Parts for Dacor ER36GSCHLP: Manifold Parts

A single aluminum low-pressure service valve that provides a sealed access point for refrigerant charging, evacuation and pressure checks. Designed to restore proper serviceability for refrigeration and sealed-system maintenance. What it does:

• Provides a dedicated, sealed port for connecting gauges and service equipment to the low-pressure side of the refrigeration system.
• Allows safe charging, evacuation and pressure testing during diagnostics and repairs.
• Helps isolate and reseal the system after service to prevent refrigerant leaks.
• Commonly used when a refrigerator or freezer needs refrigerant service or pressure verification.

• Intended for experienced technicians; refrigerant work should follow all local regulations and EPA/other certification requirements.
• Depressurize and recover refrigerant before removing or replacing the valve.
• Inspect and replace any sealing O-rings, fittings or gaskets as needed; torque to OEM specifications.
• Test for leaks and proper operation before returning the appliance to service.

This retaining ring secures the LED assembly in place, keeping indicator lights and display components stable for reliable operation. It's a small but important part that helps prevent loose or misaligned LED modules. What it does:

• Holds the LED assembly securely to the control/display area
• Prevents movement or rattling of indicator lights during operation
• Helps maintain proper alignment so LEDs remain visible and functional
• Can address symptoms like loose display trim, vibrating noises, or intermittently obscured LEDs

• Disconnect power before starting any repair to avoid shock or damage
• Handle the LED assembly and connectors gently to avoid breaking LEDs or wiring
• Use basic hand tools; avoid forcing the ring—align and snap into place per OEM guidance

This LED socket assembly restores the high-intensity indicator lighting used on select cooktops to show an active cooking zone. Replace a failed module to bring back clear, consistent illumination. What it does:

• Provides bright LED illumination for a cooking zone indicator
• Restores visual feedback that a burner/zone is in use
• Replaces a failed or damaged LED socket/module
• Common symptoms: no light, dim or flickering light, intermittent operation, or physical damage

• One LED socket assembly

• Disconnect power at the breaker before servicing
• Allow the appliance to cool and protect the glass surface while working
• Access the module from beneath the cooktop; match connector orientation and mounting position
• Test illumination before final reassembly
