Parts for Frigidaire PLEC30S9ECC: 05 - Maintop Parts

This oven bake element is the heating element that warms the oven cavity for baking and roasting. Replacing a damaged element restores proper oven heating and helps return cooking performance to normal. What it does:

• Heats the oven interior for baking, roasting and browning.
• Replaces elements that are visibly burnt, cracked, broken, or no longer glow when the oven is on.
• Common symptoms it can fix: little or no heat from the oven, uneven cooking, or an element that sparks or shows burn spots.
• Works as the direct heater inside the oven cavity; connects to the oven terminal block.

• Disconnect power at the breaker or unplug the appliance before starting any repair.
• Access typically requires removing the oven interior panels or rear access panel; support the element while disconnecting terminals.
• Handle terminals and sharp sheet metal carefully; use insulated tools and secure terminal connections.

The Dual Element is an OEM part for Frigidaire ranges. This element features two heating zones, allowing for versatile cooking options by providing both high and low heat settings on the same burner. It ensures efficient and consistent heating, making it ideal for various cooking tasks. It contains a 9-inch, 1200-watt element and a 6-inch, 1300-watt element, combining for 2500 watts at 240 volts

Causes of a bad dual element can include electrical issues, wear and tear from regular use, or physical damage such as cracks or breaks in the heating element. These issues can lead to inconsistent heating or complete failure of the element.

Symptoms of a bad dual element include:

• Burner not heating up
• Inconsistent or uneven heating
• Element not switching between high and low heat
• Visible damage to the element

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

A replacement burner box that secures and routes the cooktop's gas and ignition components to keep burners operating safely and reliably. Restores proper alignment and support for valves, igniters and burner heads. What it does:

• Houses and positions gas valves, igniters and burner assemblies for a gas cooktop
• Routes gas from the manifold to each burner for consistent delivery
• Protects internal components from spills and directs heat away from controls
• Can help resolve symptoms such as burners not lighting, irregular flames, or gas odors near the cooktop

• Turn off gas supply and disconnect power before starting any service
• Replacement may require removing the cooktop and disconnecting gas lines
• Inspect and replace any damaged gaskets or mounting hardware during installation
• Follow OEM service instructions and test for leaks and proper ignition after reinstalling

This element mounting spring secures a surface cooktop heating element to the range, keeping the element stable and ensuring consistent electrical contact for reliable heating. Replaces a worn or missing spring to restore proper element fit. What it does

• Holds the surface heating element in place under the cooktop or in the drip pan.
• Maintains stable mechanical and electrical contact so the element heats evenly.
• Prevents element wobble, movement, or poor seating that can cause intermittent heating.
• Commonly needed when an element drops, rattles, or fails to make solid contact.

• Disconnect power to the appliance before starting any repair.
• Remove the element and/or drip pan per the range service instructions to access the spring.
• Install the spring in the same orientation as the original; ensure the element seats fully and securely.

Used on the 2500 watt element

The Terminal Block Kit is an OEM part for Frigidaire appliances, typically used for connecting house power to various electrical appliances like ranges and dryers. This kit includes includes screws, nuts, and a unique terminal block. It plays a critical role in the power supply system by providing a reliable connection point for the appliance's main power cord, preventing loose connections and potential electrical hazards.

Symptoms of a bad Terminal Block Kit include:

• Signs of burning or melting at the connection points,
• Flickering power or intermittent operation of the appliance,
• A burning smell from the appliance area.

Causes of terminal block failure often involve loose connections that can lead to arcing and overheating, improper installation, or general wear and tear that degrades the integrity of the electrical contacts.

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

This deflector directs refrigerated air inside the compartment to help even cooling and protect stored items from direct airflow. It restores intended airflow paths so the appliance cools more consistently. What it does:

• Guides airflow from the evaporator/fan to distribute cold air evenly
• Reduces spots of uneven temperature and helps maintain consistent food temperatures
• Helps prevent direct fan blow on food that can cause localized freezing
• Works with cabinet airflow components to keep circulation operating as designed

• Refer to your model's service manual or parts diagram for the correct mounting location and orientation
• Power off and unplug the appliance before accessing internal compartments or removing panels
• Handle plastic parts carefully to avoid cracking; use appropriate fasteners when reinstalling

Specs: 10-32 X 0.375
