Parts for Kenmore 194.95 / 1988 (19495 / 1988, 194 95 / 1988): Motor Assembly-Pump Motor Parts

Removes residue, odor-causing soils, and food particles from dishwasher tub and gasket. Use monthly to eliminate unwanted odors and maintain peak performance.

This motor clip secures a motor to its mounting bracket or housing, keeping it aligned and stable during operation. Replacing a bent, broken, or missing clip helps stop rattling and prevents the motor from shifting. What it does:

• Retains the motor on its mounting bracket or frame
• Helps maintain alignment to reduce vibration and noise
• Prevents movement that can cause rubbing or wire strain
• Direct replacement when the original clip is damaged or missing

• One motor clip

• Disconnect power before servicing; allow all moving parts to stop
• Access the motor area, note the clip's orientation, and remove the damaged clip
• Seat the motor fully, then install the new clip to secure it to the bracket
• Inspect related mounts/grommets and wiring for wear; verify clearances before restoring power

This drive belt links the dishwasher's motor to the pump so the machine can circulate wash water and drain properly. Replacing a worn or broken belt restores wash action and helps eliminate slipping or squealing during cycles.

• Transfers motor power to the pump for water circulation and draining
• Common fix for no wash action or poor cleaning
• Can address squealing/chirping noises or a burning rubber smell
• Replaces belts that are cracked, frayed, stretched, or glazed

• Disconnect power and turn off the water supply before servicing
• Remove the lower access/toe panel to reach the motor and pump area
• Note belt routing; rotate the old belt off the pulleys and install the new belt the same way
• Check pulley alignment and hand-rotate to seat the belt before running a test cycle

A single mounting screw designed to secure panels, brackets, or components on your appliance for reliable fit and reduced vibration. Use this genuine replacement when a fastener is missing, stripped, or rusted. What it does:

• Fastens panels, trim, or mounting brackets to restore proper alignment
• Helps eliminate rattling or vibration caused by loose or missing screws
• Replaces corroded or damaged hardware to maintain safe operation
• Restores secure attachment for parts that no longer hold in place

• Disconnect power to the appliance before starting any repair
• Use the correct driver bit to avoid stripping the screw head
• Tighten until snug; avoid overtightening which can strip threads or damage parts
