Parts for Thermador T30IR70CSS-01: Profile Stripe Parts

This active carbon filter refreshes the air when your range hood is set to recirculate. Replace a saturated filter to restore effective odor reduction and maintain a more comfortable cooking space. What it does:

• Adsorbs cooking odors in recirculating operation
• Helps maintain fresher indoor air when venting back into the room
• Restores odor-removal performance when the old filter is saturated
• Typical signs it's time to replace: persistent cooking smells or diminished odor reduction

• One activated carbon filter

• Disconnect power to the hood before servicing
• Remove the metal grease filter(s) to access the charcoal filter
• Release the old filter from its clips/bayonet mount and install the new filter in the same orientation until it locks
• Charcoal filters are not washable; replace when saturated

• For hoods configured for recirculation; not used when vented to the outdoors

Replacement retaining pin that secures appliance components so panels, hinges or linkages stay connected. Use this direct-fit hardware to restore proper alignment and reduce looseness, rattling or separation caused by a missing, bent or worn pin.

• Secures mating parts like hinges, levers or shafts to prevent separation and play
• Common symptom: loose or rattling door/panel or misaligned assembly where the original pin is missing or damaged
• Typical use: keeps pivot points and small assemblies aligned for proper operation
• Metal fastener designed for a simple, local replacement

• Disconnect power (and water, if appliance type requires) before servicing
• Remove any obstructions and note original orientation before removing the old pin
• Use appropriate hand tools; do not force parts—if fit is tight, inspect mating components for damage

A decorative profile stripe that restores the finished look of the appliance door and covers the front edge for a clean appearance. Fits where the original trim is scratched, faded, dented, or missing. What it does:

• Replaces worn or damaged door trim to improve the appliance's exterior appearance
• Covers gaps along the door edge and restores a uniform front profile
• Helps keep the door edge protected from everyday bumps and scrapes
• Works with the existing mounting points or trim channel for a secure fit

• Install with the door open on a stable surface; follow the appliance service manual for disassembly and reassembly steps
• May snap into place or use adhesive depending on model—do not force parts; inspect clips or mounting features before seating
• Disconnect power and follow general electrical and safety precautions if partial disassembly exposes wiring or panels

A decorative profile stripe that restores the appliance's finished appearance and covers the cabinet edge. Replaces a worn, cracked, or missing trim piece to improve the look of the unit. What it does

• Provides the exterior trim/edge cover that completes the appliance front
• Hides gaps between panels and creates a smooth, finished appearance
• Commonly replaced when the stripe is cracked, peeled, scratched, or missing
• Helps prevent dirt and moisture from collecting in exposed seams

• One profile stripe decorative trim piece as shown

• Generally installs by snapping or sliding into place; follow your model's service instructions
• Clean mating surfaces and remove adhesive residue before installation for best fit
• Handle carefully to avoid scratching the finish during installation
