Parts for Magic Chef YE206KW: 04 - Heater Parts

This 10-24 threaded screw secures appliance components that use a #10 machine screw. It provides reliable fastening for panels, brackets, and assemblies so parts stay aligned and stable during normal use and service. What it does:

• Fastens panels, brackets, or assemblies that accept a 10-24 machine screw
• Maintains alignment and structural connection under normal operating loads
• Replaces worn, stripped, or missing screws to restore secure mounting
• Works with sheet-metal and component mating nuts or threaded inserts commonly used in appliances

• One 10-24 threaded screw

• Power tools can be used; avoid overtightening to prevent stripped threads or damaged components
• Disconnect power and follow all safety steps for your appliance before servicing
• Ensure proper engagement and torque to avoid damage

The Dryer Heating Element Kit is an OEM replacement part for Whirlpool dryers. This kit is essential for the dryer's ability to generate hot air needed to efficiently dry clothes. The heating element works by converting electrical energy into heat, which is then circulated throughout the dryer drum to evaporate moisture from the laundry.

Over time, the heating element can burn out or become damaged, leading to a significant decrease in drying efficiency or the dryer not producing any heat at all.

Symptoms of a bad Dryer Heating Element Kit include:

• Clothes taking longer to dry or not drying completely
• The dryer running but not generating any heat
• Unusual noises or smells during operation, indicating potential overheating or electrical issues
• The dryer repeatedly blowing fuses or tripping circuit breakers

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

A high-limit thermostat that stops the dryer's heating circuit if internal temperatures get too high, helping prevent overheating and protecting heating components. Replaces a failed high-limit thermostat to restore overheat protection. What it does

• Opens the heating circuit when dryer temperature exceeds the thermostat set point to prevent overheating.
• Commonly related symptoms: dryer runs but produces little or no heat, dryer gets unusually hot, or the thermal cutoff repeatedly fails.
• Works as part of the dryer's temperature-safety system to protect heating elements, fuses, and internal wiring.

• One high-limit thermostat

• Disconnect power before accessing the dryer and work only after panels are cool.
• Take a photo or label wires before removal to ensure correct reconnection.
• Test the thermostat for continuity with a multimeter to confirm failure before replacing.
• If other safety devices (thermal fuse, cycling thermostat, element) show symptoms, inspect and test those components too.

The Whirlpool screw is an OEM replacement part responsible for securing various components or parts on different types of Whirlpool appliances. The screw is designed to provide a secure and reliable fastening connection, ensuring that different parts of the appliance stay in place. It is commonly used in different locations within the appliance, such as the cabinet, panels, or other structural elements.

This part fixes the following symptoms:

• Loose or wobbly components within the appliance
• Panels or parts that are not securely attached
• Rattling or unusual noises due to loose parts
• Damaged or missing screw

The Whirlpool screw can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

This 10-24 threaded screw secures appliance components that use a #10 machine screw. It provides reliable fastening for panels, brackets, and assemblies so parts stay aligned and stable during normal use and service. What it does:

• Fastens panels, brackets, or assemblies that accept a 10-24 machine screw
• Maintains alignment and structural connection under normal operating loads
• Replaces worn, stripped, or missing screws to restore secure mounting
• Works with sheet-metal and component mating nuts or threaded inserts commonly used in appliances

• One 10-24 threaded screw

• Power tools can be used; avoid overtightening to prevent stripped threads or damaged components
• Disconnect power and follow all safety steps for your appliance before servicing
• Ensure proper engagement and torque to avoid damage

Size: 10-32 inch.

The Thermal Fuse is an OEM part for Whirlpool dryers. This part prevents the dryer from overheating by cutting off power to the heating element if the dryer exceeds a safe temperature. It helps protect the appliance and home from potential fire hazards caused by overheating.

Causes of a bad thermal fuse can include lint buildup restricting airflow, a malfunctioning thermostat, or excessive load causing the dryer to overheat.

Symptoms of a bad thermal fuse include:

• Dryer not starting
• Dryer not producing heat
• Dryer shutting off mid-cycle
• No power to the dryer despite other electrical components functioning

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.
