Ge WD08X23655 Sump Gasket (Dishwasher) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Dishwasher Gasket & Seal.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WD08X23655 replaces AP6890930, WD08X10046.

Description

This sump gasket seals the dishwasher's sump to the tub to keep wash water contained. Replacing a worn or flattened gasket helps stop leaks and maintain proper wash and circulation performance.

• Creates a watertight seal between the sump/pump assembly and the tub bottom
• Helps prevent leaks onto the floor or into the base pan
• Maintains wash pressure and circulation by preventing air intrusion
• Replace if torn, cracked, deformed, or if water is leaking from the center/bottom of the unit

What's included: 1 sump gasket Install notes:

• Disconnect power and water before servicing; use gloves to protect from sharp edges
• Access the sump from inside the tub or underside (model dependent); remove spray arm/filter as needed and release the retaining ring or tabs
• Clean mating surfaces; install the new gasket evenly without twists and ensure proper orientation
• Reassemble and run a brief fill/wash to check for leaks before fully reinstalling
