allow the oven to cool completely before starting
• Remove oven racks and access the broiler area to unfasten and replace the shield using basic hand tools
• Inspect mounting tabs and surrounding liner; replace any damaged clips or screws as needed

Package of 12
