Parts for Ge JEBC200B01: 01 - Section1 Parts

This magnetron generates microwave energy to heat food in compatible countertop and over-the-range microwaves. Replacing a worn magnetron restores cooking power and helps eliminate uneven heating or failure to heat. What it does:

• Converts high-voltage electrical power into microwave radiation used to cook and reheat food
• Common symptom: oven runs but food doesn't heat or heats very slowly
• May also be needed if you notice loud buzzing, arcing, or burning odors during operation
• Works with the microwave's high-voltage system; other components may also need inspection

• One magnetron (single unit as shown)

• Disconnect power and discharge the microwave's high-voltage capacitor before servicing
• Inspect surrounding parts (waveguide, diode, capacitor, and cooling fan) for damage during replacement
• Use only the correct replacement part number to ensure proper fit and safe operation

Ceramic

This control board cover is a replacement protective shield designed to sit over the appliance control assembly and help prevent debris, moisture, and accidental contact with electrical components. It restores the factory protection and appearance of the control area. What it does

• Covers and protects the control board and wiring from dust, spills, and physical contact
• Helps prevent short circuits and component damage caused by loose debris or accidental impact
• Restores proper fit and finished look to the control area when the original cover is cracked, warped, or missing
• Matches OEM fit and mounting points so the control assembly sits securely

• One control board cover

• Disconnect power to the appliance before attempting any repair to avoid shock
• Remove any trim or access panels as needed to reach mounting screws; keep hardware for reinstallation
• Align cover to existing mounting points and secure with original screws; do not overtighten

This damper cam engages the refrigerator air damper assembly to help control airflow between compartments, restoring proper vent movement and temperature balance. It replaces a worn or broken cam that prevents the damper from opening or closing correctly. What it does:

• Fits into the damper/actuator assembly to transfer motion from the damper motor to the vent
• Helps regulate airflow between fresh food and freezer compartments
• Commonly replaces a cracked, stripped, or broken cam that causes vents to stick
• Can resolve symptoms like uneven cooling, warm spots, or vents that won't open/close

• Disconnect power to the appliance before starting any repair
• Access may require removing interior panels or the damper housing; keep track of screws and clips
• Handle plastic gears and cams carefully to avoid damage during installation
• After installation, restore power and verify the damper cycles and vents move normally

The Capacitor is an OEM part for GE microwaves. This component stores and releases electrical energy to help power the microwave's high-voltage circuits, essential for the proper functioning of the appliance.

Over time, capacitors can fail due to electrical surges, overheating, or degradation of the internal components. When a capacitor goes bad, it can affect the microwave's ability to generate heat and operate efficiently.

Symptoms of a bad Capacitor include:

• The microwave not heating food
• Unusual humming or buzzing noises
• The microwave shutting down or not starting

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This high-voltage rectifier diode is used in the microwave's high-voltage circuit. It converts AC to DC so the magnetron can produce heat. A failed diode can cause no heat, loud humming, or a blown fuse when starting. What it does:

• Rectifies high-voltage AC to DC to power the magnetron
• Blocks reverse voltage in the HV circuit
• Common failure symptoms can include: runs but doesn't heat; loud hum then shutdown; line fuse blows at startup

• 1 high-voltage diode

• Unplug the microwave and properly discharge the high-voltage capacitor before servicing—dangerous voltage can remain even when unplugged
• Match diode orientation/polarity to the original and ensure a solid chassis ground connection where used
• Route leads and reinstall any clamps/insulators exactly as found; keep wiring clear of sharp edges and hot components
• If the original diode failed, inspect the HV capacitor and transformer for related issues before reassembly

This high-voltage transformer supplies the ignition voltage used to create sparks for gas burner/oven ignition. Replaces a worn or failed transformer to restore reliable spark firing and consistent burner ignition. What it does:

• Converts line voltage to the high-voltage pulse needed for spark ignition
• Sends ignition sparks to surface burners or oven igniters so gas will light
• Common symptom: clicking with no visible spark at the burner or burner(s) that fail to ignite
• Other symptom: intermittent ignition or weak sparking

• One high-voltage transformer

• Disconnect power to the appliance before servicing to avoid electrical shock
• Handle the transformer and high-voltage leads with care; do not operate with covers removed
• Verify correct diagnosis before replacing; check ignition module, wiring, and spark electrodes for faults

This gas flame sensor detects whether a burner's flame is present so the range/oven's gas valve and ignition control can operate safely. It helps restore reliable ignition and prevents the valve from staying open when no flame is detected. What it does:

• Senses the presence of a gas flame and signals the control to keep the valve open
• Helps prevent gas flow if a flame is not detected
• Can stop ignition or cause the oven/range not to heat when failing
• Commonly replaced when burners won't stay lit or control shows ignition-related errors

• One gas flame sensor

• Turn off electrical power and shut off the gas supply before servicing
• Handle the sensor and its connector carefully to avoid damage
• Reinstall in the exact position and orientation; loose connections can cause false faults

This cord bushing provides a protective seal where the appliance power cord passes through the cabinet, preventing chafing and reducing strain on the cord. It restores a safe cord entry and helps maintain proper cord alignment. What it does

• Protects the power cord from rubbing against sharp edges or metal panels.
• Helps prevent electrical shorts and exposed wiring caused by worn or damaged openings.
• Reduces cord movement and strain at the entry point to the appliance.
• Commonly replaced when the cord shows wear at the cabinet or when the bushing is cracked or missing.

• One cord bushing

• Turn off power to the appliance (unplug or switch off circuit breaker) before inspecting or replacing the bushing.
• Install by seating the bushing in the cord entry hole and routing the cord through; ensure the bushing sits flush and the cord moves freely without pinching.
• Use basic hand tools; no special wiring changes are required for this part.

The Light Bulb is an OEM part for GE microwaves. This bulb illuminates the interior of the microwave during operation, enhancing visibility so you can monitor the cooking process without opening the door. It is designed to withstand the high temperatures and vibrations typically found in microwave ovens.

Over time, the light bulb can burn out or become damaged due to the harsh environment of the microwave. Frequent on and off cycles can also shorten the lifespan of the bulb. Replacing a non-functioning or dim bulb will restore visibility and improve the functionality of your microwave.

Symptoms of a bad light bulb include:

• Dim lighting inside the microwave.
•  Flickering or inconsistent performance.
• Complete lack of light when the microwave is operating.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This lamp bracket is the replacement mounting support that secures the oven/cabinet lamp assembly so the light stays in position and the bulb remains stable during use. Restores proper lamp alignment and helps prevent rattling. What it does:

• Holds the lamp socket or lamp assembly firmly in place inside the oven or appliance cavity
• Keeps the bulb aligned so the light properly illuminates the interior
• Prevents vibration and rattling that can occur with a broken or bent bracket
• Compatible with the original lamp mounting location to allow simple reinstallation

• One replacement lamp bracket

• Turn off power to the appliance and disconnect from the electrical supply before starting
• Handle the lamp and socket carefully; remove the bulb before removing the old bracket
• Installation usually requires basic hand tools (screwdriver); keep fasteners removed from the old part for reuse if undamaged

The Microwave Door Switch is an OEM part for GE microwaves, designed to prevent the microwave from operating when the door is open by interrupting the power whenever the door is not securely closed. The door switch is an essential safety feature.

Symptoms of a failing Microwave Door Switch include:

• The microwave not starting or heating
• Running when the door is opened
• Unusual noises when the door is closed

Causes of a bad Microwave Door Switch can result from repeated opening and closing of the door or slamming that can cause the switch to degrade or become misaligned, leading to intermittent or failure.

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

The Microwave Door Switch is an OEM part for GE microwaves, designed to prevent the microwave from operating when the door is open by interrupting the power whenever the door is not securely closed. The door switch is an essential safety feature.

Symptoms of a failing Microwave Door Switch include:

• The microwave not starting or heating
• Running when the door is opened
• Unusual noises when the door is closed

Causes of a bad Microwave Door Switch can result from repeated opening and closing of the door or slamming that can cause the switch to degrade or become misaligned, leading to intermittent or failure.

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

This door key is the small keyed actuator used to engage or release a door latch assembly. It restores proper door latch operation so the appliance door will stay closed and latch securely during use. What it does:

• Replaces a worn or broken door key that won't engage the door latch
• Restores the mechanical interface between the door and the latch assembly
• Helps resolve symptoms such as a door that won't stay latched or won't fully engage
• Small, user-replaceable component that mounts to the door/latch area

• Turn off power to the appliance and disconnect power before servicing
• Remove door trim or access panel as needed to reach the key; keep fasteners organized
• Install by aligning and securing the key to the latch per OEM orientation; test latch operation before reassembling

This small spacer positions and stabilizes the oven rack inside the cavity. Replacing a worn or missing spacer restores correct rack height and alignment so the rack slides smoothly without scraping or wobbling during use.

• Maintains proper clearance between the rack and oven wall/rail
• Keeps the rack level and correctly aligned on its supports
• Helps the rack slide in and out smoothly
• Direct replacement for a cracked, deformed, or missing spacer

• Disconnect power; if gas, shut off gas supply. Allow the oven to cool completely.
• Remove the rack and note the spacer's original location and orientation.
• Install the spacer in the designated position and ensure it is fully seated.
• Reinstall the rack and ensure smooth movement and secure support.
