Parts for Ge JES1634WAP02: 01 - Section1 Parts

This glass tray is a flat oven shelf that provides a smooth, easy-to-clean surface for baking and roasting. It restores a stable cooking surface and replaces cracked, chipped, or otherwise damaged oven glass trays. What it does:

• Supports bakeware and cookware for even heating on the oven floor or shelf area
• Replaces trays that are cracked, chipped, or shattered and may cause uneven cooking
• Provides a smooth, non-porous surface that's simple to wipe clean
• Helps prevent food drips from contacting the oven floor when used as intended

• One glass tray

• Handle carefully; glass can break and cause injury—wear cut-resistant gloves
• Allow the oven to cool completely before removing or installing the tray
• Inspect tray for chips or stress cracks before first use; do not use if damaged
• Follow the appliance manufacturer's instructions for placement and safe use

This inner door frame secures the oven's inner panel and helps support the inner glass, keeping the door assembly stable and aligned for safe, efficient oven operation. Replacing a damaged inner frame restores proper door fit and appearance. What it does:

• Supports and positions the inner door panel and inner glass
• Helps maintain proper door alignment and seal for efficient heating
• Prevents rattling or looseness caused by bent or cracked frames
• Restores safe, stable door operation and original fit

• Disconnect power to the appliance before starting any repair
• Handle glass and sharp edges carefully; wear gloves and eye protection
• Removal may require lifting out the door and removing retaining screws or clips

The Microwave Door Switch is an OEM part for GE microwaves, designed to prevent the microwave from operating when the door is open by interrupting the power whenever the door is not securely closed. The door switch is an essential safety feature.

Symptoms of a failing Microwave Door Switch include:

• The microwave not starting or heating
• Running when the door is opened
• Unusual noises when the door is closed

Causes of a bad Microwave Door Switch can result from repeated opening and closing of the door or slamming that can cause the switch to degrade or become misaligned, leading to intermittent or failure.

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

The Monitor Switch is an OEM replacement part for GE microwave ovens. Located internally on the turntable control circuit board, this switch monitors rotation of the turntable during cooking cycles.

Causes of failure involve degradation of the electrical contacts from continuous arcing loads over years of use combined with vibration stresses.

Symptoms of a faulty monitor switch include:

• The turntable no longer rotates or spinning intermittently
• Cooking cycles aborting prematurely with error messages
• Screeching or grinding noises emanating from beneath cavity
• Visible burnt spots on turntable drive assembly

This genuine GE switch is also compatible with select Hotpoint and RCA models.

This Supporter - mgt is a small mounting support that helps secure and stabilize the appliance assembly where it attaches. It reduces movement and keeps related components aligned for reliable operation. What it does:

• Provides structural support for the appliance assembly and helps hold parts in position
• Reduces rattling, vibration, and movement caused by loose or worn supports
• Helps maintain proper alignment of adjacent panels or components
• Can prevent further wear or damage resulting from a loose assembly

• Disconnect power to the appliance before starting any repair
• Remove any trim or panels that block access to the mounting location
• Typical installation requires basic hand tools (screwdriver, nut driver); keep fasteners organized

This magnetron assembly generates the microwave energy that heats food. Replace a weak or failed unit to restore proper cooking performance and resolve no-heat complaints when the microwave appears to run but no longer warms items. What it does:

• Converts high-voltage power into microwave energy to heat food inside the oven cavity
• Failure can cause: microwave runs but won't heat or takes much longer to heat
• Often accompanied by a loud humming/buzzing during cook
• May trip the internal fuse/breaker or shut off shortly after start
• Visible damage to the magnetron antenna cap or signs of arcing near the waveguide can point to failure

• 1 magnetron assembly

• Unplug the microwave and safely discharge the high-voltage capacitor before servicing
• Remove the outer cover to access the magnetron; note wire locations and orientation
• Transfer any required mounting hardware/shields from the old part; avoid touching or damaging the ceramic insulators or antenna cap
• Reassemble completely and test heating with a cup of water—never operate the unit empty

• No-heat issues can also be caused by a failed high-voltage diode, capacitor, transformer, or door switches; diagnose where safe before replacing

This power cord assembly provides the main electrical connection for the appliance, restoring safe, reliable power delivery when the original cord is damaged or fails. Designed to match the OEM connection type and fit. What it does:

• Delivers mains power from the wall outlet to the appliance's terminal block
• Replaces frayed, cut, or heat-damaged power cords that can cause loss of power
• Helps stop symptoms like the appliance not powering on, intermittent power, or visible cord damage
• Restores a proper grounding/neutral connection when the cord or terminals are compromised

• Always disconnect power at the breaker and verify the appliance is de-energized before servicing
• Secure the cord with the appliance's strain relief or clamp to prevent stress on the electrical terminals

This part has been discontinued and is no longer available.

The Fuse is an OEM part for GE microwaves. It serves as a safety device designed to protect the microwave from excessive current that can cause overheating and potential fire hazards. When the current flowing through the microwave circuit exceeds a certain level, the fuse blows or breaks, cutting off the power to prevent damage or fire.

Common causes for a fuse to blow include power surges, faulty wiring within the appliance, or the use of microwave inappropriate containers that cause sparks. It is essential to address these issues not only to replace the fuse but also to correct the underlying problems to prevent future failures.

Symptoms of a bad fuse include:

• The microwave suddenly stops working.
• No signs of power or response even when the microwave door is closed and the start button is pressed.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This high-voltage rectifier diode is used in the microwave's high-voltage circuit. It converts AC to DC so the magnetron can produce heat. A failed diode can cause no heat, loud humming, or a blown fuse when starting. What it does:

• Rectifies high-voltage AC to DC to power the magnetron
• Blocks reverse voltage in the HV circuit
• Common failure symptoms can include: runs but doesn't heat; loud hum then shutdown; line fuse blows at startup

• 1 high-voltage diode

• Unplug the microwave and properly discharge the high-voltage capacitor before servicing—dangerous voltage can remain even when unplugged
• Match diode orientation/polarity to the original and ensure a solid chassis ground connection where used
• Route leads and reinstall any clamps/insulators exactly as found; keep wiring clear of sharp edges and hot components
• If the original diode failed, inspect the HV capacitor and transformer for related issues before reassembly

This gas flame sensor detects whether a burner's flame is present so the range/oven's gas valve and ignition control can operate safely. It helps restore reliable ignition and prevents the valve from staying open when no flame is detected. What it does:

• Senses the presence of a gas flame and signals the control to keep the valve open
• Helps prevent gas flow if a flame is not detected
• Can stop ignition or cause the oven/range not to heat when failing
• Commonly replaced when burners won't stay lit or control shows ignition-related errors

• One gas flame sensor

• Turn off electrical power and shut off the gas supply before servicing
• Handle the sensor and its connector carefully to avoid damage
• Reinstall in the exact position and orientation; loose connections can cause false faults
