Parts for Ge PTS9200SN2SS: Lower Door Parts

The Badge Assembly is an OEM part for GE ranges. It includes the magnetic decorative badge affixed to the front of the range. This badge displays important information such as the brand name, model number, and technical specifications.

Causes of a bad badge assembly can include damage from impacts or abrasions over time, adhesive failure from repeated heat exposure, or normal wear from routine cleaning. On a range, the badge must withstand higher cooking temperatures.

Symptoms of a bad badge assembly include:

• Faded or illegible print on the badge face
• Cracks or breaks in the plastic material
• The badge lifting or peeling away from the surface
• Missing or loose attachment clips/fasteners

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This oven door insulation panel fits inside the oven door to help contain heat for more even cooking and protect the outer door surface. It replaces worn or missing insulation to reduce heat loss and improve oven performance. What it does:

• Helps retain oven cavity heat for more consistent baking and roasting
• Reduces heat transfer to the outer door, improving user safety
• Limits heat loss from the oven cavity that can cause longer cook times
• Restores proper door sealing alignment when insulation is compressed or missing

• Disconnect power (and gas if applicable) before starting any repair
• Remove the oven door or inner door panel to access insulation
• Wear gloves to protect against sharp edges and insulation fibers
• Reinstall panels and check door fit and seal before returning the oven to service

This oven door gasket forms the heat-sealing seal around the oven door to help keep heat and cooking odors in the oven cavity for more even cooking. It replaces worn, torn, or deformed seals to improve oven performance. What it does:

• Seals the oven door to reduce heat loss and help maintain consistent cooking temperatures.
• Helps prevent smoke or odors from escaping the oven cavity during use.
• Reduces energy waste caused by oven heat leaking around the door.
• Commonly replaced when the gasket is cracked, compressed, burnt, or shows visible gaps.

• One oven door gasket as shown.

• Remove power to the appliance and allow the oven to fully cool before servicing.
• Inspect the gasket channel and clean debris before installing the new gasket for a proper seat.
• Press the gasket into the door channel, working around the perimeter to ensure an even fit; some gaskets may be secured with clips or adhesive—follow the oven's service instructions.

This hex-head machine screw has a 10-32 thread and measures 1-3/4 inches long. Use it to replace a missing, stripped, or rusted fastener and restore a secure fit where this exact size is specified.

• Secures brackets, panels, and internal components requiring a 10-32 x 1-3/4 in hex-head screw
• Restores proper alignment and mounting integrity
• Replaces damaged, corroded, or lost hardware
• Can help resolve symptoms like loose/rattling parts or shifting components

• Disconnect power (and shut off gas, if applicable) before servicing; allow appliance to cool
• Remove the old screw, align parts, and start the new screw by hand to avoid cross-threading
• Tighten snugly but do not overtighten
• Reuse any original washers or spacers if present

This silicon controlled rectifier (SCR) is an electronic switching component that controls current flow in appliance control circuits, helping regulate power to heaters, motors, or other loads for stable operation. What it does:

• Switches and regulates current in control boards and power circuits
• Can prevent power from reaching a heater, motor, or element when failed
• Helps protect downstream components by controlling surge/current flow

• Disconnect power to the appliance before servicing to avoid shock.
• Handle the SCR carefully to avoid electrostatic discharge (ESD) damage.
• May require board-level replacement or soldering skills.
