Parts for Viking Range VGIS48: Grill Assembly Parts

This burner igniter is the surface spark electrode that lights a gas burner on your range. Replacing a worn or cracked electrode restores dependable ignition so burners light promptly when you turn the knob.

• Produces a high-voltage spark at the burner head to ignite the gas
• Activates when a burner knob is turned; interfaces with the unit's spark ignition system
• A cracked insulator or worn tip can result in weak or no spark
• Symptoms may include clicking without lighting, intermittent ignition, or needing a match to light

• Disconnect electrical power and shut off gas before servicing
• Remove grates, caps, and the burner head as needed to access the electrode
• Transfer any mounting hardware from the old electrode; position the tip at the same gap and orientation as original
• Route and connect the lead to the correct terminal; keep wiring clear of heat and sharp edges, then test for spark before reassembly

This spark ignition switch mounts on the gas valve shaft and signals the ignition system when you turn the knob to Lite. Replacing a worn switch helps restore dependable burner lighting and can reduce nuisance clicking from a stuck switch. What it does

• Closes the circuit to the spark module when a burner knob is turned
• Triggers the igniter to spark so the burner lights
• May help resolve: no spark at a specific burner, intermittent ignition, or continuous clicking with knobs off (stuck/wet switch)
• Designed for use on the valve stem behind the control knob

• One spark ignition switch

• Disconnect electrical power; shut off gas if working near supply lines
• Pull off the knob and access the switch on the valve stem
• Transfer wires one at a time and match the original orientation
• Keep the area dry; test for proper spark before reassembly

This 1/2" x 1/4" rubber bumper cushions contact points to reduce noise and prevent damage on appliance doors, drawers, and panels. It restores proper cushioning for smoother, quieter operation and helps maintain a snug fit. What it does:

• Absorbs shock where panels or doors meet to reduce rattling and clapping noises
• Prevents metal-to-metal contact that can cause chipping, scratching, or wear
• Helps doors and drawers close more evenly by restoring original spacing
• Commonly used where small, press-fit bumpers have worn, flattened, or fallen off

• One 1/2" x 1/4" rubber bumper

• Press-fit replacement; remove old bumper and press new bumper into the same hole until flush
• No special tools required; use a flat pick or small screwdriver to remove old bumper if needed
• Avoid installing on hot surfaces or near heating elements; let appliance cool before service
• Replace matching bumpers in the same area if others show wear for even performance

The Spark Module Wire is an OEM part for Viking ranges and cooktops. It is responsible for transmitting the electrical signal from the spark module to the burner igniters, enabling the burners to ignite when the control knob is turned on. This wire is crucial for the proper functioning of the ignition system, ensuring that the gas ignites quickly and efficiently.

Over time, the spark module wire can become worn or damaged due to heat exposure, accidental pinching during maintenance, or normal wear and tear. When the wire is compromised, it can lead to issues with the burner ignition process, affecting the overall performance of the appliance.

Symptoms of a bad spark module wire include:

• Burners not igniting or taking longer to ignite
• Intermittent sparking or no sparking at all
• Clicking sound without ignition

This OEM part is specifically designed for Viking appliances, ensuring compatibility and reliable performance.
