Parts for Kitchenaid KOWT100EBS00: Internal Warming Drawer Parts

This drawer slide assembly mounts to the refrigerator cabinet and supports the interior bin as it moves. Replacing a worn slide restores smooth, level drawer travel for easier access and reliable sealing.

• Supports and guides a refrigerator drawer so it glides in and out smoothly
• Attaches to the cabinet wall and interfaces with the drawer track
• Helps keep the drawer level and aligned to prevent binding or scraping
• Typical signs of failure: sticking drawer, sagging on one side, popping off track, or visible cracks in the rail

• Unplug the refrigerator and remove items from the affected drawer
• Pull out and remove the drawer (and shelf/glass if required for access)
• Remove mounting screws, swap the slide in the same orientation, and tighten securely
• Reinstall the drawer and verify smooth operation; use gloves and caution around glass and sharp edges

This electronic console control board manages cycle selection and user inputs for your appliance, restoring responsive controls and reliable cycle operation. It replaces a failed or unresponsive control to bring back normal control-panel function. What it does:

• Interprets button/touch inputs and runs selected cycles or settings
• Sends signals to motors, valves, heaters, and displays to coordinate operation
• Helps resolve symptoms like unresponsive buttons, incorrect cycles, or control-panel error codes
• Prevents intermittent operation caused by a failing or shorted control

• Disconnect power (unplug or shut off breaker) before starting any repair
• Handle the board carefully; avoid touching circuit traces and use anti-static precautions if possible
• Reconnect wiring harnesses to their original connectors and verify connections are fully seated
• Test the appliance after installation before reassembling panels

This thermal fuse stops power if an appliance overheats, helping prevent damage and unsafe operation. Use as a direct replacement when the original high-limit fuse has failed and the appliance will not operate normally. What it does:

• Opens the circuit when temperatures exceed safe limits, acting as a high-limit safety cutoff.
• Protects the appliance and home from overheating-related damage and hazards.
• Common symptoms of a blown thermal fuse: appliance won't heat, intermittent heating, or the unit fails to start.
• If the fuse blows, it often indicates an underlying issue—inspect heating elements, thermostats, and venting for faults.

• Disconnect power to the appliance before servicing to avoid electrical shock.
• Allow the appliance to cool, then access the fuse location; note wiring orientation and terminal connections for reassembly.
• Replace with the exact type of thermal fuse; do not bypass, jumper, or defeat the device.
• If the replacement fuse fails again, check for restricted venting, failed heating components, or faulty thermostats/controls.

This broil element replaces a failed oven broiler heating element to restore top-heat cooking and browning. Designed to match OEM fit and function for compatible Whirlpool-family built-in and freestanding ovens. What it does:

• Heats the top of the oven cavity for broiling, browning, and finishing dishes.
• Commonly used when the broiler fails to heat, uneven broiling occurs, or the element is visibly burned or broken.
• Replaces a worn or damaged element to stop sparking, arcing, or no-heat conditions at the broiler.
• Matches OEM mounting and terminal locations for a direct replacement in compatible units.

• One broil element

• Disconnect power to the appliance before servicing to prevent shock or injury.
• Access may require removing the oven door or interior panels; follow the oven's service manual.
• Inspect terminal connections and wiring for damage; tighten or replace connectors as needed.

This replacement screw secures appliance panels and components so they stay tight and aligned during use. Replacing a missing or damaged screw restores a solid fit and helps eliminate rattles, loose trim, or shifting parts.

• Fastens brackets, panels, trim, or components to the appliance chassis
• Helps correct loose or missing hardware after vibration or service
• Replaces stripped, rusted, or broken screws
• Can reduce rattling noises or misaligned parts caused by missing fasteners

• Disconnect power; for gas appliances, also shut off the gas supply
• Support the part being fastened; start threads by hand to avoid cross-threading
• Use the correct driver size; tighten snugly without overtightening
• Replace hardware with the exact part number to ensure proper fit

This wire harness assembly routes power and control signals between components to restore proper electrical connections. It replaces a damaged or worn harness to help resolve power loss and intermittent operation. What it does:

• Delivers power and signal connections between control, motors, switches, and sensors.
• Restores reliable electrical continuity when old wires are frayed, broken, or corroded.
• Helps eliminate symptoms like no power to components, intermittent operation, or electrical shorts.
• Keeps wiring organized and properly routed to prevent chafing and accidental disconnection.

• One wire harness assembly as shown.

• Disconnect power to the appliance before starting any repairs to avoid shock.
• Ensure all connectors are fully seated and that wires are secured away from sharp edges and moving parts.
