Parts for Kitchenaid KFCP22EXMP5: 03 - Refrigerator Liner Parts

This housing is the replacement outer tub housing that supports and secures the washer tub and related drive components for proper alignment and operation. Restores stable drum mounting and reduces abnormal motion. What it does:

• Supports the washer's tub/drum assembly so the drum spins smoothly and stays aligned
• Provides a mounting surface for suspension and drive components to reduce vibration and noise
• Helps prevent rubbing or scraping by keeping internal components correctly positioned
• Commonly replaced when the tub feels loose, spins unevenly, or makes unusual noises

• One housing

• Disconnect power to the appliance before beginning any repair
• Handle with care to avoid damaging seals, sensors, or surrounding trim pieces
• Verify correct orientation and torque for fasteners; follow OEM service manual steps

This user interface control board manages the oven's front-panel display and touch controls so you can select functions, set temperatures and start cycles. Replacing a failed UI board restores normal control and display feedback. What it does:

• Receives and processes inputs from the touchpad or buttons so selections start the correct cycles
• Drives the front-panel display and indicator lights for cycle status and settings
• Communicates commands to the main control to trigger heating and timing operations
• Fault symptom coverage: blank or unresponsive display, unresponsive touchpad/buttons, or incorrect front-panel behavior

• One user interface control board

• Disconnect power at the breaker before starting any repair to prevent shock
• Handle the board by edges and avoid touching components; observe anti-static precautions
• Verify connectors are fully seated but do not force; match connector shapes and pin counts

This replacement housing is the outer cabinet component that supports and protects internal appliance parts, restoring proper alignment and preventing debris intrusion. It's a direct-fit service piece when the original housing is cracked, bent, or damaged. What it does:

• Replaces a damaged or cracked outer housing to restore structural support
• Protects internal components from dirt, moisture, and impact
• Reduces vibration and rattling caused by warped or broken housing
• Helps maintain correct alignment of internal assemblies for reliable operation

• One replacement housing

• Disconnect power (and water if applicable) before starting any repair
• Handle edges carefully — use gloves to protect against sharp metal or plastic
• Follow OEM instructions for removal and reassembly; fasteners and trim may be required

The Light Bulb Socket is an OEM part for Whirlpool refrigerators. It is responsible for housing the bulb that illuminates the interior fridge light. The socket provides a protective casing and stable electrical connection for the light bulb. Its interior components are precisely arranged to safely conduct current to the bulb.

Causes of a bad light bulb socket can include cracks, loose connections, or damaged internal wiring due to regular use over time.

Symptoms of a bad light bulb socket include:

• The fridge interior light failing to turn on
• The bulb burning out quickly
• Flickering or intermittent lighting

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This damper cover insert fits the refrigerator's air damper/diffuser. It helps guide and seal airflow from the freezer to the fresh food section, supporting stable temperatures and reducing drafts when the original insert is cracked or missing.

• Seats inside the damper cover to shape and restrict airflow between freezer and refrigerator compartments
• Helps seal the vent opening to limit air leaks
• Supports proper temperature balance and airflow distribution in the fresh food section
• Typical symptoms include a broken/missing insert, air drafts at the vent, rattling from the cover, or inconsistent cooling

• Disconnect power to the refrigerator before servicing
• Remove shelves as needed and access the damper cover in the fresh food compartment
• Release and remove the damaged insert; snap the new insert into the cover with correct orientation and a secure fit
• Handle nearby foam seals and the damper door carefully to avoid damage

This base damper cove is the plastic cover that protects and supports the refrigerator damper assembly, keeping airflow components secure and helping maintain proper internal airflow. Replacing a damaged cove prevents loose parts and air leaks. What it does:

• Protects the damper assembly and related components from debris and damage
• Helps maintain proper airflow routing between compartments
• Reduces rattling or vibration from a loose or broken damper cover
• Can prevent cold-air leaks that contribute to uneven cooling

• One base damper cove

• Disconnect power to the appliance before beginning any service
• Remove the kickplate or access panel to reach the damper area as required
• Handle plastic pieces gently to avoid cracking; use proper fasteners if provided

This insulation panel helps reduce heat transfer in the refrigerator cabinet so the appliance holds cold temperatures more efficiently and reduces frost buildup. It's a direct-fit replacement for the factory cabinet insulation. What it does:

• Slows thermal transfer between the cabinet and ambient air to help maintain interior temperatures
• Helps reduce frost buildup on evaporator and interior surfaces
• Improves cooling efficiency by minimizing cold-air loss
• Quietly adds a layer of thermal and acoustic insulation behind the liner

• Disconnect power and remove food before starting any repair
• Access requires removing the interior liner or trim
• Handle gently and wear gloves; insulation can tear or shed fibers
• Follow OEM instructions for adhesive or fastener placement and secure fit

The Damper Control Assembly is an OEM part for Whirlpool refrigerators. It regulates the airflow between the refrigerator and freezer compartments, maintaining optimal temperatures and ensuring efficient cooling. This assembly helps control the amount of cold air that enters the refrigerator section from the freezer.

Causes of a bad damper control assembly can include wear and tear over time, damage from temperature fluctuations, or malfunctioning electronic components.

Symptoms of a bad damper control assembly include:

• Inconsistent temperatures in the refrigerator
• Freezer being too cold while the refrigerator is too warm
• Frost buildup in the refrigerator compartment
• Unusual noises coming from the damper area

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Whirlpool Refrigerator Water Filter Head is an OEM part for Whirlpool refrigerators. It serves as the connection point for the water filter, allowing clean, filtered water to flow to your refrigerator's dispenser and ice maker. This part ensures that your refrigerator delivers fresh and safe drinking water.

Causes of a bad water filter head can include wear and tear over time, mineral buildup from hard water, or damage due to improper installation or mishandling.

Symptoms of a bad water filter head include:

• Water leaks around the filter area
• Decreased water flow from the dispenser
• Ice maker not producing ice
• The filter not locking into place correctly

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This replacement screw secures panels, brackets, and components inside appliances. Replacing a missing or stripped fastener restores a snug, rattle-free fit using the correct #8-18 thread and 5/8-inch length.

• Fastens covers, trims, brackets, and internal parts to the cabinet/frame
• Used wherever a #8-18 x 5/8 screw is specified
• Replace if the original is missing, corroded, stripped, or will not tighten
• Symptoms: loose or rattling panels, gaps, or hardware that backs out

• Disconnect power; shut off gas/water before servicing
• Match thread and length; start by hand to avoid cross-threading
• Use the correct driver bit and tighten snugly—do not overtighten
• Inspect and replace damaged clips or tabs before securing

This replacement cover shields and finishes a designated area of your appliance, protecting internal components from dust, moisture, and accidental contact. Replace a cracked or missing cover to maintain proper operation and a clean, finished look.

• Protects internal parts from debris and moisture intrusion
• Restores intended airflow/containment and component protection
• Helps reduce rattles or vibration from loose or broken trim
• Common signs it's needed: cracks, broken tabs, loose fit, or exposed components

• Disconnect power; also shut off water supply
• Retain and reuse original screws/clips unless your model specifies otherwise
• Align tabs and mounting holes carefully to avoid stress on plastic
• Do not overtighten fasteners; snug by hand to prevent cracking

This replacement cover shields and finishes a designated area of your appliance, protecting internal components from dust, moisture, and accidental contact. Replace a cracked or missing cover to maintain proper operation and a clean, finished look.

• Protects internal parts from debris and moisture intrusion
• Restores intended airflow/containment and component protection
• Helps reduce rattles or vibration from loose or broken trim
• Common signs it's needed: cracks, broken tabs, loose fit, or exposed components

• Disconnect power; also shut off water supply
• Retain and reuse original screws/clips unless your model specifies otherwise
• Align tabs and mounting holes carefully to avoid stress on plastic
• Do not overtighten fasteners; snug by hand to prevent cracking

This limit switch is a temperature safety device that opens the circuit if heat rises too high. Replacing a weak or failed switch restores proper overheat protection and can resolve nuisance shutdowns or no-heat conditions due to an open safety. What it does:

• Monitors temperature at its mounting location
• Opens the electrical circuit at a preset over-temperature to stop heating or operation
• Helps protect internal components and wiring from heat damage
• Common symptoms include: won't heat, shuts off during use, or no power after an overheat event

• 1 limit switch

• Disconnect power (and gas, if applicable) before servicing
• Access the switch, note wire positions, and transfer wires one at a time
• Mount the switch flat and firmly against the original sensing surface or bracket
• After replacement, check for root causes of overheating (blocked airflow, failed fan, dirty filters, shorted element)

The Water Line Union is an OEM part for Whirlpool refrigerators. It connects sections of the water line, ensuring a secure and leak-proof connection that facilitates the proper flow of water to the ice maker and water dispenser.

Causes of a bad water line union can include wear and tear from prolonged use, exposure to fluctuating temperatures, or physical damage from handling.

Symptoms of a bad water line union include:

• Leaks or water pooling around the refrigerator
• Reduced water flow to the dispenser or ice maker
• Water line disconnections
• Visible cracks or damage on the union

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

The Cartridge Bypass is an OEM part for Whirlpool refrigerators. It is designed to replace the water filter cartridge when filtration is not desired or necessary. This allows the refrigerator to bypass the filter and provide unfiltered water to the dispenser and ice maker.

Common causes of failure include wear and tear, improper installation, or physical damage from mishandling.

Symptoms of a bad Cartridge Bypass include:

• Water leakage around the filter area
• Reduced water flow or no water flow from the dispenser
• Ice maker not producing ice

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This wire harness is the factory-style electrical connector assembly that routes power and signals between components for reliable operation. It replaces worn, damaged, or corroded wiring to restore proper connectivity and help stop intermittent electrical faults. What it does:

• Connects control, sensors, and power circuits so the appliance components communicate and run correctly
• Replaces frayed wires or broken connectors that can cause intermittent operation or complete failure
• Restores factory routing and connector fit to prevent chafing and shorts
• Helps eliminate loose or corroded connections that can cause error codes or operational issues

• One complete wire harness assembly

• Disconnect electrical power before beginning any service to avoid shock or injury
• Verify connector orientation and routing; secure with existing clips or cable ties to prevent rubbing
• Inspect mating connectors and terminals—replace if pins are bent or corroded
