Parts for Thermador T30IR70CSS-01: Refrigerator Door Parts

This active carbon filter refreshes the air when your range hood is set to recirculate. Replace a saturated filter to restore effective odor reduction and maintain a more comfortable cooking space. What it does:

• Adsorbs cooking odors in recirculating operation
• Helps maintain fresher indoor air when venting back into the room
• Restores odor-removal performance when the old filter is saturated
• Typical signs it's time to replace: persistent cooking smells or diminished odor reduction

• One activated carbon filter

• Disconnect power to the hood before servicing
• Remove the metal grease filter(s) to access the charcoal filter
• Release the old filter from its clips/bayonet mount and install the new filter in the same orientation until it locks
• Charcoal filters are not washable; replace when saturated

• For hoods configured for recirculation; not used when vented to the outdoors

This door hinge secures and guides an appliance door, restoring stable, smooth opening and closing. Use it to replace a broken, bent, or worn hinge so the door hangs correctly and seals as intended. What it does:

• Provides a pivot point so the door opens and closes smoothly
• Restores proper door alignment and prevents sagging or dragging
• Helps the door form a proper seal to maintain temperature and function
• Fits the factory mounting locations for a direct replacement

• One door hinge

• Disconnect power and empty the door before starting; support the door while removing mounting screws
• Use appropriate hand tools and keep fasteners for reuse unless new hardware is provided
• Tighten screws securely but avoid over-torquing to prevent damage

This genuine replacement fixture secures internal components to prevent movement and ensure stable operation. Restores proper alignment and reduces vibration where a damaged or missing mounting retainer causes instability. What it does:

• Secures and positions internal parts so assemblies stay aligned during use
• Reduces rattling, vibration, and intermittent contact caused by loose components
• Helps maintain seals and connections by keeping parts properly seated
• Useful when the original fixture is cracked, broken, or missing

• Disconnect power (and water supply if applicable) before starting any repairs
• Inspect surrounding clips or fasteners; replace any damaged hardware for a secure fit
• Hand-start fasteners, then tighten to snug — avoid overtightening plastic parts

This is a mounting fixing kit used to secure specific dishwasher components. It replaces worn or missing hardware so parts stay firmly in place and the appliance operates as intended.

• Secures designated parts to prevent loosening, rattling, or misalignment
• Helps resolve issues like loose panels or components shifting during cycles
• Useful when original fasteners are stripped, corroded, or lost
• Restores proper fitment after service or replacement of related parts

• Disconnect power and turn off water before servicing
• Keep track of original hardware locations for correct reassembly
• Hand-start screws to avoid cross-threading; tighten to snug, do not overtighten
• Address corrosion or damage present on mating parts before installation

This air grid installs in the appliance's air-flow path to direct and protect internal ventilation. It helps maintain even circulation so the appliance cools and operates as designed. What it does

• Directs internal airflow to promote consistent temperature distribution
• Protects ventilation openings from debris and large obstructions
• Helps prevent localized warming or frost buildup caused by poor airflow
• Works with the appliance's blower/evap system to maintain performance

• One air grid / vent grille

• Install in the original orientation; part snaps or screws into the ventilation opening
• Remove power to the appliance before accessing internal panels or components
• Inspect surrounding foam seals and mounting tabs; replace if damaged to preserve airflow control

A replacement refrigerator door seal that restores the fridge door's airtight seal to help maintain proper cooling and energy efficiency. Fits molded-edge style doors and replaces worn, cracked, or torn gaskets. What it does:

• Creates an airtight seal around the refrigerator door to help keep cold air in and warm air out
• Helps prevent moisture buildup and frost inside the compartment
• Reduces energy use caused by a leaking door gasket
• Commonly used when the existing seal is cracked, torn, flattened, or no longer seats properly

• One door seal/gasket (single piece)

• Inspect the door flange and mounting channel for debris or damage before installing
• Clean the flange and allow it to dry for proper adhesion and seating
• Gasket may require a short break-in period to fully seat; avoid forcing the door closed tightly during initial cycles

This fixture is a small mounting clamp that secures internal components in place to keep them aligned and stable during normal appliance operation. It helps reduce movement and vibration for a quieter, more reliable appliance. What it does:

• Holds internal assemblies or wiring harnesses securely to prevent shifting
• Keeps parts properly positioned to maintain function and reduce wear
• Helps reduce rattling or vibration caused by loose components
• Supports safe, consistent operation by keeping components from contacting other parts

• Disconnect power and water supply before accessing internal components
• Basic hand tools may be required to remove panels and fasten the fixture
• Inspect surrounding clips and fasteners; replace any that are damaged

This fixture is a small mounting clip designed to secure internal components and panels so they stay correctly positioned during normal appliance operation. It helps reduce movement that can cause noise or misalignment. What it does:

• Secures and positions internal parts or panels to prevent shifting
• Reduces vibration-related noise by holding components firmly
• Helps maintain proper alignment for connected assemblies
• Common symptom: loose or rattling panels or parts that move during operation

• One mounting fixture

• Disconnect power to the appliance before starting any repair
• Use basic hand tools; avoid forcing the clip into place to prevent breakage
• Inspect mating surfaces and replace any damaged mounts or clips
• Test the appliance after installation to ensure the part holds components securely

This fixture is the OEM mounting bracket used to secure internal components inside the appliance, keeping assemblies aligned and stable for reliable operation. It replaces a broken or worn bracket to restore proper fit and reduce movement. What it does

• Secures and positions internal parts to prevent shifting or rattling during operation
• Restores proper alignment of assemblies that rely on the bracket for support
• Can help stop intermittent noises or misfeeds caused by a loose or broken mount
• Protects adjacent components by holding parts in the correct location

• One fixture (mounting bracket) as shown

• Always disconnect power and water before starting repairs
• Typical installation requires basic hand tools; avoid overtightening plastic fasteners
• If damaged surrounding fittings are present, inspect and replace them to ensure a secure fit
