Parts for Ge ZEM200WV01: 01 - Section1 Parts

This magnetron generates microwave energy to heat food in compatible countertop and over-the-range microwaves. Replacing a worn magnetron restores cooking power and helps eliminate uneven heating or failure to heat. What it does:

• Converts high-voltage electrical power into microwave radiation used to cook and reheat food
• Common symptom: oven runs but food doesn't heat or heats very slowly
• May also be needed if you notice loud buzzing, arcing, or burning odors during operation
• Works with the microwave's high-voltage system; other components may also need inspection

• One magnetron (single unit as shown)

• Disconnect power and discharge the microwave's high-voltage capacitor before servicing
• Inspect surrounding parts (waveguide, diode, capacitor, and cooling fan) for damage during replacement
• Use only the correct replacement part number to ensure proper fit and safe operation

This high-voltage rectifier diode is used in the microwave's high-voltage circuit. It converts AC to DC so the magnetron can produce heat. A failed diode can cause no heat, loud humming, or a blown fuse when starting. What it does:

• Rectifies high-voltage AC to DC to power the magnetron
• Blocks reverse voltage in the HV circuit
• Common failure symptoms can include: runs but doesn't heat; loud hum then shutdown; line fuse blows at startup

• 1 high-voltage diode

• Unplug the microwave and properly discharge the high-voltage capacitor before servicing—dangerous voltage can remain even when unplugged
• Match diode orientation/polarity to the original and ensure a solid chassis ground connection where used
• Route leads and reinstall any clamps/insulators exactly as found; keep wiring clear of sharp edges and hot components
• If the original diode failed, inspect the HV capacitor and transformer for related issues before reassembly

The Microwave Door Switch is an OEM part for GE microwaves, designed to prevent the microwave from operating when the door is open by interrupting the power whenever the door is not securely closed. The door switch is an essential safety feature.

Symptoms of a failing Microwave Door Switch include:

• The microwave not starting or heating
• Running when the door is opened
• Unusual noises when the door is closed

Causes of a bad Microwave Door Switch can result from repeated opening and closing of the door or slamming that can cause the switch to degrade or become misaligned, leading to intermittent or failure.

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

The Microwave Door Switch is an OEM part for GE microwaves, designed to prevent the microwave from operating when the door is open by interrupting the power whenever the door is not securely closed. The door switch is an essential safety feature.

Symptoms of a failing Microwave Door Switch include:

• The microwave not starting or heating
• Running when the door is opened
• Unusual noises when the door is closed

Causes of a bad Microwave Door Switch can result from repeated opening and closing of the door or slamming that can cause the switch to degrade or become misaligned, leading to intermittent or failure.

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

This small replacement cushion pads the oven lamp cover to prevent vibration and keep the glass cover seated securely. It restores a snug fit so the lamp cover doesn't rattle or shift during oven use. What it does:

• Cushions and centers the oven lamp cover to reduce rattling and vibration
• Helps keep the lamp cover properly seated and aligned with the housing
• Protects the lamp glass from direct contact with metal edges
• Can be used if the original cushion is torn, missing, or hardened

• One oven lamp cover cushion

• Disconnect power to the appliance before servicing; allow the oven to cool completely
• Remove the lamp cover and replace the worn or missing cushion, then re-seat the cover
• Handle the lamp glass carefully to avoid breakage; wear gloves and eye protection
• If the cover or lamp assembly is cracked or damaged, replace the damaged components rather than relying solely on the cushion

This gas flame sensor detects whether a burner's flame is present so the range/oven's gas valve and ignition control can operate safely. It helps restore reliable ignition and prevents the valve from staying open when no flame is detected. What it does:

• Senses the presence of a gas flame and signals the control to keep the valve open
• Helps prevent gas flow if a flame is not detected
• Can stop ignition or cause the oven/range not to heat when failing
• Commonly replaced when burners won't stay lit or control shows ignition-related errors

• One gas flame sensor

• Turn off electrical power and shut off the gas supply before servicing
• Handle the sensor and its connector carefully to avoid damage
• Reinstall in the exact position and orientation; loose connections can cause false faults

Ceramic

This wire harness "B" connects electrical circuits inside the appliance to restore reliable power and signal routing. It replaces a damaged or worn harness to help components receive proper electrical connections. What it does

• Provides the factory routing and connector set for the appliance's internal electrical circuits
• Restores power and signal continuity when a broken or shorted harness causes intermittent or no operation
• Prevents loose or exposed wires that can cause arcing or component failure
• Matches OEM connector types to ensure a secure fit with control boards and components

• One replacement wire harness "B"

• Disconnect power before starting any repair to avoid shock or injury
• Compare the new harness to the old one to ensure correct connector types and lengths before installing
• Route and secure the harness using the same clips and fasteners to prevent chafing or pinching
• If wiring or connector damage is observed beyond the harness, inspect adjacent components and wiring; do not attempt unsafe splices

This complete freezer door assembly restores the freezer access panel and outer finish, helping the freezer seal properly and maintain consistent temperature. Ideal for replacing a dented, bent, or non-sealing freezer door. What it does

• Replaces the freezer door panel and outer components so the door closes and seals properly.
• Helps stop cold air loss that can lead to frost buildup or warmer-than-normal freezer temperatures.
• Restores the exterior appearance when the original door is dented, cracked, or cosmetically damaged.
• Works with existing hinges, gasket, and handle locations to return normal door operation.

• Disconnect power and empty the door area before starting; support the door during removal.
• Two people may be required to remove/install the assembly to avoid dropping or damage.
• Keep existing hinge hardware and gasket unless replacement items are specified.
• Follow model-specific service manual or OEM instructions for alignment and torque specs.

A small keyed retaining spring that secures and tensions moving components to restore proper engagement and alignment. Replaces a worn or missing spring to help stop loose parts and intermittent engagement. What it does:

• Holds keyed components or shafts in place to maintain proper alignment and operation
• Provides tension for reliable engagement of latches or moving parts
• Helps eliminate play, rattling, or intermittent contact caused by a broken or missing spring
• Used where a compact, keyed retaining spring is required for secure fit

• Disconnect power before beginning any repair to avoid shock or injury
• Verify correct orientation and seating of the keyed end before tightening or reassembling
• Use basic hand tools; avoid forcing parts—if it won't seat easily, recheck alignment
