Parts for Ge JT3500EJ1ES: Lower Door Parts

This door liner kit replaces a damaged or worn refrigerator door interior to restore a clean, sealed surface and improve door appearance. Designed to fit the OEM mounting points for a proper fit and reliable performance. What it does:

• Replaces cracked, warped, stained or otherwise damaged door liner surfaces
• Restores a smooth interior surface to help door shelves and bins mount correctly
• Helps maintain a consistent door seal by providing a true mounting surface for gaskets and hardware
• Improves overall appearance of the refrigerator door interior

• Disconnect power to the appliance before beginning service
• Remove door shelves, bins, and any trim before removing the old liner
• Retain and reuse any existing screws, clips, or hardware unless replacements are provided in the kit

This door insulation retainer is a small plastic clip that secures insulation inside a refrigerator/freezer door to help maintain proper temperature and reduce noise. It replaces worn or missing retainers to keep the door liner insulation in place. What it does:

• Secures the door insulation to the inner door liner so insulation stays positioned
• Helps prevent insulation from shifting or sagging that can affect door seal performance
• Commonly used when insulation falls out or the liner shows gaps around the insulation
• Works as a direct-fit replacement for the original retainer designed for the door assembly

• One door insulation retainer clip

• Installation generally requires removing the door panel or liner; keep track of fasteners and trim
• Handle the door liner and insulation carefully to avoid damage or tearing the insulation
• Use proper tools and disconnect power if working near electrical components or lights
• Replace all affected clips for an even, secure fit

A replacement liner support that secures the refrigerator cabinet liner and keeps interior trim and panels aligned for a proper seal and appearance. Restores stability to cracked or broken support points. What it does:

• Holds the cabinet liner and interior trim in position to prevent gaps and movement
• Helps maintain door seal alignment by keeping liner edges stable
• Reduces rattling or shifting caused by a damaged support
• Commonly replaced when liner pieces are cracked, broken, or loose

• One liner support

• Disconnect power to the appliance before beginning any repair
• Remove food, shelves, and trim pieces as needed to access the damaged support
• This part typically secures with clips or fasteners; inspect existing hardware and replace if necessary

This handle support mount kit secures and reinforces an appliance door handle so it stays aligned and stable during normal use. It replaces worn or broken handle supports to restore proper handle fit and function. What it does:

• Provides the mounting point and hardware to secure a door or panel handle
• Stops handle wobble, looseness, or sag caused by worn supports or damaged mounts
• Restores correct handle alignment for safe, reliable operation
• Works as the replacement support when the original mounting has cracked or failed

• Disconnect power (or unplug) and remove any panels before starting
• Use basic hand tools (screwdriver/socket) and avoid over-tightening fasteners to prevent damage
• Handle replacement may require holding the handle in position while securing the support

This replacement oven door window glass restores a clear view into the oven and helps maintain proper heat containment. Replace a cracked, shattered, or clouded window panel to keep cooking safe and your appliance looking like new.

• Creates the transparent viewing window in the oven door
• Helps retain heat and maintain a proper door seal
• Direct replacement for cracked, shattered, scratched, or stained glass
• Typical symptoms: visible damage, fogging between panes, loose/rattling window, or noticeable heat loss at the door

• Disconnect power and allow the oven to cool completely
• Wear cut-resistant gloves and eye protection; handle glass carefully
• Remove the door and lay it flat on a padded surface; transfer any brackets, trim, or gasket from the original glass as required by your model
• Reassemble carefully; do not overtighten fasteners and verify the door seals and operates properly

This inner oven door window spacer positions and cushions the glass inside the oven door assembly to help maintain a secure fit and proper spacing. It supports safe, consistent sealing and helps prevent rattling or glass contact with the inner panel. What it does:

• Keeps the inner oven door glass properly spaced from the door frame and outer glass
• Cushions the glass to reduce vibration and rattling during operation
• Helps maintain an even seal to support temperature stability inside the oven
• Prevents direct glass-to-metal contact that can cause chipping or stress

• One oven door window spacer

• Designed for use inside the oven door assembly; door disassembly is usually required
• Handle glass and spacer carefully to avoid chips or cuts; use gloves and safety glasses
• Disconnect power to the appliance before starting any repair and follow OEM instructions

ST10-16 X 7/16"

Black. 8-18 AB HXW 3/8

Includes 12 washers.

This hex-head machine screw has a 10-32 thread and measures 1-3/4 inches long. Use it to replace a missing, stripped, or rusted fastener and restore a secure fit where this exact size is specified.

• Secures brackets, panels, and internal components requiring a 10-32 x 1-3/4 in hex-head screw
• Restores proper alignment and mounting integrity
• Replaces damaged, corroded, or lost hardware
• Can help resolve symptoms like loose/rattling parts or shifting components

• Disconnect power (and shut off gas, if applicable) before servicing; allow appliance to cool
• Remove the old screw, align parts, and start the new screw by hand to avoid cross-threading
• Tighten snugly but do not overtighten
• Reuse any original washers or spacers if present

This 10-32 machine screw secures brackets, panels, and other hardware in cooking appliances. Replacing a missing or stripped screw restores a snug, rattle-free fit and keeps components aligned and safely fastened. What it does:

• Fastens panels, brackets, and components using a 10-32 machine thread
• Replaces hardware that is missing, rusted, or stripped
• Helps address loose or rattling parts and minor panel misalignment
• Maintains secure mounting after service or part replacement

• One 10-32 machine screw

• Disconnect power; for gas appliances, also shut off gas before service
• Support the panel or bracket while removing/installing hardware
• Start threads by hand to avoid cross-threading; do not overtighten
• Replace them one at a time to keep alignment
