Parts for Ge JTP17WT1WW: 04 - Section4 Parts

This oven door latch assembly secures the door during the self-clean cycle and reports lock status to the control. Replace a worn or failed latch to restore safe locking and reliable self-clean operation.

• Locks the oven door during self-clean to prevent opening at high temperatures
• Signals the control when the door is locked or unlocked
• Helps the oven start and complete a self-clean cycle safely
• Typical symptoms: self-clean won't start or finish, door won't lock/unlock, lock motor runs continuously or is noisy, lock indicator stays on

• Disconnect power at the breaker and allow the oven to cool completely before servicing
• Access is typically from the top or behind the control panel; remove panels as required and note linkage/switch orientation
• Transfer any linkages or mounting hardware from the original latch in the same orientation
• Manually cycle the latch to verify smooth operation before restoring power and testing self-clean

The Element Convx is an OEM part for GE ovens. This convection element is designed to provide consistent and even heat distribution within the oven, ensuring optimal cooking and baking results. It typically works in conjunction with the convection fan to circulate hot air evenly throughout the oven cavity.

Causes of a bad convection element can include regular wear and tear, electrical surges, or damage from physical impact. A malfunctioning element can lead to uneven cooking, longer preheating times, and overall reduced oven performance.

Symptoms of a bad convection element include:

• Uneven cooking or baking results
• The oven not reaching the set temperature
• Longer than usual preheating times
• The convection fan operating without generating heat

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

Note: Motor only - convect fan WB2X8351 not included.

Replacement fan blade that mounts to the motor shaft to circulate air inside the appliance, restoring airflow and reducing vibration or noise from damaged or bent blades. Works with the fan motor to help maintain proper cooling and ventilation. What it does:

• Spins on the motor shaft to move air through the appliance's cabinet or evaporator area.
• Restores even airflow for more consistent cooling and performance.
• Reduces excessive noise and vibration caused by cracked, warped, or missing blades.
• Helps prevent airflow-related issues such as warm spots or slow cooling when the fan is not operating properly.

• Disconnect power to the appliance before servicing to avoid electric shock or injury.
• Remove interior panels or housing to access the fan; handle the blade carefully — edges can be sharp.
• Slide the blade onto the motor shaft and secure per OEM method (set screw, clip, or hub); ensure proper alignment and rotation direction.
• Test fan operation after installation and reassemble panels securely.

This upper fan cover protects the dryer's blower area and helps direct airflow so the machine vents properly and runs quietly. It replaces a cracked or damaged cover to restore safe airflow routing and reduce rubbing or rattling noises. What it does:

• Shields the blower and upper fan assembly from lint and debris
• Directs exhaust airflow through the vent path for efficient drying
• Prevents contact between the fan and cabinet that can cause noise or wear
• Helps reduce hot spots that contribute to overheating symptoms

• Disconnect power (unplug or switch off breaker) before beginning any repair
• Access typically requires removing the dryer cabinet top or rear panel; follow your model's disassembly steps
• Handle edges and surrounding components carefully—sharp sheet metal may be present
• Inspect nearby seals, mounting clips, and the blower wheel for damage while replacing the cover

Package of 12

This replacement screw secures appliance components so panels, brackets, and assemblies stay tight and aligned. Replace stripped or missing hardware to eliminate rattles and keep your unit assembled safely and correctly.

• Fastens panels, brackets, or components to the appliance frame
• Restores a secure fit when the original screw is lost, stripped, or corroded
• Helps prevent vibration noise and movement during operation
• Supports proper alignment of trim and assemblies

• Disconnect power; for gas units, also shut off the gas supply
• Use the correct driver to avoid stripping the head; do not overtighten
• Inspect and address damaged mating threads, clips, or brackets before reinstalling
• Refer to your model's parts diagram to confirm location and quantity

Package of 12

Black. 8-18 AB HXW 3/8

Includes 12 washers.

This is a flat metal washer used to secure fasteners and maintain proper spacing on the appliance. It provides a simple, durable spacer that helps keep components aligned and fasteners snug for reliable performance. What it does:

• Acts as a spacer to maintain correct clearance between parts
• Distributes load from a fastener to prevent pull-through or damage
• Helps keep bolts and screws from loosening under vibration
• Can reduce noise or vibration caused by loose or misaligned components

• Disconnect power (and water if applicable) before beginning any repair.
• Use the correct fastener and orientation for reassembly; replace any damaged hardware.
• Tighten fasteners snugly but avoid over-torquing;
• If the appliance shows continued vibration, noise, or instability after replacing the washer, further inspection of mounting hardware and suspension components is recommended.

This is a replacement mounting nut used to secure appliance components and fasteners. It restores proper fastening where a stripped, lost, or damaged nut causes loose panels or rattling, helping stabilize the assembly. What it does:

• Secures studs, bolts, or threaded fasteners to hold parts in place
• Prevents movement and vibration that can cause noise or misalignment
• Replaces stripped, rusted, or missing nuts to restore safe operation
• Matches OEM fit for a secure, long-lasting connection

• Disconnect power and unplug the appliance before starting any repair
• Use the correct socket or wrench size to avoid rounding the nut
• Tighten to snug; avoid overtightening which can strip threads or damage components
